NEMA Canvas C/CE Fabric Reinforced Phenolic Tubes
Canvas NEMA C/CE Fabric Reinforced Phenolic
- natural (light tan to brown)
Nema CE Tubes Technical Data Sheet
This grade is composed of a continuous cotton woven cloth
impregnated with a phenolic resin binder. This grade contains a medium weave
canvas and is known primarily for it's mechanical properties. This grade is not
recommended for primary insulation.
NEMA grades C, and CE Canvas Cotton-Cloth Reinforced Phenolic -- natural color is typically light tan to brown. C and CE grades are composed of a continuous cotton woven cloth impregnated with a phenolic resin binder. These grades contain a medium weave canvas and are known primarily for their mechanical properties. These grades are not recommended for primary electrical insulation.
(NEMA C certifies to Mil-I-24768/16 FBM, IEC 60893-3 Type 4, PF CC 201)
(NEMA CE certifies to Mil-I-24768/14 FBG, IEC 60893-3 Type 4, PF CC 203)
NEMA Chemical Resistance Chart
NEMA/CE Tubes NEMA C/CE Sheets NEMA C/CE Bar Stock
Tubes are made in random lengths between 30" - 36".
Our pricing and minimums are based on the 36".
Tubes can also be made in 42" to 48" random lengths for the same pricing.
Measured lengths of 36"±1" and 48"±1" are also available via manual quote.
| .375" Wall Thickness - C/CE Tubes | |||||
| Part # | OD (in.) | ID (in.) | Minimum | Price Per Foot | Order Online |
|---|---|---|---|---|---|
| KM-16154 | 1.250 | .500 | 24 Feet | $55.47 | Add to Order |
| KM-16141 | 1.312 | .562 | 21 Feet | $58.80 | Add to Order |
| KM-16140 | 1.375 | .625 | 21 Feet | $62.10 | Add to Order |
| KM-16139 | 1.437 | .687 | 21 Feet | $65.43 | Add to Order |
| KM-16138 | 1.500 | .750 | 18 Feet | $68.73 | Add to Order |
| KM-16137 | 1.562 | .812 | 18 Feet | $72.03 | Add to Order |
| KM-16136 | 1.625 | .875 | 18 Feet | $75.36 | Add to Order |
| KM-16135 | 1.688 | .937 | 18 Feet | $78.66 | Add to Order |
| KM-16134 | 1.750 | 1.000 | 18 Feet | $76.11 | Add to Order |
| KM-16099 | 1.812 | 1.062 | 18 Feet | $79.17 | Add to Order |
| KM-16153 | 1.875 | 1.125 | 15 Feet | $82.26 | Add to Order |
| KM-16119 | 1.937 | 1.187 | 15 Feet | $85.32 | Add to Order |
| KM-2061 | 2.000 | 1.250 | 15 Feet | $88.41 | Add to Order |
| KM-16085 | 2.062 | 1.312 | 15 Feet | $91.47 | Add to Order |
| KM-16084 | 2.125 | 1.375 | 15 Feet | $94.56 | Add to Order |
| KM-16083 | 2.188 | 1.437 | 15 Feet | $97.62 | Add to Order |
| KM-2065 | 2.250 | 1.500 | 12 Feet | $100.71 | Add to Order |
| KM-16081 | 2.312 | 1.562 | 12 Feet | $103.77 | Add to Order |
| KM-16080 | 2.375 | 1.625 | 12 Feet | $106.86 | Add to Order |
| KM-16079 | 2.437 | 1.687 | 12 Feet | $109.92 | Add to Order |
