Canvas NEMA C/CE Fabric Reinforced Phenolic Tubes - .750 Wall
Canvas C/CE Fabric Reinforced Phenolic -
natural (light tan to brown)
Technical Data Sheet
This grade is composed of a continuous cotton woven cloth
impregnated with a phenolic resin binder. This grade contains a medium weave
canvas and is known primarily for it's mechanical properties. This grade is not
recommended for primary insulation.
NEMA grades C, and CE Canvas Cotton-Cloth Reinforced Phenolic -- natural color is typically light tan to brown. C and CE grades are composed of a continuous cotton woven cloth impregnated with a phenolic resin binder. These grades contain a medium weave canvas and are known primarily for their mechanical properties. These grades are not recommended for primary electrical insulation.
(NEMA C certifies to Mil-I-24768/16 FBM, IEC 60893-3 Type 4, PF CC 201)
(NEMA CE certifies to Mil-I-24768/14 FBG, IEC 60893-3 Type 4, PF CC 203)
NEMA C/CE Tubes NEMA C/CE Sheets NEMA C/CE Bar Stock
Tubes are made in random lengths between 30" - 36".
Our pricing and minimums are based on the 36".
Tubes can also be made in 42" to 48" random lengths for the same pricing.
Measured lengths of 36"±1" and 48"±1" are also available via manual quote.
| .750" Wall Thickness - C, CE Tubing | |||||
| Part # | OD (in.) | ID (in.) | Minimum | Price Per Foot | Order Online |
|---|---|---|---|---|---|
| KM-17424 | 2.000 | .500 | 9 Feet | $141.09 | Add to Order |
| KM-17401 | 2.062 | .562 | 9 Feet | $147.60 | Add to Order |
| KM-17432 | 2.125 | .625 | 9 Feet | $154.11 | Add to Order |
| KM-17431 | 2.188 | .687 | 9 Feet | $160.62 | Add to Order |
| KM-17430 | 2.250 | .750 | 9 Feet | $167.13 | Add to Order |
| KM-17429 | 2.312 | .812 | 9 Feet | $173.64 | Add to Order |
| KM-17428 | 2.375 | .875 | 9 Feet | $180.15 | Add to Order |
| KM-17427 | 2.437 | .937 | 9 Feet | $186.66 | Add to Order |
| KM-17426 | 2.500 | 1.000 | 9 Feet | $179.37 | Add to Order |
| KM-17425 | 2.562 | 1.062 | 9 Feet | $185.34 | Add to Order |
| KM-17412 | 2.625 | 1.125 | 9 Feet | $191.43 | Add to Order |
| KM-17423 | 2.688 | 1.187 | 9 Feet | $197.43 | Add to Order |
| KM-17434 | 2.750 | 1.250 | 6 Feet | $203.52 | Add to Order |
| KM-17421 | 2.812 | 1.312 | 6 Feet | $209.52 | Add to Order |
| KM-17420 | 2.875 | 1.375 | 6 Feet | $215.61 | Add to Order |
| KM-17419 | 2.937 | 1.437 | 6 Feet | $221.61 | Add to Order |
| KM-17418 | 3.000 | 1.500 | 6 Feet | $227.70 | Add to Order |
| KM-17417 | 3.062 | 1.562 | 6 Feet | $233.70 | Add to Order |
| KM-17416 | 3.125 | 1.625 | 6 Feet | $239.79 | Add to Order |
