G11 Glass Reinforced Tubes
- 1.00" Wall Thickness
G11 Glass Reinforced Tubes
(yellow green to amber)
This grade is similar to G10/FR4, with the addition of a higher operating
temperature and some improved mechanical strength at elevated temperatures.
The main difference between NEMA Grades G11 and FR5 is that FR5 is a fire retardant grade of G11. Therefore, FR5 can be safely substituted when G11 is called for, while G11 can never be substituted where FR5 is called for.
(NEMA G-11 certs to MIL-I-24768/3 GEB, IEC 60893-3 Type 2 EP GC 203; FR5 certifies to Mil-I-24768/28 GEB-F.)
G11 Tubes Technical Data Sheet
G11 Tubes Chemical Resistance Chart
Tubes are made in random lengths between 30" - 36".
Our pricing and minimums are based on the 36".
Tubes can also be made in 42" to 48" random lengths for the same pricing.
Measured lengths of 36"±1" and 48"±1" are also available via manual quote.
| 1.00" Wall Thickness G11 FR5 Tubes | |||||
| Part # | OD (in.) | ID (in.) | Price Per Foot | Minimum | Order Online |
|---|---|---|---|---|---|
| KM-8732 | 2.500 | 0.500 | $571.23 | 3 Feet | Add to Order |
| KM-9933 | 2.562 | 0.562 | $593.75 | 3 Feet | Add to Order |
| KM-10125 | 2.625 | 0.625 | $423.15 | 3 Feet | Add to Order |
| KM-10115 | 2.687 | 0.687 | $438.60 | 3 Feet | Add to Order |
| KM-10123 | 2.750 | 0.750 | $454.05 | 3 Feet | Add to Order |
| KM-10131 | 2.812 | 0.812 | $469.50 | 3 Feet | Add to Order |
| KM-10121 | 2.875 | 0.875 | $484.95 | 3 Feet | Add to Order |
| KM-10120 | 2.937 | 0.937 | $500.40 | 3 Feet | Add to Order |
| KM-10119 | 3.000 | 1.000 | $515.85 | 3 Feet | Add to Order |
| KM-10118 | 3.062 | 1.062 | $531.20 | 3 Feet | Add to Order |
| KM-10117 | 3.125 | 1.125 | $546.78 | 3 Feet | Add to Order |
| KM-10116 | 3.187 | 1.187 | $562.10 | 3 Feet | Add to Order |
| KM-10097 | 3.250 | 1.250 | $577.68 | 3 Feet | Add to Order |
| KM-10072 | 3.312 | 1.312 | $593.00 | 3 Feet | Add to Order |
| KM-10105 | 3.375 | 1.375 | $608.58 | 3 Feet | Add to Order |
| KM-10079 | 3.437 | 1.437 | $623.90 | 3 Feet | Add to Order |
| KM-10078 | 3.500 | 1.500 | $639.48 | 3 Feet | Add to Order |
| KM-10077 | 3.562 | 1.562 | $654.80 | 3 Feet | Add to Order |
| KM-10076 | 3.625 | 1.625 | $670.38 | 3 Feet | Add to Order |
| KM-10075 | 3.687 | 1.687 | $685.70 | 3 Feet | Add to Order |
| KM-10066 | 3.750 | 1.750 | $701.28 | 3 Feet | Add to Order |
| KM-10073 | 3.812 | 1.812 | $716.63 | 3 Feet | Add to Order |