| KM-2070 | 2.500 | 1.750 | 12 Feet | $113.01 | Add to Order |
| KM-16066 | 2.562 | 1.812 | 12 Feet | $116.07 | Add to Order |
| KM-16076 | 2.625 | 1.875 | 12 Feet | $119.16 | Add to Order |
| KM-16087 | 2.688 | 1.937 | 12 Feet | $122.22 | Add to Order |
| KM-2075 | 2.750 | 2.000 | 12 Feet | $125.31 | Add to Order |
| KM-16073 | 2.812 | 2.062 | 12 Feet | $128.37 | Add to Order |
| KM-16072 | 2.875 | 2.125 | 12 Feet | $131.46 | Add to Order |
| KM-16071 | 2.937 | 2.187 | 9 Feet | $134.52 | Add to Order |
| KM-2080 | 3.000 | 2.250 | 9 Feet | $140.28 | Add to Order |
| KM-16069 | 3.062 | 2.312 | 9 Feet | $143.37 | Add to Order |
| KM-16068 | 3.125 | 2.375 | 9 Feet | $146.55 | Add to Order |
| KM-16097 | 3.188 | 2.437 | 9 Feet | $149.64 | Add to Order |
| KM-2085 | 3.250 | 2.500 | 9 Feet | $152.82 | Add to Order |
| KM-16077 | 3.312 | 2.562 | 9 Feet | $155.91 | Add to Order |
| KM-16108 | 3.375 | 2.625 | 9 Feet | $159.09 | Add to Order |
| KM-16107 | 3.437 | 2.687 | 9 Feet | $162.18 | Add to Order |
| KM-2090 | 3.500 | 2.750 | 9 Feet | $165.36 | Add to Order |
| KM-16105 | 3.562 | 2.812 | 9 Feet | $168.45 | Add to Order |
| KM-16104 | 3.625 | 2.875 | 9 Feet | $171.63 | Add to Order |
| KM-16103 | 3.687 | 2.937 | 9 Feet | $174.72 | Add to Order |
| KM-2095 | 3.750 | 3.000 | 9 Feet | $177.87 | Add to Order |
| KM-16101 | 3.812 | 3.062 | 9 Feet | $180.99 | Add to Order |
| KM-16100 | 3.875 | 3.125 | 9 Feet | $184.14 | Add to Order |
| KM-16088 | 3.937 | 3.187 | 9 Feet | $187.26 | Add to Order |
| KM-2100 | 4.000 | 3.250 | 9 Feet | $190.41 | Add to Order |
| KM-16109 | 4.062 | 3.312 | 9 Feet | $193.53 | Add to Order |
| KM-16096 | 4.125 | 3.375 | 9 Feet | $196.68 | Add to Order |
| KM-16095 | 4.187 | 3.437 | 9 Feet | $199.80 | Add to Order |
| KM-2105 | 4.250 | 3.500 | 6 Feet | $202.95 | Add to Order |
| KM-16093 | 4.312 | 3.562 | 6 Feet | $206.07 | Add to Order |
| KM-16092 | 4.375 | 3.625 | 6 Feet | $209.22 | Add to Order |
| KM-16091 | 4.437 | 3.687 | 6 Feet | $212.34 | Add to Order |
| KM-2110 | 4.500 | 3.750 | 6 Feet | $215.49 | Add to Order |
| KM-16357 | 4.562 | 3.812 | 6 Feet | $218.61 | Add to Order |
| KM-16000 | 4.625 | 3.875 | 6 Feet | $221.76 | Add to Order |
| KM-16267 | 4.687 | 3.937 | 6 Feet | $224.88 | Add to Order |
| KM-16606 | 4.750 | 4.000 | 6 Feet | $228.03 | Add to Order |
| KM-16605 | 4.812 | 4.062 | 6 Feet | $231.15 | Add to Order |
| KM-16604 | 4.875 | 4.125 | 6 Feet | $234.30 | Add to Order |
| KM-16603 | 4.937 | 4.187 | 6 Feet | $237.42 | Add to Order |
| KM-16602 | 5.000 | 4.250 | 6 Feet | $240.57 | Add to Order |
| KM-16601 | 5.062 | 4.312 | 6 Feet | $243.69 | Add to Order |