| KM-17415 | 3.188 | 1.687 | 6 Feet | $245.79 | Add to Order |
| KM-17414 | 3.250 | 1.750 | 6 Feet | $251.88 | Add to Order |
| KM-17413 | 3.312 | 1.812 | 6 Feet | $257.85 | Add to Order |
| KM-17388 | 3.375 | 1.875 | 6 Feet | $263.94 | Add to Order |
| KM-17354 | 3.437 | 1.937 | 6 Feet | $269.94 | Add to Order |
| KM-17399 | 3.500 | 2.000 | 6 Feet | $276.03 | Add to Order |
| KM-17364 | 3.562 | 2.062 | 6 Feet | $282.03 | Add to Order |
| KM-17363 | 3.625 | 2.125 | 6 Feet | $288.12 | Add to Order |
| KM-17362 | 3.687 | 2.187 | 6 Feet | $294.12 | Add to Order |
| KM-17361 | 3.750 | 2.250 | 6 Feet | $305.97 | Add to Order |
| KM-17360 | 3.812 | 2.312 | 6 Feet | $312.09 | Add to Order |
| KM-16241 | 3.875 | 2.375 | 6 Feet | $318.30 | Add to Order |
| KM-17359 | 3.937 | 2.437 | 6 Feet | $324.42 | Add to Order |
| KM-17358 | 4.000 | 2.500 | 6 Feet | $330.63 | Add to Order |
| KM-17357 | 4.062 | 2.562 | 6 Feet | $336.72 | Add to Order |
| KM-17345 | 4.125 | 2.625 | 6 Feet | $342.93 | Add to Order |
| KM-17355 | 4.187 | 2.687 | 6 Feet | $349.05 | Add to Order |
| KM-17366 | 4.250 | 2.750 | 6 Feet | $355.26 | Add to Order |
| KM-17353 | 4.312 | 2.812 | 6 Feet | $361.35 | Add to Order |
| KM-17352 | 4.375 | 2.875 | 6 Feet | $367.56 | Add to Order |
| KM-17351 | 4.437 | 2.937 | 6 Feet | $373.68 | Add to Order |
| KM-17350 | 4.500 | 3.000 | 6 Feet | $379.89 | Add to Order |
| KM-17349 | 4.562 | 3.062 | 6 Feet | $385.98 | Add to Order |
| KM-17348 | 4.625 | 3.125 | 6 Feet | $392.19 | Add to Order |
| KM-17347 | 4.687 | 3.187 | 6 Feet | $398.31 | Add to Order |
| KM-17346 | 4.75 | 3.250 | 3 Feet | $404.52 | Add to Order |
| KM-17377 | 4.812 | 3.312 | 3 Feet | $410.64 | Add to Order |
| KM-17379 | 4.875 | 3.375 | 3 Feet | $416.85 | Add to Order |
| KM-17356 | 4.937 | 3.437 | 3 Feet | $422.94 | Add to Order |
| KM-17387 | 5.000 | 3.500 | 3 Feet | $429.15 | Add to Order |
| KM-17386 | 5.062 | 3.562 | 3 Feet | $435.27 | Add to Order |
| KM-17385 | 5.125 | 3.625 | 3 Feet | $441.48 | Add to Order |
| KM-17384 | 5.187 | 3.687 | 3 Feet | $447.57 | Add to Order |
| KM-17383 | 5.250 | 3.750 | 3 Feet | $453.78 | Add to Order |
| KM-17382 | 5.312 | 3.812 | 3 Feet | $459.90 | Add to Order |
| KM-17381 | 5.375 | 3.875 | 3 Feet | $466.11 | Add to Order |
| KM-17380 | 5.437 | 3.937 | 3 Feet | $472.23 | Add to Order |
| KM-2116 | 5.500 | 4.000 | 3 Feet | $478.44 | Add to Order |
| KM-17378 | 5.562 | 4.062 | 3 Feet | $484.53 | Add to Order |
| KM-17389 | 5.625 | 4.125 | 3 Feet | $490.74 | Add to Order |
| KM-17376 | 5.688 | 4.187 | 3 Feet | $496.86 | Add to Order |
| KM-17375 | 5.750 | 4.250 | 3 Feet | $503.07 | Add to Order |