| KM-10081 | 3.875 | 1.875 | $732.20 | 3 Feet | Add to Order |
| KM-10071 | 3.937 | 1.937 | $747.53 | 3 Feet | Add to Order |
| KM-10070 | 4.000 | 2.000 | $763.10 | 3 Feet | Add to Order |
| KM-10069 | 4.062 | 2.062 | $778.43 | 3 Feet | Add to Order |
| KM-10068 | 4.125 | 2.125 | $794.00 | 3 Feet | Add to Order |
| KM-10067 | 4.187 | 2.187 | $809.33 | 3 Feet | Add to Order |
| KM-10089 | 4.250 | 2.250 | $824.90 | 3 Feet | Add to Order |
| KM-10091 | 4.312 | 2.312 | $840.22 | 3 Feet | Add to Order |
| KM-10074 | 4.375 | 2.375 | $855.80 | 3 Feet | Add to Order |
| KM-10096 | 4.437 | 2.437 | $871.13 | 3 Feet | Add to Order |
| KM-10095 | 4.500 | 2.500 | $886.70 | 3 Feet | Add to Order |
| KM-10094 | 4.562 | 2.562 | $902.05 | 3 Feet | Add to Order |
| KM-10093 | 4.625 | 2.625 | $917.63 | 3 Feet | Add to Order |
| KM-10092 | 4.687 | 2.687 | $932.95 | 3 Feet | Add to Order |
| KM-10082 | 4.750 | 2.750 | $948.53 | 3 Feet | Add to Order |
| KM-10088 | 4.937 | 2.937 | $994.75 | 3 Feet | Add to Order |
| KM-10090 | 4.812 | 2.812 | $963.85 | 3 Feet | Add to Order |
| KM-10098 | 4.875 | 2.875 | $979.43 | 3 Feet | Add to Order |
| KM-10087 | 5.000 | 3.000 | $1,010.33 | 3 Feet | Add to Order |
| KM-10086 | 5.062 | 3.062 | $1,025.65 | 3 Feet | Add to Order |
| KM-10085 | 5.125 | 3.125 | $1,041.23 | 3 Feet | Add to Order |
| KM-10084 | 5.187 | 3.187 | $1,056.55 | 3 Feet | Add to Order |
| KM-10265 | 5.250 | 3.250 | $1,072.13 | 3 Feet | Add to Order |
| KM-10002 | 5.312 | 3.312 | $1,087.48 | 3 Feet | Add to Order |
| KM-9060 | 5.375 | 3.375 | $1,103.05 | 3 Feet | Add to Order |
| KM-9062 | 5.437 | 3.437 | $1,118.38 | 3 Feet | Add to Order |
| KM-8514 | 5.500 | 3.500 | $1,133.95 | 3 Feet | Add to Order |
| KM-9083 | 5.562 | 3.562 | $1,149.27 | 3 Feet | Add to Order |
| KM-9082 | 5.625 | 3.625 | $1,164.85 | 3 Feet | Add to Order |
| KM-9081 | 5.687 | 3.687 | $1,180.18 | 3 Feet | Add to Order |
| KM-9080 | 5.750 | 3.750 | $1,195.75 | 3 Feet | Add to Order |
| KM-9079 | 5.812 | 3.812 | $1,211.08 | 3 Feet | Add to Order |
| KM-9070 | 5.875 | 3.875 | $1,226.65 | 3 Feet | Add to Order |
| KM-9077 | 5.937 | 3.937 | $1,241.98 | 3 Feet | Add to Order |
| KM-9085 | 6.000 | 4.000 | $1,257.55 | 3 Feet | Add to Order |
| KM-9075 | 6.062 | 4.062 | $1,272.88 | 3 Feet | Add to Order |
| KM-9074 | 6.125 | 4.125 | $1,288.48 | 3 Feet | Add to Order |
| KM-9073 | 6.187 | 4.187 | $1,303.80 | 3 Feet | Add to Order |
| KM-9072 | 6.250 | 4.250 | $1,319.38 | 3 Feet | Add to Order |