| KM-16600 | 5.125 | 4.375 | 6 Feet | $246.84 | Add to Order |
| KM-16599 | 5.187 | 4.438 | 6 Feet | $249.96 | Add to Order |
| KM-16598 | 5.250 | 4.500 | 6 Feet | $253.11 | Add to Order |
| KM-16586 | 5.312 | 4.562 | 6 Feet | $256.23 | Add to Order |
| KM-16596 | 5.375 | 4.625 | 6 Feet | $259.38 | Add to Order |
| KM-16607 | 5.437 | 4.687 | 6 Feet | $262.50 | Add to Order |
| KM-16594 | 5.500 | 4.750 | 6 Feet | $265.65 | Add to Order |
| KM-16593 | 5.562 | 4.812 | 6 Feet | $268.77 | Add to Order |
| KM-16592 | 5.625 | 4.875 | 6 Feet | $283.29 | Add to Order |
| KM-16405 | 5.688 | 4.937 | 6 Feet | $286.53 | Add to Order |
| KM-16591 | 5.750 | 5.000 | 6 Feet | $289.80 | Add to Order |
| KM-16590 | 5.812 | 5.062 | 6 Feet | $293.04 | Add to Order |
| KM-16589 | 5.875 | 5.125 | 6 Feet | $296.34 | Add to Order |
| KM-16588 | 5.938 | 5.187 | 6 Feet | $299.58 | Add to Order |
| KM-16587 | 6.000 | 5.250 | 6 Feet | $302.88 | Add to Order |
| KM-16618 | 6.063 | 5.313 | 6 Feet | $306.12 | Add to Order |
| KM-16620 | 6.125 | 5.375 | 6 Feet | $309.39 | Add to Order |
| KM-16597 | 6.187 | 5.437 | 6 Feet | $312.63 | Add to Order |
| KM-16628 | 6.250 | 5.500 | 6 Feet | $315.93 | Add to Order |
| KM-16627 | 6.312 | 5.562 | 6 Feet | $319.17 | Add to Order |
| KM-16626 | 6.375 | 5.625 | 6 Feet | $322.47 | Add to Order |
| KM-16625 | 6.437 | 5.687 | 6 Feet | $325.71 | Add to Order |
| KM-16624 | 6.500 | 5.750 | 6 Feet | $328.98 | Add to Order |
| KM-16623 | 6.562 | 5.812 | 6 Feet | $332.22 | Add to Order |
| KM-16622 | 6.625 | 5.875 | 6 Feet | $335.52 | Add to Order |
| KM-16621 | 6.688 | 5.937 | 6 Feet | $338.76 | Add to Order |
| KM-16608 | 6.750 | 6.000 | 6 Feet | $342.06 | Add to Order |
| KM-16619 | 6.812 | 6.062 | 6 Feet | $324.51 | Add to Order |
| KM-16630 | 6.875 | 6.125 | 6 Feet | $327.66 | Add to Order |
| KM-16617 | 6.938 | 6.187 | 6 Feet | $330.81 | Add to Order |
| KM-16616 | 7.000 | 6.250 | 6 Feet | $333.96 | Add to Order |
| KM-16615 | 7.062 | 6.312 | 6 Feet | $337.11 | Add to Order |
| KM-16614 | 7.125 | 6.375 | 6 Feet | $340.29 | Add to Order |
| KM-16613 | 7.187 | 6.437 | 6 Feet | $343.41 | Add to Order |
| KM-16612 | 7.250 | 6.500 | 6 Feet | $346.59 | Add to Order |
| KM-16611 | 7.312 | 6.562 | 6 Feet | $349.71 | Add to Order |
| KM-16610 | 7.375 | 6.625 | 6 Feet | $352.89 | Add to Order |
| KM-16575 | 7.437 | 6.687 | 6 Feet | $356.01 | Add to Order |
| KM-16629 | 7.500 | 6.750 | 6 Feet | $359.19 | Add to Order |
| KM-16595 | 7.562 | 6.812 | 6 Feet | $362.31 | Add to Order |
| KM-16562 | 7.625 | 6.875 | 6 Feet | $365.49 | Add to Order |
| KM-16561 | 7.688 | 6.938 | 6 Feet | $368.61 | Add to Order |