| KM-17374 | 5.812 | 4.312 | 3 Feet | $509.16 | Add to Order |
| KM-17373 | 5.875 | 4.375 | 3 Feet | $515.37 | Add to Order |
| KM-17372 | 5.938 | 4.438 | 3 Feet | $521.49 | Add to Order |
| KM-2121 | 6.000 | 4.500 | 3 Feet | $527.70 | Add to Order |
| KM-17370 | 6.063 | 4.562 | 3 Feet | $533.79 | Add to Order |
| KM-17369 | 6.125 | 4.625 | 3 Feet | $540.00 | Add to Order |
| KM-17234 | 6.187 | 4.687 | 3 Feet | $546.12 | Add to Order |
| KM-17410 | 6.250 | 4.750 | 3 Feet | $552.33 | Add to Order |
| KM-17257 | 6.312 | 4.812 | 3 Feet | $558.45 | Add to Order |
| KM-17142 | 6.375 | 4.875 | 3 Feet | $588.24 | Add to Order |
| KM-17141 | 6.437 | 4.937 | 3 Feet | $594.60 | Add to Order |
| KM-2126 | 6.500 | 5.000 | 3 Feet | $601.08 | Add to Order |
| KM-17139 | 6.562 | 5.062 | 3 Feet | $607.44 | Add to Order |
| KM-17138 | 6.625 | 5.125 | 3 Feet | $613.89 | Add to Order |
| KM-17137 | 6.688 | 5.187 | 3 Feet | $620.28 | Add to Order |
| KM-17136 | 6.750 | 5.250 | 3 Feet | $626.73 | Add to Order |
| KM-17135 | 6.812 | 5.313 | 3 Feet | $633.09 | Add to Order |
| KM-17134 | 6.875 | 5.375 | 3 Feet | $639.57 | Add to Order |
| KM-17122 | 6.938 | 5.437 | 3 Feet | $645.93 | Add to Order |
| KM-2132 | 7.000 | 5.500 | 3 Feet | $652.41 | Add to Order |
| KM-17143 | 7.062 | 5.562 | 3 Feet | $658.77 | Add to Order |
| KM-17130 | 7.125 | 5.625 | 3 Feet | $665.22 | Add to Order |
| KM-17129 | 7.187 | 5.687 | 3 Feet | $671.61 | Add to Order |
| KM-17128 | 7.250 | 5.750 | 3 Feet | $678.06 | Add to Order |
| KM-17127 | 7.312 | 5.812 | 3 Feet | $684.42 | Add to Order |
| KM-17126 | 7.375 | 5.875 | 3 Feet | $690.90 | Add to Order |
| KM-17125 | 7.437 | 5.937 | 3 Feet | $697.26 | Add to Order |
| KM-2138 | 7.500 | 6.000 | 3 Feet | $703.74 | Add to Order |
| KM-17123 | 7.562 | 6.062 | 3 Feet | $686.79 | Add to Order |
| KM-17154 | 7.625 | 6.125 | 3 Feet | $693.15 | Add to Order |
| KM-17156 | 7.688 | 6.187 | 3 Feet | $699.42 | Add to Order |
| KM-17133 | 7.750 | 6.250 | 3 Feet | $705.75 | Add to Order |
| KM-17164 | 7.812 | 6.312 | 3 Feet | $712.02 | Add to Order |
| KM-17163 | 7.875 | 6.375 | 3 Feet | $718.35 | Add to Order |
| KM-17162 | 7.938 | 6.437 | 3 Feet | $724.62 | Add to Order |
| KM-17161 | 8.000 | 6.500 | 3 Feet | $730.95 | Add to Order |
| KM-17160 | 8.062 | 6.562 | 3 Feet | $737.22 | Add to Order |
| KM-17159 | 8.125 | 6.625 | 3 Feet | $743.58 | Add to Order |
| KM-17158 | 8.188 | 6.687 | 3 Feet | $749.82 | Add to Order |
| KM-17157 | 8.250 | 6.750 | 3 Feet | $756.18 | Add to Order |
| KM-17144 | 8.312 | 6.812 | 3 Feet | $762.42 | Add to Order |