| KM-9150 | 6.312 | 4.312 | $1,334.70 | 3 Feet | Add to Order |
| KM-9036 | 6.375 | 4.375 | $1,350.28 | 3 Feet | Add to Order |
| KM-9152 | 6.437 | 4.437 | $1,365.60 | 3 Feet | Add to Order |
| KM-9153 | 6.500 | 4.500 | $1,381.18 | 3 Feet | Add to Order |
| KM-9154 | 6.562 | 4.562 | $1,396.50 | 3 Feet | Add to Order |
| KM-9155 | 6.625 | 4.625 | $1,412.08 | 3 Feet | Add to Order |
| KM-9156 | 6.687 | 4.687 | $1,427.40 | 3 Feet | Add to Order |
| KM-9157 | 6.750 | 4.750 | $1,442.98 | 3 Feet | Add to Order |
| KM-9158 | 6.812 | 4.812 | $1,458.30 | 3 Feet | Add to Order |
| KM-9192 | 6.875 | 4.875 | $1,618.38 | 3 Feet | Add to Order |
| KM-9102 | 6.937 | 4.937 | $1,635.23 | 3 Feet | Add to Order |
| KM-1596 | 7.000 | 5.000 | $1,652.32 | 3 Feet | Add to Order |
| KM-9222 | 7.062 | 5.062 | $1,669.15 | 3 Feet | Add to Order |
| KM-9311 | 7.125 | 5.125 | $1,686.25 | 3 Feet | Add to Order |
| KM-9312 | 7.187 | 5.187 | $1,703.08 | 3 Feet | Add to Order |
| KM-9327 | 7.250 | 5.250 | $1,720.20 | 3 Feet | Add to Order |
| KM-9314 | 7.312 | 5.312 | $1,737.02 | 3 Feet | Add to Order |
| KM-9301 | 7.375 | 5.375 | $1,754.13 | 3 Feet | Add to Order |
| KM-9316 | 7.437 | 5.437 | $1,770.95 | 3 Feet | Add to Order |
| KM-1602 | 7.500 | 5.500 | $1,788.05 | 3 Feet | Add to Order |
| KM-9318 | 7.562 | 5.562 | $1,804.88 | 3 Feet | Add to Order |
| KM-9319 | 7.625 | 5.625 | $1,822.00 | 3 Feet | Add to Order |
| KM-9320 | 7.687 | 5.687 | $1,838.82 | 3 Feet | Add to Order |
| KM-9321 | 7.750 | 5.750 | $1,855.93 | 3 Feet | Add to Order |
| KM-9322 | 7.812 | 5.812 | $1,872.75 | 3 Feet | Add to Order |
| KM-9323 | 7.875 | 5.875 | $1,889.85 | 3 Feet | Add to Order |
| KM-9324 | 7.937 | 5.937 | $1,906.70 | 3 Feet | Add to Order |
| KM-1608 | 8.000 | 6.000 | $1,923.80 | 3 Feet | Add to Order |
| KM-9326 | 8.062 | 6.062 | $1,891.32 | 3 Feet | Add to Order |
| KM-9367 | 8.125 | 6.125 | $1,908.20 | 3 Feet | Add to Order |
| KM-9408 | 8.187 | 6.187 | $1,924.80 | 3 Feet | Add to Order |
| KM-9342 | 8.250 | 6.250 | $1,941.68 | 3 Feet | Add to Order |
| KM-9384 | 8.312 | 6.312 | $1,958.27 | 3 Feet | Add to Order |
| KM-9385 | 8.375 | 6.375 | $1,975.15 | 3 Feet | Add to Order |
| KM-9386 | 8.437 | 6.437 | $1,991.75 | 3 Feet | Add to Order |
| KM-9387 | 8.500 | 6.500 | $2,008.63 | 3 Feet | Add to Order |
| KM-9388 | 8.562 | 6.562 | $2,025.23 | 3 Feet | Add to Order |
| KM-9389 | 8.625 | 6.625 | $2,042.10 | 3 Feet | Add to Order |