| KM-16560 | 7.750 | 7.000 | 6 Feet | $371.79 | Add to Order |
| KM-16559 | 7.812 | 7.062 | 6 Feet | $374.91 | Add to Order |
| KM-16558 | 7.875 | 7.125 | 6 Feet | $378.09 | Add to Order |
| KM-16557 | 7.938 | 7.187 | 6 Feet | $381.21 | Add to Order |
| KM-16556 | 8.000 | 7.250 | 6 Feet | $384.39 | Add to Order |
| KM-16555 | 8.062 | 7.312 | 6 Feet | $387.51 | Add to Order |
| KM-16554 | 8.125 | 7.375 | 6 Feet | $390.69 | Add to Order |
| KM-16542 | 8.188 | 7.437 | 6 Feet | $393.81 | Add to Order |
| KM-16552 | 8.250 | 7.500 | 6 Feet | $396.99 | Add to Order |
| KM-16563 | 8.312 | 7.562 | 3 Feet | $400.11 | Add to Order |
| KM-16550 | 8.375 | 7.625 | 3 Feet | $403.29 | Add to Order |
| KM-16549 | 8.437 | 7.687 | 3 Feet | $406.41 | Add to Order |
| KM-16548 | 8.500 | 7.750 | 3 Feet | $409.59 | Add to Order |
| KM-16547 | 8.562 | 7.812 | 3 Feet | $412.71 | Add to Order |
| KM-16546 | 8.625 | 7.875 | 3 Feet | $415.89 | Add to Order |
| KM-16545 | 8.688 | 7.937 | 3 Feet | $419.01 | Add to Order |
| KM-16544 | 8.750 | 8.000 | 3 Feet | $422.19 | Add to Order |
| KM-16551 | 8.875 | 8.125 | 3 Feet | $428.49 | Add to Order |
| KM-16553 | 8.938 | 8.187 | 3 Feet | $431.61 | Add to Order |
| KM-16584 | 9.000 | 8.250 | 3 Feet | $434.79 | Add to Order |
| KM-16583 | 9.062 | 8.312 | 3 Feet | $437.91 | Add to Order |
| KM-16582 | 9.125 | 8.375 | 3 Feet | $441.09 | Add to Order |
| KM-16581 | 9.188 | 8.437 | 3 Feet | $444.21 | Add to Order |
| KM-16580 | 9.250 | 8.500 | 3 Feet | $447.39 | Add to Order |
| KM-16579 | 9.312 | 8.562 | 3 Feet | $450.54 | Add to Order |
| KM-16578 | 9.375 | 8.625 | 3 Feet | $453.69 | Add to Order |
| KM-16577 | 9.437 | 8.687 | 3 Feet | $456.84 | Add to Order |
| KM-16576 | 9.500 | 8.750 | 3 Feet | $459.99 | Add to Order |
| KM-16564 | 9.563 | 8.812 | 3 Feet | $463.14 | Add to Order |
| KM-16574 | 9.625 | 8.875 | 3 Feet | $466.29 | Add to Order |
| KM-16585 | 9.688 | 8.937 | 3 Feet | $469.44 | Add to Order |
| KM-16572 | 9.750 | 9.000 | 3 Feet | $472.62 | Add to Order |
| KM-16571 | 9.812 | 9.062 | 3 Feet | $475.74 | Add to Order |
| KM-16570 | 9.875 | 9.125 | 3 Feet | $478.92 | Add to Order |
| KM-16569 | 9.937 | 9.187 | 3 Feet | $482.04 | Add to Order |
| KM-16568 | 10.000 | 9.250 | 3 Feet | $485.22 | Add to Order |
| KM-16567 | 10.062 | 9.312 | 3 Feet | $488.34 | Add to Order |
| KM-16566 | 10.125 | 9.375 | 3 Feet | $491.52 | Add to Order |
| KM-16565 | 10.187 | 9.437 | 3 Feet | $494.64 | Add to Order |
| KM-16651 | 10.250 | 9.500 | 3 Feet | $497.82 | Add to Order |
| KM-16719 | 10.313 | 9.562 | 3 Feet | $500.94 | Add to Order |
| KM-16609 | 10.375 | 9.625 | 3 Feet | $504.12 | Add to Order |