| KM-17155 | 8.375 | 6.875 | 3 Feet | $768.78 | Add to Order |
| KM-17166 | 8.437 | 6.938 | 3 Feet | $775.02 | Add to Order |
| KM-17153 | 8.500 | 7.000 | 3 Feet | $781.38 | Add to Order |
| KM-17152 | 8.562 | 7.062 | 3 Feet | $787.62 | Add to Order |
| KM-17151 | 8.625 | 7.125 | 3 Feet | $793.98 | Add to Order |
| KM-17150 | 8.688 | 7.187 | 3 Feet | $800.22 | Add to Order |
| KM-17149 | 8.750 | 7.250 | 3 Feet | $806.58 | Add to Order |
| KM-17148 | 8.812 | 7.312 | 3 Feet | $812.82 | Add to Order |
| KM-17147 | 8.875 | 7.375 | 3 Feet | $819.18 | Add to Order |
| KM-17146 | 8.938 | 7.437 | 3 Feet | $825.42 | Add to Order |
| KM-17111 | 9.000 | 7.500 | 3 Feet | $831.78 | Add to Order |
| KM-17165 | 9.062 | 7.562 | 3 Feet | $838.05 | Add to Order |
| KM-17131 | 9.125 | 7.625 | 3 Feet | $844.38 | Add to Order |
| KM-17098 | 9.188 | 7.687 | 3 Feet | $850.65 | Add to Order |
| KM-17097 | 9.250 | 7.750 | 3 Feet | $856.98 | Add to Order |
| KM-17096 | 9.312 | 7.812 | 3 Feet | $863.25 | Add to Order |
| KM-17095 | 9.375 | 7.875 | 3 Feet | $869.58 | Add to Order |
| KM-17094 | 9.437 | 7.937 | 3 Feet | $875.85 | Add to Order |
| KM-17093 | 9.500 | 8.000 | 3 Feet | $882.21 | Add to Order |
| KM-17091 | 9.625 | 8.125 | 3 Feet | $894.81 | Add to Order |
| KM-17090 | 9.688 | 8.187 | 3 Feet | $901.05 | Add to Order |
| KM-17078 | 9.750 | 8.250 | 3 Feet | $907.41 | Add to Order |
| KM-17088 | 9.812 | 8.312 | 3 Feet | $913.65 | Add to Order |
| KM-17099 | 9.875 | 8.375 | 3 Feet | $920.01 | Add to Order |
| KM-17086 | 9.937 | 8.437 | 3 Feet | $926.25 | Add to Order |
| KM-17085 | 10.00 | 8.500 | 3 Feet | $932.61 | Add to Order |
| KM-17084 | 10.062 | 8.562 | 3 Feet | $938.85 | Add to Order |
| KM-17083 | 10.125 | 8.625 | 3 Feet | $945.21 | Add to Order |
| KM-17082 | 10.187 | 8.687 | 3 Feet | $951.45 | Add to Order |
| KM-17081 | 10.250 | 8.75 | 3 Feet | $957.81 | Add to Order |
| KM-17080 | 10.313 | 8.812 | 3 Feet | $964.08 | Add to Order |
| KM-17109 | 10.375 | 8.875 | 3 Feet | $970.41 | Add to Order |
| KM-17087 | 10.437 | 8.937 | 3 Feet | $976.68 | Add to Order |
| KM-17089 | 10.500 | 9.000 | 3 Feet | $983.01 | Add to Order |
| KM-16210 | 10.563 | 9.062 | 3 Feet | $989.28 | Add to Order |
| KM-17120 | 10.625 | 9.125 | 3 Feet | $995.61 | Add to Order |
| KM-17119 | 10.688 | 9.187 | 3 Feet | $1,001.88 | Add to Order |
| KM-17118 | 10.750 | 9.250 | 3 Feet | $1,008.24 | Add to Order |
| KM-17117 | 10.813 | 9.312 | 3 Feet | $1,014.48 | Add to Order |
| KM-17116 | 10.875 | 9.375 | 3 Feet | $1,020.84 | Add to Order |
| KM-17115 | 10.937 | 9.437 | 3 Feet | $1,027.08 | Add to Order |