| KM-9390 | 8.687 | 6.687 | $2,058.70 | 3 Feet | Add to Order |
| KM-9391 | 8.750 | 6.750 | $2,075.58 | 3 Feet | Add to Order |
| KM-9392 | 8.812 | 6.812 | $2,092.18 | 3 Feet | Add to Order |
| KM-9393 | 8.875 | 6.875 | $2,109.05 | 3 Feet | Add to Order |
| KM-9409 | 8.937 | 6.937 | $2,125.65 | 3 Feet | Add to Order |
| KM-9395 | 9.000 | 7.000 | $2,142.53 | 3 Feet | Add to Order |
| KM-9382 | 9.062 | 7.062 | $2,159.15 | 3 Feet | Add to Order |
| KM-9397 | 9.125 | 7.125 | $2,176.00 | 3 Feet | Add to Order |
| KM-9398 | 9.187 | 7.187 | $2,192.63 | 3 Feet | Add to Order |
| KM-9399 | 9.250 | 7.250 | $2,209.50 | 3 Feet | Add to Order |
| KM-9400 | 9.312 | 7.312 | $2,226.10 | 3 Feet | Add to Order |
| KM-9401 | 9.375 | 7.375 | $2,242.98 | 3 Feet | Add to Order |
| KM-9402 | 9.437 | 7.437 | $2,259.58 | 3 Feet | Add to Order |
| KM-9403 | 9.500 | 7.500 | $2,276.45 | 3 Feet | Add to Order |
| KM-9404 | 9.562 | 7.562 | $2,293.05 | 3 Feet | Add to Order |
| KM-9405 | 9.625 | 7.625 | $2,309.93 | 3 Feet | Add to Order |
| KM-9406 | 9.687 | 7.687 | $2,326.53 | 3 Feet | Add to Order |
| KM-9407 | 9.750 | 7.750 | $2,343.40 | 3 Feet | Add to Order |
| KM-9369 | 9.812 | 7.812 | $2,360.00 | 3 Feet | Add to Order |
| KM-9396 | 9.875 | 7.875 | $2,376.88 | 3 Feet | Add to Order |
| KM-9394 | 9.937 | 7.937 | $2,393.48 | 3 Feet | Add to Order |
| KM-9356 | 10.000 | 8.000 | $2,410.35 | 3 Feet | Add to Order |
| KM-9358 | 10.125 | 8.125 | $2,443.83 | 3 Feet | Add to Order |
| KM-9359 | 10.187 | 8.187 | $2,460.42 | 3 Feet | Add to Order |
| KM-9360 | 10.250 | 8.250 | $2,477.30 | 3 Feet | Add to Order |
| KM-9361 | 10.312 | 8.312 | $2,493.90 | 3 Feet | Add to Order |
| KM-9362 | 10.375 | 8.375 | $2,510.77 | 3 Feet | Add to Order |
| KM-9363 | 10.437 | 8.437 | $2,527.38 | 3 Feet | Add to Order |
| KM-9364 | 10.500 | 8.500 | $2,544.25 | 3 Feet | Add to Order |
| KM-9365 | 10.562 | 8.562 | $2,560.88 | 3 Feet | Add to Order |
| KM-9366 | 10.625 | 8.625 | $2,577.73 | 3 Feet | Add to Order |
| KM-9381 | 10.687 | 8.687 | $2,594.35 | 3 Feet | Add to Order |
| KM-9368 | 10.750 | 8.750 | $2,611.23 | 3 Feet | Add to Order |
| KM-9355 | 10.812 | 8.812 | $2,627.83 | 3 Feet | Add to Order |
| KM-9370 | 10.875 | 8.875 | $2,644.70 | 3 Feet | Add to Order |
| KM-9371 | 10.937 | 8.937 | $2,661.30 | 3 Feet | Add to Order |
| KM-9372 | 11.000 | 9.000 | $2,678.18 | 3 Feet | Add to Order |
| KM-9373 | 11.062 | 9.062 | $2,694.78 | 3 Feet | Add to Order |