| KM-16695 | 10.437 | 9.687 | 3 Feet | $507.24 | Add to Order |
| KM-16694 | 10.500 | 9.750 | 3 Feet | $510.42 | Add to Order |
| KM-16693 | 10.563 | 9.813 | 3 Feet | $513.54 | Add to Order |
| KM-16692 | 10.625 | 9.875 | 3 Feet | $516.72 | Add to Order |
| KM-16691 | 10.688 | 9.937 | 3 Feet | $519.84 | Add to Order |
| KM-16690 | 10.750 | 10.000 | 3 Feet | $523.02 | Add to Order |
| KM-16689 | 10.813 | 10.062 | 3 Feet | $526.14 | Add to Order |
| KM-16688 | 10.875 | 10.125 | 3 Feet | $529.32 | Add to Order |
| KM-16676 | 10.937 | 10.187 | 3 Feet | $532.44 | Add to Order |
| KM-16686 | 11.000 | 10.250 | 3 Feet | $535.62 | Add to Order |
| KM-16697 | 11.062 | 10.312 | 3 Feet | $538.74 | Add to Order |
| KM-16684 | 11.125 | 10.375 | 3 Feet | $541.92 | Add to Order |
| KM-16683 | 11.188 | 10.437 | 3 Feet | $545.04 | Add to Order |
| KM-16682 | 11.250 | 10.500 | 3 Feet | $548.22 | Add to Order |
| KM-16681 | 11.313 | 10.562 | 3 Feet | $551.34 | Add to Order |
| KM-16680 | 11.375 | 10.625 | 3 Feet | $554.52 | Add to Order |
| KM-16679 | 11.437 | 10.687 | 3 Feet | $557.64 | Add to Order |
| KM-18162 | 11.500 | 10.750 | 3 Feet | $560.82 | Add to Order |
| KM-18151 | 11.562 | 10.812 | 3 Feet | $563.94 | Add to Order |
| KM-18141 | 11.625 | 10.875 | 3 Feet | $567.12 | Add to Order |
| KM-18153 | 11.687 | 10.937 | 3 Feet | $570.24 | Add to Order |
| KM-18154 | 11.750 | 11.000 | 3 Feet | $573.42 | Add to Order |
| KM-18155 | 11.812 | 11.062 | 3 Feet | $576.54 | Add to Order |
| KM-18156 | 11.875 | 11.125 | 3 Feet | $579.72 | Add to Order |
| KM-18157 | 11.937 | 11.187 | 3 Feet | $582.87 | Add to Order |
| KM-18158 | 12.000 | 11.250 | 3 Feet | $586.02 | Add to Order |
| KM-18159 | 12.062 | 11.312 | 3 Feet | $589.17 | Add to Order |
| KM-18160 | 12.125 | 11.375 | 3 Feet | $592.32 | Add to Order |
| KM-18131 | 12.187 | 11.437 | 3 Feet | $595.47 | Add to Order |
| KM-18152 | 12.250 | 11.500 | 3 Feet | $598.62 | Add to Order |
| KM-18150 | 12.313 | 11.562 | 3 Feet | $601.77 | Add to Order |
| KM-18121 | 12.375 | 11.625 | 3 Feet | $604.95 | Add to Order |
| KM-18122 | 12.437 | 11.687 | 3 Feet | $608.07 | Add to Order |
| KM-18123 | 12.500 | 11.750 | 3 Feet | $611.25 | Add to Order |
| KM-18124 | 12.562 | 11.812 | 3 Feet | $614.37 | Add to Order |
| KM-18125 | 12.625 | 11.875 | 3 Feet | $617.55 | Add to Order |
| KM-18126 | 12.687 | 11.937 | 3 Feet | $620.67 | Add to Order |
| KM-18127 | 12.750 | 12.000 | 3 Feet | $623.85 | Add to Order |
| KM-18128 | 12.812 | 12.062 | 3 Feet | $626.97 | Add to Order |
| KM-18140 | 12.875 | 12.125 | 3 Feet | $630.15 | Add to Order |
| KM-18130 | 12.937 | 12.187 | 3 Feet | $633.27 | Add to Order |