| KM-17114 | 11.000 | 9.500 | 3 Feet | $1,033.44 | Add to Order |
| KM-17113 | 11.062 | 9.562 | 3 Feet | $1,039.68 | Add to Order |
| KM-17112 | 11.125 | 9.625 | 3 Feet | $1,046.04 | Add to Order |
| KM-17100 | 11.188 | 9.687 | 3 Feet | $1,052.28 | Add to Order |
| KM-17110 | 11.250 | 9.750 | 3 Feet | $1,058.64 | Add to Order |
| KM-17121 | 11.313 | 9.813 | 3 Feet | $1,064.88 | Add to Order |
| KM-17108 | 11.375 | 9.875 | 3 Feet | $1,071.24 | Add to Order |
| KM-17107 | 11.437 | 9.937 | 3 Feet | $1,077.48 | Add to Order |
| KM-17106 | 11.500 | 10.000 | 3 Feet | $1,083.84 | Add to Order |
| KM-17105 | 11.562 | 10.062 | 3 Feet | $1,090.08 | Add to Order |
| KM-17104 | 11.625 | 10.125 | 3 Feet | $1,096.44 | Add to Order |
| KM-17103 | 11.687 | 10.187 | 3 Feet | $1,102.71 | Add to Order |
| KM-17102 | 11.750 | 10.250 | 3 Feet | $1,109.04 | Add to Order |
| KM-17941 | 11.812 | 10.312 | 3 Feet | $1,115.31 | Add to Order |
| KM-17942 | 11.875 | 10.375 | 3 Feet | $1,121.64 | Add to Order |
| KM-17943 | 11.937 | 10.437 | 3 Feet | $1,127.91 | Add to Order |
| KM-17944 | 12.000 | 10.500 | 3 Feet | $1,134.24 | Add to Order |
| KM-17913 | 12.062 | 10.562 | 3 Feet | $1,140.51 | Add to Order |
| KM-17911 | 12.125 | 10.625 | 3 Feet | $1,146.87 | Add to Order |
| KM-17933 | 12.187 | 10.687 | 3 Feet | $1,153.11 | Add to Order |
| KM-17904 | 12.250 | 10.750 | 3 Feet | $1,159.47 | Add to Order |
| KM-17905 | 12.313 | 10.812 | 3 Feet | $1,165.71 | Add to Order |
| KM-17906 | 12.375 | 10.875 | 3 Feet | $1,172.07 | Add to Order |
| KM-17907 | 12.437 | 10.937 | 3 Feet | $1,178.31 | Add to Order |
| KM-17908 | 12.500 | 11.000 | 3 Feet | $1,184.67 | Add to Order |
| KM-17909 | 12.562 | 11.062 | 3 Feet | $1,190.91 | Add to Order |
| KM-17910 | 12.625 | 11.125 | 3 Feet | $1,197.27 | Add to Order |
| KM-17923 | 12.687 | 11.187 | 3 Feet | $1,203.51 | Add to Order |
| KM-17912 | 12.750 | 11.250 | 3 Feet | $1,209.87 | Add to Order |
| KM-17902 | 12.812 | 11.312 | 3 Feet | $1,216.11 | Add to Order |
| KM-17914 | 12.875 | 11.375 | 3 Feet | $1,222.47 | Add to Order |
| KM-17168 | 12.937 | 11.437 | 3 Feet | $1,228.71 | Add to Order |
| KM-17079 | 13.000 | 11.500 | 3 Feet | $1,235.07 | Add to Order |
| KM-17145 | 13.062 | 11.562 | 3 Feet | $1,241.34 | Add to Order |
| KM-17231 | 13.125 | 11.625 | 3 Feet | $1,247.67 | Add to Order |
| KM-17230 | 13.187 | 11.687 | 3 Feet | $1,253.94 | Add to Order |
| KM-17229 | 13.250 | 11.750 | 3 Feet | $1,260.27 | Add to Order |
| KM-17228 | 13.312 | 11.812 | 3 Feet | $1,266.54 | Add to Order |