| KM-9374 | 11.125 | 9.125 | $2,711.65 | 3 Feet | Add to Order |
| KM-9375 | 11.187 | 9.187 | $2,728.25 | 3 Feet | Add to Order |
| KM-9376 | 11.250 | 9.250 | $2,745.13 | 3 Feet | Add to Order |
| KM-9377 | 11.312 | 9.312 | $2,761.73 | 3 Feet | Add to Order |
| KM-9378 | 11.375 | 9.375 | $2,778.60 | 3 Feet | Add to Order |
| KM-9379 | 11.437 | 9.437 | $2,795.20 | 3 Feet | Add to Order |
| KM-9690 | 11.500 | 9.500 | $2,812.08 | 3 Feet | Add to Order |
| KM-9302 | 11.562 | 9.562 | $2,828.68 | 3 Feet | Add to Order |
| KM-9490 | 11.625 | 9.625 | $2,845.55 | 3 Feet | Add to Order |
| KM-9693 | 11.687 | 9.687 | $2,862.15 | 3 Feet | Add to Order |
| KM-9694 | 11.750 | 9.750 | $2,879.02 | 3 Feet | Add to Order |
| KM-9695 | 11.812 | 9.812 | $2,895.63 | 3 Feet | Add to Order |
| KM-9696 | 11.875 | 9.875 | $2,912.50 | 3 Feet | Add to Order |
| KM-8890 | 11.937 | 9.937 | $2,929.10 | 3 Feet | Add to Order |
| KM-9711 | 12.000 | 10.000 | $2,945.98 | 3 Feet | Add to Order |
| KM-9699 | 12.062 | 10.062 | $2,962.60 | 3 Feet | Add to Order |
| KM-9688 | 12.125 | 10.125 | $2,979.45 | 3 Feet | Add to Order |
| KM-9701 | 12.187 | 10.187 | $2,996.08 | 3 Feet | Add to Order |
| KM-9702 | 12.250 | 10.250 | $3,012.95 | 3 Feet | Add to Order |
| KM-9703 | 12.312 | 10.312 | $3,029.55 | 3 Feet | Add to Order |
| KM-9704 | 12.375 | 10.375 | $3,046.42 | 3 Feet | Add to Order |
| KM-9705 | 12.437 | 10.437 | $3,063.03 | 3 Feet | Add to Order |
| KM-9706 | 12.500 | 10.500 | $3,079.90 | 3 Feet | Add to Order |
| KM-9707 | 12.562 | 10.562 | $3,096.50 | 3 Feet | Add to Order |
| KM-9708 | 12.625 | 10.625 | $3,113.38 | 3 Feet | Add to Order |
| KM-9709 | 12.687 | 10.687 | $3,129.98 | 3 Feet | Add to Order |
| KM-9710 | 12.750 | 10.750 | $3,146.85 | 3 Feet | Add to Order |
| KM-9676 | 12.812 | 10.812 | $3,163.45 | 3 Feet | Add to Order |
| KM-9674 | 12.875 | 10.875 | $3,180.33 | 3 Feet | Add to Order |
| KM-9698 | 12.937 | 10.937 | $3,196.93 | 3 Feet | Add to Order |
| KM-9666 | 13.000 | 11.000 | $3,213.80 | 3 Feet | Add to Order |
| KM-9667 | 13.062 | 11.062 | $3,230.40 | 3 Feet | Add to Order |
| KM-9668 | 13.125 | 11.125 | $3,247.28 | 3 Feet | Add to Order |
| KM-9669 | 13.187 | 11.187 | $3,263.88 | 3 Feet | Add to Order |
| KM-9670 | 13.250 | 11.250 | $3,280.75 | 3 Feet | Add to Order |
| KM-9671 | 13.312 | 11.312 | $3,297.35 | 3 Feet | Add to Order |
| KM-9672 | 13.375 | 11.375 | $3,314.23 | 3 Feet | Add to Order |