| KM-18120 | 13.000 | 12.250 | 3 Feet | $636.45 | Add to Order |
| KM-18132 | 13.062 | 12.312 | 3 Feet | $639.57 | Add to Order |
| KM-18133 | 13.125 | 12.375 | 3 Feet | $642.75 | Add to Order |
| KM-16678 | 13.187 | 12.437 | 3 Feet | $645.87 | Add to Order |
| KM-16677 | 13.250 | 12.500 | 3 Feet | $649.05 | Add to Order |
| KM-16708 | 13.312 | 12.562 | 3 Feet | $652.17 | Add to Order |
| KM-16710 | 13.375 | 12.625 | 3 Feet | $655.35 | Add to Order |
| KM-16687 | 13.437 | 12.687 | 3 Feet | $658.47 | Add to Order |
| KM-16718 | 13.500 | 12.750 | 3 Feet | $661.65 | Add to Order |
| KM-16717 | 13.562 | 12.813 | 3 Feet | $664.77 | Add to Order |
| KM-16716 | 13.625 | 12.875 | 3 Feet | $667.95 | Add to Order |
| KM-16715 | 13.687 | 12.937 | 3 Feet | $671.07 | Add to Order |
| KM-16714 | 13.750 | 13.000 | 3 Feet | $674.25 | Add to Order |
| KM-16713 | 13.812 | 13.062 | 3 Feet | $677.37 | Add to Order |
| KM-16712 | 13.875 | 13.125 | 3 Feet | $680.55 | Add to Order |
| KM-16711 | 13.937 | 13.187 | 3 Feet | $683.67 | Add to Order |
| KM-16698 | 14.000 | 13.250 | 3 Feet | $686.85 | Add to Order |
| KM-16709 | 14.062 | 13.312 | 3 Feet | $689.97 | Add to Order |
| KM-16720 | 14.125 | 13.375 | 3 Feet | $693.15 | Add to Order |
| KM-16707 | 14.187 | 13.437 | 3 Feet | $696.27 | Add to Order |
| KM-16706 | 14.250 | 13.500 | 3 Feet | $699.45 | Add to Order |
| KM-16705 | 14.312 | 13.562 | 3 Feet | $702.57 | Add to Order |
| KM-16704 | 14.375 | 13.625 | 3 Feet | $705.75 | Add to Order |
| KM-16703 | 14.437 | 13.687 | 3 Feet | $708.87 | Add to Order |
| KM-16702 | 14.500 | 13.750 | 3 Feet | $712.05 | Add to Order |
| KM-16701 | 14.562 | 13.812 | 3 Feet | $715.17 | Add to Order |
| KM-16700 | 14.625 | 13.875 | 3 Feet | $718.35 | Add to Order |
| KM-16699 | 14.687 | 13.937 | 3 Feet | $721.50 | Add to Order |
| KM-16674 | 14.750 | 14.000 | 3 Feet | $724.65 | Add to Order |
| KM-16640 | 14.812 | 14.062 | 3 Feet | $727.80 | Add to Order |
| KM-16685 | 14.875 | 14.125 | 3 Feet | $730.95 | Add to Order |
| KM-16650 | 14.937 | 14.187 | 3 Feet | $734.10 | Add to Order |
| KM-16649 | 15.000 | 14.250 | 3 Feet | $737.28 | Add to Order |
| KM-16648 | 15.062 | 14.312 | 3 Feet | $740.40 | Add to Order |
| KM-16647 | 15.125 | 14.375 | 3 Feet | $743.58 | Add to Order |
| KM-16646 | 15.187 | 14.437 | 3 Feet | $746.70 | Add to Order |
| KM-16645 | 15.250 | 14.500 | 3 Feet | $749.88 | Add to Order |
| KM-16644 | 15.312 | 14.562 | 3 Feet | $753.00 | Add to Order |
| KM-16643 | 15.375 | 14.625 | 3 Feet | $756.18 | Add to Order |
| KM-16631 | 15.437 | 14.687 | 3 Feet | $759.30 | Add to Order |
| KM-16641 | 15.500 | 14.750 | 3 Feet | $762.48 | Add to Order |