| KM-17227 | 13.375 | 11.875 | 3 Feet | $1,272.90 | Add to Order |
| KM-17226 | 13.437 | 11.937 | 3 Feet | $1,279.14 | Add to Order |
| KM-17225 | 13.500 | 12.000 | 3 Feet | $1,285.50 | Add to Order |
| KM-17224 | 13.562 | 12.062 | 3 Feet | $1,291.74 | Add to Order |
| KM-17223 | 13.625 | 12.125 | 3 Feet | $1,298.10 | Add to Order |
| KM-17211 | 13.687 | 12.187 | 3 Feet | $1,304.34 | Add to Order |
| KM-17221 | 13.750 | 12.250 | 3 Feet | $1,310.70 | Add to Order |
| KM-17232 | 13.812 | 12.312 | 3 Feet | $1,316.94 | Add to Order |
| KM-17219 | 13.875 | 12.375 | 3 Feet | $1,323.30 | Add to Order |
| KM-17218 | 13.937 | 12.437 | 3 Feet | $1,329.54 | Add to Order |
| KM-17217 | 14.000 | 12.500 | 3 Feet | $1,335.90 | Add to Order |
| KM-17216 | 14.062 | 12.562 | 3 Feet | $1,342.14 | Add to Order |
| KM-17215 | 14.125 | 12.625 | 3 Feet | $1,348.50 | Add to Order |
| KM-17214 | 14.187 | 12.687 | 3 Feet | $1,354.74 | Add to Order |
| KM-17213 | 14.250 | 12.750 | 3 Feet | $1,361.10 | Add to Order |
| KM-17212 | 14.312 | 12.813 | 3 Feet | $1,367.37 | Add to Order |
| KM-17243 | 14.375 | 12.875 | 3 Feet | $1,373.70 | Add to Order |
| KM-17245 | 14.437 | 12.937 | 3 Feet | $1,379.97 | Add to Order |
| KM-17222 | 14.500 | 13.000 | 3 Feet | $1,386.30 | Add to Order |
| KM-17253 | 14.562 | 13.062 | 3 Feet | $1,392.57 | Add to Order |
| KM-17252 | 14.625 | 13.125 | 3 Feet | $1,398.90 | Add to Order |
| KM-17251 | 14.687 | 13.187 | 3 Feet | $1,405.17 | Add to Order |
| KM-17250 | 14.750 | 13.250 | 3 Feet | $1,411.53 | Add to Order |
| KM-17249 | 14.812 | 13.312 | 3 Feet | $1,417.77 | Add to Order |
| KM-17248 | 14.875 | 13.375 | 3 Feet | $1,424.13 | Add to Order |
| KM-17247 | 14.937 | 13.437 | 3 Feet | $1,430.37 | Add to Order |
| KM-17246 | 15.000 | 13.500 | 3 Feet | $1,436.73 | Add to Order |
| KM-17233 | 15.062 | 13.562 | 3 Feet | $1,442.97 | Add to Order |
| KM-17244 | 15.125 | 13.625 | 3 Feet | $1,449.33 | Add to Order |
| KM-17255 | 15.187 | 13.687 | 3 Feet | $1,455.57 | Add to Order |
| KM-17242 | 15.250 | 13.750 | 3 Feet | $1,461.93 | Add to Order |
| KM-17241 | 15.312 | 13.812 | 3 Feet | $1,468.17 | Add to Order |
| KM-17240 | 15.375 | 13.875 | 3 Feet | $1,474.53 | Add to Order |
| KM-17239 | 15.437 | 13.937 | 3 Feet | $1,480.77 | Add to Order |
| KM-17238 | 15.500 | 14.000 | 3 Feet | $1,487.13 | Add to Order |
| KM-17237 | 15.562 | 14.062 | 3 Feet | $1,493.37 | Add to Order |
| KM-17236 | 15.625 | 14.125 | 3 Feet | $1,499.73 | Add to Order |
| KM-17235 | 15.687 | 14.187 | 3 Feet | $1,506.00 | Add to Order |
| KM-17200 | 15.750 | 14.250 | 3 Feet | $1,512.33 | Add to Order |
