Canvas NEMA C/CE Fabric Reinforced Phenolic Tubes .500 Wall
Canvas C/CE Fabric Reinforced Phenolic -
natural (light tan to brown)
Technical Data Sheet
This grade is composed of a continuous cotton woven cloth
impregnated with a phenolic resin binder. This grade contains a medium weave
canvas and is known primarily for it's mechanical properties. This grade is not
recommended for primary insulation.
NEMA grades C, and CE Canvas Cotton-Cloth Reinforced Phenolic -- natural color is typically light tan to brown. C and CE grades are composed of a continuous cotton woven cloth impregnated with a phenolic resin binder. These grades contain a medium weave canvas and are known primarily for their mechanical properties. These grades are not recommended for primary electrical insulation.
(NEMA C certifies to Mil-I-24768/16 FBM, IEC 60893-3 Type 4, PF CC 201)
(NEMA CE certifies to Mil-I-24768/14 FBG, IEC 60893-3 Type 4, PF CC 203)
C/CE Tubes C/CE Sheets C/CE Bar Stock
Tubes are made in random lengths between 30" - 36".
Our pricing and minimums are based on the 36".
Tubes can also be made in 42" to 48" random lengths for the same pricing.
Measured lengths of 36"±1" and 48"±1" are also available via manual quote.