| KM-9673 | 13.437 | 11.437 | $3,330.83 | 3 Feet | Add to Order |
| KM-9687 | 13.500 | 11.500 | $3,347.70 | 3 Feet | Add to Order |
| KM-9675 | 13.562 | 11.562 | $3,364.33 | 3 Feet | Add to Order |
| KM-9664 | 13.625 | 11.625 | $3,381.18 | 3 Feet | Add to Order |
| KM-9677 | 13.687 | 11.687 | $3,397.80 | 3 Feet | Add to Order |
| KM-9678 | 13.750 | 11.750 | $3,414.67 | 3 Feet | Add to Order |
| KM-9679 | 13.812 | 11.812 | $3,431.28 | 3 Feet | Add to Order |
| KM-9680 | 13.875 | 11.875 | $3,448.15 | 3 Feet | Add to Order |
| KM-9681 | 13.937 | 11.937 | $3,464.75 | 3 Feet | Add to Order |
| KM-9682 | 14.000 | 12.000 | $3,481.63 | 3 Feet | Add to Order |
| KM-9683 | 14.062 | 12.062 | $3,498.23 | 3 Feet | Add to Order |
| KM-9684 | 14.125 | 12.125 | $3,515.10 | 3 Feet | Add to Order |
| KM-9685 | 14.187 | 12.187 | $3,531.70 | 3 Feet | Add to Order |
| KM-9593 | 14.250 | 12.250 | $3,548.58 | 3 Feet | Add to Order |
| KM-9700 | 14.312 | 12.312 | $3,565.17 | 3 Feet | Add to Order |
| KM-9638 | 14.375 | 12.375 | $3,582.05 | 3 Feet | Add to Order |
| KM-9545 | 14.437 | 12.437 | $3,598.65 | 3 Feet | Add to Order |
| KM-9546 | 14.500 | 12.500 | $3,615.53 | 3 Feet | Add to Order |
| KM-9547 | 14.562 | 12.562 | $3,632.13 | 3 Feet | Add to Order |
| KM-9548 | 14.625 | 12.625 | $3,649.00 | 3 Feet | Add to Order |
| KM-9549 | 14.687 | 12.687 | $3,665.60 | 3 Feet | Add to Order |
| KM-9550 | 14.750 | 12.750 | $3,682.48 | 3 Feet | Add to Order |
| KM-9551 | 14.812 | 12.812 | $3,699.08 | 3 Feet | Add to Order |
| KM-9552 | 14.875 | 12.875 | $3,715.95 | 3 Feet | Add to Order |
| KM-9553 | 14.937 | 12.937 | $3,732.55 | 3 Feet | Add to Order |
| KM-9567 | 15.000 | 13.000 | $3,749.43 | 3 Feet | Add to Order |
| KM-9555 | 15.062 | 13.062 | $3,766.05 | 3 Feet | Add to Order |
| KM-9544 | 15.125 | 13.125 | $3,782.90 | 3 Feet | Add to Order |
| KM-9557 | 15.187 | 13.187 | $3,799.52 | 3 Feet | Add to Order |
| KM-9558 | 15.250 | 13.250 | $3,816.40 | 3 Feet | Add to Order |
| KM-9559 | 15.312 | 13.312 | $3,833.00 | 3 Feet | Add to Order |
| KM-9560 | 15.375 | 13.375 | $3,849.88 | 3 Feet | Add to Order |
| KM-9561 | 15.437 | 13.437 | $3,866.48 | 3 Feet | Add to Order |
| KM-9562 | 15.500 | 13.500 | $3,883.35 | 3 Feet | Add to Order |
| KM-9563 | 15.562 | 13.562 | $3,899.95 | 3 Feet | Add to Order |
| KM-9564 | 15.625 | 13.625 | $3,916.83 | 3 Feet | Add to Order |
| KM-9565 | 15.687 | 13.687 | $3,933.42 | 3 Feet | Add to Order |