| KM-17254 | 15.812 | 14.312 | 3 Feet | $1,518.60 | Add to Order |
| KM-17220 | 15.875 | 14.375 | 3 Feet | $1,524.93 | Add to Order |
| KM-17187 | 15.937 | 14.437 | 3 Feet | $1,531.20 | Add to Order |
| KM-17186 | 16.000 | 14.500 | 3 Feet | $1,537.53 | Add to Order |
| KM-17185 | 16.062 | 14.562 | 3 Feet | $1,543.80 | Add to Order |
| KM-17184 | 16.125 | 14.625 | 3 Feet | $1,550.16 | Add to Order |
| KM-17183 | 16.187 | 14.687 | 3 Feet | $1,556.40 | Add to Order |
| KM-17182 | 16.250 | 14.750 | 3 Feet | $1,562.76 | Add to Order |
| KM-17181 | 16.312 | 14.812 | 3 Feet | $1,569.00 | Add to Order |
| KM-17180 | 16.375 | 14.875 | 3 Feet | $1,575.36 | Add to Order |
| KM-17179 | 16.437 | 14.937 | 3 Feet | $1,581.60 | Add to Order |
| KM-17167 | 16.500 | 15.000 | 3 Feet | $1,587.96 | Add to Order |
| KM-17177 | 16.562 | 15.062 | 3 Feet | $1,594.20 | Add to Order |
| KM-17188 | 16.625 | 15.125 | 3 Feet | $1,600.56 | Add to Order |
| KM-17175 | 16.687 | 15.187 | 3 Feet | $1,606.80 | Add to Order |
| KM-17174 | 16.750 | 15.250 | 3 Feet | $1,613.16 | Add to Order |
| KM-17173 | 16.812 | 15.312 | 3 Feet | $1,619.40 | Add to Order |
| KM-17172 | 16.875 | 15.375 | 3 Feet | $1,625.76 | Add to Order |
| KM-17171 | 16.937 | 15.437 | 3 Feet | $1,632.03 | Add to Order |
| KM-17170 | 17.000 | 15.500 | 3 Feet | $1,638.36 | Add to Order |
| KM-17169 | 17.062 | 15.562 | 3 Feet | $1,644.63 | Add to Order |
| KM-17198 | 17.125 | 15.625 | 3 Feet | $1,650.96 | Add to Order |
| KM-17176 | 17.187 | 15.687 | 3 Feet | $1,657.23 | Add to Order |
| KM-17178 | 17.250 | 15.750 | 3 Feet | $1,663.56 | Add to Order |
| KM-17209 | 17.312 | 15.812 | 3 Feet | $1,669.83 | Add to Order |
| KM-17208 | 17.375 | 15.875 | 3 Feet | $1,676.19 | Add to Order |
| KM-17207 | 17.437 | 15.937 | 3 Feet | $1,682.43 | Add to Order |
| KM-17206 | 17.500 | 16.000 | 3 Feet | $1,688.79 | Add to Order |
| KM-17205 | 17.562 | 16.062 | 3 Feet | $1,695.03 | Add to Order |
| KM-17204 | 17.625 | 16.125 | 3 Feet | $1,701.39 | Add to Order |
| KM-17203 | 17.687 | 16.187 | 3 Feet | $1,707.63 | Add to Order |
| KM-17202 | 17.750 | 16.250 | 3 Feet | $1,713.99 | Add to Order |
| KM-17201 | 17.812 | 16.312 | 3 Feet | $1,720.23 | Add to Order |
| KM-17189 | 17.875 | 16.375 | 3 Feet | $1,726.59 | Add to Order |
| KM-17199 | 17.937 | 16.437 | 3 Feet | $1,732.83 | Add to Order |
| KM-17210 | 18.000 | 16.500 | 3 Feet | $1,739.19 | Add to Order |
| KM-17197 | 18.062 | 16.562 | 3 Feet | $1,745.43 | Add to Order |
| KM-17196 | 18.125 | 16.625 | 3 Feet | $1,751.79 | Add to Order |
| KM-17195 | 18.187 | 16.687 | 3 Feet | $1,758.03 | Add to Order |