| KM-16652 | 15.562 | 14.812 | 3 Feet | $765.60 | Add to Order |
| KM-16639 | 15.625 | 14.875 | 3 Feet | $768.78 | Add to Order |
| KM-16638 | 15.687 | 14.937 | 3 Feet | $771.90 | Add to Order |
| KM-16637 | 15.750 | 15.000 | 3 Feet | $775.08 | Add to Order |
| KM-16636 | 15.812 | 15.062 | 3 Feet | $778.20 | Add to Order |
| KM-16635 | 15.875 | 15.125 | 3 Feet | $781.38 | Add to Order |
| KM-16634 | 15.937 | 15.187 | 3 Feet | $784.50 | Add to Order |
| KM-16633 | 16.000 | 15.250 | 3 Feet | $787.68 | Add to Order |
| KM-16632 | 16.062 | 15.312 | 3 Feet | $790.80 | Add to Order |
| KM-16663 | 16.125 | 15.375 | 3 Feet | $793.98 | Add to Order |
| KM-16665 | 16.187 | 15.437 | 3 Feet | $797.10 | Add to Order |
| KM-16642 | 16.250 | 15.500 | 3 Feet | $800.28 | Add to Order |
| KM-16673 | 16.312 | 15.562 | 3 Feet | $803.40 | Add to Order |
| KM-16672 | 16.375 | 15.625 | 3 Feet | $806.58 | Add to Order |
| KM-16671 | 16.437 | 15.687 | 3 Feet | $809.70 | Add to Order |
| KM-16670 | 16.500 | 15.750 | 3 Feet | $812.88 | Add to Order |
| KM-16669 | 16.562 | 15.812 | 3 Feet | $816.00 | Add to Order |
| KM-16668 | 16.625 | 15.875 | 3 Feet | $819.18 | Add to Order |
| KM-16667 | 16.687 | 15.937 | 3 Feet | $822.30 | Add to Order |
| KM-16666 | 16.750 | 16.000 | 3 Feet | $825.48 | Add to Order |
| KM-16653 | 16.812 | 16.062 | 3 Feet | $828.60 | Add to Order |
| KM-16664 | 16.875 | 16.125 | 3 Feet | $831.78 | Add to Order |
| KM-16675 | 16.937 | 16.187 | 3 Feet | $834.90 | Add to Order |
| KM-16662 | 17.000 | 16.250 | 3 Feet | $838.08 | Add to Order |
| KM-16661 | 17.062 | 16.312 | 3 Feet | $841.20 | Add to Order |
| KM-16660 | 17.125 | 16.375 | 3 Feet | $844.38 | Add to Order |
| KM-16659 | 17.187 | 16.437 | 3 Feet | $847.50 | Add to Order |
| KM-16658 | 17.250 | 16.500 | 3 Feet | $850.68 | Add to Order |
| KM-16657 | 17.312 | 16.562 | 3 Feet | $853.83 | Add to Order |
| KM-16656 | 17.375 | 16.625 | 3 Feet | $856.98 | Add to Order |
| KM-16655 | 17.437 | 16.687 | 3 Feet | $860.13 | Add to Order |
| KM-16520 | 17.500 | 16.750 | 3 Feet | $863.28 | Add to Order |
| KM-16696 | 17.562 | 16.812 | 3 Feet | $866.43 | Add to Order |
| KM-16543 | 17.625 | 16.875 | 3 Feet | $869.58 | Add to Order |
| KM-16398 | 17.687 | 16.937 | 3 Feet | $872.73 | Add to Order |
| KM-16397 | 17.750 | 17.000 | 3 Feet | $875.91 | Add to Order |
| KM-16396 | 17.812 | 17.062 | 3 Feet | $879.03 | Add to Order |
| KM-16395 | 17.875 | 17.125 | 3 Feet | $882.21 | Add to Order |
| KM-16394 | 17.937 | 17.187 | 3 Feet | $885.33 | Add to Order |
| KM-16393 | 18.000 | 17.250 | 3 Feet | $888.51 | Add to Order |
| KM-16392 | 18.062 | 17.312 | 3 Feet | $891.63 | Add to Order |
