Nema Canvas C/CE Fabric Reinforced Phenolic Rods and Sheets
Nema Canvas C/CE Fabric Reinforced Phenolic - natural (light tan to brown)
Canvas Phenolic Technical Data Sheet
This grade is composed of a continuous cotton woven cloth
impregnated with a phenolic resin binder. This grade contains a medium weave
canvas and is known primarily for it's mechanical properties. This grade is not
recommended for primary insulation.
NEMA grades C, and CE Canvas -Cloth Reinforced Phenolic -- natural color is typically light tan to brown. C and CE grades are composed of a continuous cotton woven cloth impregnated with a phenolic resin binder. These grades contain a medium weave canvas and are known primarily for their mechanical properties. These grades are not recommended for primary electrical insulation.
(Grade C certifies to Mil-I-24768/16 FBM, IEC 60893-3 Type 4, PF CC 201)
(Grade CE certifies to Mil-I-24768/14
FBG, IEC 60893-3 Type 4, PF CC 203)
Nema C/CE Cemical Resistance
Chart
Nema C/CE Tubes Nema C/CE Sheets C/CE Bar
| Nema C/CE Canvas Fabric Reinforced Rods | |||
| Part # | Diameter (in.) | Price Per Foot | Order Online |
|---|---|---|---|
| KR-1312B | .125" | $1.91 | Add to Order |
| KR-1312 | .187" | $2.05 | Add to Order |
| KR-1313 | .250" | $2.23 | Add to Order |
| KR-1314 | .312" | $2.54 | Add to Order |
| KR-1315 | .375" | $2.90 | Add to Order |
| KR-1316 | .500" | $3.92 | Add to Order |
| KR-1317 | .562" | $4.55 | Add to Order |
| KR-1318 | .625" | $5.90 | Add to Order |
| KR-1319 | .750" | $6.95 | Add to Order |
| KR-1320 | .875" | $9.00 | Add to Order |
| KR-1321 | 1.000" | $11.32 | Add to Order |
| KR-1322 | 1.125" | $14.11 | Add to Order |
| KR-1323 | 1.250" | $17.15 | Add to Order |
| KR-1324 | 1.375" | $20.23 | Add to Order |
| KR-1325 | 1.500" | $23.60 | Add to Order |
| KR-1326 | 1.625" | $28.80 | Add to Order |
| KR-1327 | 1.750" | $32.76 | Add to Order |
| KR-1328 | 2.000" | $36.63 | Add to Order |
| KR-1329 | 2.250" | $49.98 | Add to Order |
| KR-1330 | 2.500" | $61.67 | Add to Order |
| KR-1331 | 2.750" | $74.63 | Add to Order |
| KR-1332 | 3.000" | $88.83 | Add to Order |
| KR-1333 | 3.250" | $104.33 | Add to Order |
| KR-1334 | 3.500" | $121.07 | Add to Order |
| KR-1335 | 3.750" | $139.08 | Add to Order |
| KR-1336 | 4.000" | $158.36 | Add to Order |
| KR-1337 | 4.500" | $200.72 | Add to Order |
| KR-1338 | 5.000" | $248.13 | Add to Order |
| KR-1339 | 6.000" | $358.16 | Add to Order |
| Tolerances | |||
Under 1.375" Dia. |
±.001" | ||
1.375" Dia. & Over |
±.003" | ||
| Rev. 05-26, 03-25, 06-24, 04-23 | |||