| KM-17194 | 18.250 | 16.750 | 3 Feet | $1,764.39 | Add to Order |
| KM-17193 | 18.312 | 16.812 | 3 Feet | $1,770.66 | Add to Order |
| KM-17192 | 18.375 | 16.875 | 3 Feet | $1,776.99 | Add to Order |
| KM-17191 | 18.437 | 16.937 | 3 Feet | $1,783.26 | Add to Order |
| KM-17190 | 18.500 | 17.000 | 3 Feet | $1,789.59 | Add to Order |
| KM-16654 | 18.562 | 17.062 | 3 Feet | $1,795.86 | Add to Order |
| KM-16089 | 18.625 | 17.125 | 3 Feet | $1,802.19 | Add to Order |
| KM-16833 | 18.687 | 17.187 | 3 Feet | $1,808.46 | Add to Order |
| KM-16218 | 18.750 | 17.250 | 3 Feet | $1,814.82 | Add to Order |
| KM-16217 | 18.812 | 17.312 | 3 Feet | $1,821.06 | Add to Order |
| KM-16216 | 18.875 | 17.375 | 3 Feet | $1,827.42 | Add to Order |
| KM-16215 | 18.937 | 17.437 | 3 Feet | $1,833.66 | Add to Order |
| KM-16214 | 19.000 | 17.500 | 3 Feet | $1,840.02 | Add to Order |
| KM-16213 | 19.062 | 17.562 | 3 Feet | $1,846.26 | Add to Order |
| KM-16212 | 19.125 | 17.625 | 3 Feet | $1,852.62 | Add to Order |
| KM-16211 | 19.187 | 17.687 | 3 Feet | $1,858.86 | Add to Order |
| KM-16199 | 19.250 | 17.750 | 3 Feet | $1,865.22 | Add to Order |
| KM-16209 | 19.312 | 17.812 | 3 Feet | $1,871.46 | Add to Order |
| KM-16220 | 19.375 | 17.875 | 3 Feet | $1,877.82 | Add to Order |
| KM-16207 | 19.437 | 17.937 | 3 Feet | $1,884.06 | Add to Order |
| KM-16206 | 19.500 | 18.000 | 3 Feet | $1,890.42 | Add to Order |
| KM-16205 | 19.562 | 18.062 | 3 Feet | $1,896.66 | Add to Order |
| KM-16204 | 19.625 | 18.125 | 3 Feet | $1,903.02 | Add to Order |
| KM-16203 | 19.687 | 18.187 | 3 Feet | $1,909.29 | Add to Order |
| KM-16202 | 19.750 | 18.250 | 3 Feet | $1,915.62 | Add to Order |
| KM-16201 | 19.812 | 18.312 | 3 Feet | $1,921.89 | Add to Order |
| KM-16200 | 19.875 | 18.375 | 3 Feet | $1,928.22 | Add to Order |
| KM-16231 | 19.937 | 18.437 | 3 Feet | $1,934.49 | Add to Order |
| KM-16233 | 20.000 | 18.500 | 3 Feet | $1,940.82 | Add to Order |
| Rev. 09-26, 08-22, 04-22, 02-22 | |||||
| Phenolic Tube Tolerances | ||||
| ↓ Inside Diameter ↓ | ||||
| Outside Diameter | Turned OD Tolerance |
Steel Mandrel |
Built-up Mandrel |
|
| 0.125" to 0.749" | ±.005" | ±.003" | - | |
| 0.750" to 1.999" | ±.005" | ±.004" | - | |
| 2.000" to 4.000" | ±.008" | ±.006" | - | |
| 4.001" - 12.000" | ±.025" ** | ±.010" | - | |
| 12.001" - 18.000" | ±.030" ** | ±.030" | ±.060" | |
| 18.001" - 24.000" | ±.035" ** | ±.040" | ±.075" | |
| 24.001" - 48.000" | ±.040" ** | ±.060" | ±.090" | |
|
** Tubes over 8.000" OD are supplied as wound, which
** Tubes turned to the following OD tolerance
|
||||