| KM-16391 | 18.125 | 17.375 | 3 Feet | $894.81 | Add to Order |
| KM-16390 | 18.187 | 17.437 | 3 Feet | $897.93 | Add to Order |
| KM-16378 | 18.250 | 17.500 | 3 Feet | $901.11 | Add to Order |
| KM-16388 | 18.312 | 17.562 | 3 Feet | $904.23 | Add to Order |
| KM-16399 | 18.375 | 17.625 | 3 Feet | $907.41 | Add to Order |
| KM-16386 | 18.437 | 17.687 | 3 Feet | $910.53 | Add to Order |
| KM-16385 | 18.500 | 17.750 | 3 Feet | $913.71 | Add to Order |
| KM-16384 | 18.562 | 17.812 | 3 Feet | $916.83 | Add to Order |
| KM-16383 | 18.625 | 17.875 | 3 Feet | $920.01 | Add to Order |
| KM-16382 | 18.687 | 17.937 | 3 Feet | $923.13 | Add to Order |
| KM-16381 | 18.750 | 18.000 | 3 Feet | $926.31 | Add to Order |
| KM-16380 | 18.812 | 18.062 | 3 Feet | $929.43 | Add to Order |
| KM-16379 | 18.875 | 18.125 | 3 Feet | $932.61 | Add to Order |
| KM-16410 | 18.937 | 18.187 | 3 Feet | $935.73 | Add to Order |
| KM-16412 | 19.000 | 18.250 | 3 Feet | $938.91 | Add to Order |
| KM-16389 | 19.062 | 18.312 | 3 Feet | $942.03 | Add to Order |
| KM-16420 | 19.125 | 18.375 | 3 Feet | $945.21 | Add to Order |
| KM-16419 | 19.187 | 18.437 | 3 Feet | $948.33 | Add to Order |
| KM-16418 | 19.250 | 18.500 | 3 Feet | $951.51 | Add to Order |
| KM-16417 | 19.312 | 18.563 | 3 Feet | $954.63 | Add to Order |
| KM-16416 | 19.375 | 18.625 | 3 Feet | $957.81 | Add to Order |
| KM-16415 | 19.437 | 18.687 | 3 Feet | $960.93 | Add to Order |
| KM-16414 | 19.500 | 18.750 | 3 Feet | $964.11 | Add to Order |
| KM-16413 | 19.562 | 18.812 | 3 Feet | $967.23 | Add to Order |
| KM-16400 | 19.625 | 18.875 | 3 Feet | $970.41 | Add to Order |
| KM-16411 | 19.687 | 18.937 | 3 Feet | $973.53 | Add to Order |
| KM-16422 | 19.750 | 19.000 | 3 Feet | $976.71 | Add to Order |
| KM-16409 | 19.812 | 19.062 | 3 Feet | $979.83 | Add to Order |
| KM-16408 | 19.875 | 19.125 | 3 Feet | $983.01 | Add to Order |
| KM-16407 | 19.937 | 19.187 | 3 Feet | $986.16 | Add to Order |
| KM-16406 | 20.000 | 19.250 | 3 Feet | $989.31 | Add to Order |
| Rev. 09-26, 08-22, 04-22, 03-22 | |||||
| Phenolic Tube Tolerances | ||||
| ↓ Inside Diameter ↓ | ||||
| Outside Diameter | Turned OD Tolerance |
Steel Mandrel |
Built-up Mandrel |
|
| 0.125" to 0.749" | ±.005" | ±.003" | - | |
| 0.750" to 1.999" | ±.005" | ±.004" | - | |
| 2.000" to 4.000" | ±.008" | ±.006" | - | |
| 4.001" - 12.000" | ±.025" ** | ±.010" | - | |
| 12.001" - 18.000" | ±.030" ** | ±.030" | ±.060" | |
| 18.001" - 24.000" | ±.035" ** | ±.040" | ±.075" | |
| 24.001" - 48.000" | ±.040" ** | ±.060" | ±.090" | |
|
** Tubes over 8.000" OD are supplied as wound, which
** Tubes turned to the following OD tolerance
|
||||