| KM-9533 | 15.750 | 13.750 | $3,950.30 | 3 Feet | Add to Order |
| KM-9556 | 15.812 | 13.812 | $3,966.90 | 3 Feet | Add to Order |
| KM-9554 | 15.875 | 13.875 | $3,983.78 | 3 Feet | Add to Order |
| KM-9522 | 15.937 | 13.937 | $4,000.38 | 3 Feet | Add to Order |
| KM-9523 | 16.000 | 14.000 | $4,017.25 | 3 Feet | Add to Order |
| KM-9524 | 16.062 | 14.062 | $4,033.85 | 3 Feet | Add to Order |
| KM-9525 | 16.125 | 14.125 | $4,050.73 | 3 Feet | Add to Order |
| KM-9526 | 16.187 | 14.187 | $4,067.33 | 3 Feet | Add to Order |
| KM-9527 | 16.250 | 14.250 | $4,084.20 | 3 Feet | Add to Order |
| KM-9528 | 16.312 | 14.312 | $4,100.80 | 3 Feet | Add to Order |
| KM-9529 | 16.375 | 14.375 | $4,117.68 | 3 Feet | Add to Order |
| KM-9530 | 16.437 | 14.437 | $4,134.30 | 3 Feet | Add to Order |
| KM-9543 | 16.500 | 14.500 | $4,151.15 | 3 Feet | Add to Order |
| KM-9532 | 16.562 | 14.562 | $4,167.78 | 3 Feet | Add to Order |
| KM-9521 | 16.625 | 14.625 | $4,184.63 | 3 Feet | Add to Order |
| KM-9534 | 16.687 | 14.687 | $4,201.25 | 3 Feet | Add to Order |
| KM-9535 | 16.750 | 14.750 | $4,218.13 | 3 Feet | Add to Order |
| KM-9536 | 16.812 | 14.812 | $4,234.73 | 3 Feet | Add to Order |
| KM-9537 | 16.875 | 14.875 | $4,251.60 | 3 Feet | Add to Order |
| KM-9538 | 16.937 | 14.937 | $4,268.20 | 3 Feet | Add to Order |
| KM-9539 | 17.000 | 15.000 | $4,285.08 | 3 Feet | Add to Order |
| KM-9540 | 17.062 | 15.062 | $4,301.68 | 3 Feet | Add to Order |
| KM-9541 | 17.125 | 15.125 | $4,318.55 | 3 Feet | Add to Order |
| KM-9542 | 17.187 | 15.187 | $4,335.15 | 3 Feet | Add to Order |
| KM-9569 | 17.250 | 15.250 | $4,352.03 | 3 Feet | Add to Order |
| KM-9604 | 17.312 | 15.312 | $4,368.63 | 3 Feet | Add to Order |
| KM-9566 | 17.375 | 15.375 | $4,385.50 | 3 Feet | Add to Order |
| KM-9594 | 17.437 | 15.437 | $4,402.10 | 3 Feet | Add to Order |
| KM-9595 | 17.500 | 15.500 | $4,418.97 | 3 Feet | Add to Order |
| KM-9596 | 17.562 | 15.562 | $4,435.58 | 3 Feet | Add to Order |
| KM-9597 | 17.625 | 15.625 | $4,452.45 | 3 Feet | Add to Order |
| KM-9598 | 17.687 | 15.687 | $4,469.05 | 3 Feet | Add to Order |
| KM-9599 | 17.750 | 15.750 | $4,485.92 | 3 Feet | Add to Order |
| KM-9600 | 17.812 | 15.812 | $4,502.53 | 3 Feet | Add to Order |
| KM-9601 | 17.875 | 15.875 | $4,519.40 | 3 Feet | Add to Order |
| KM-9615 | 17.937 | 15.937 | $4,536.03 | 3 Feet | Add to Order |
| KM-9603 | 18.000 | 16.000 | $4,552.88 | 3 Feet | Add to Order |
| KM-9592 | 18.062 | 16.062 | $4,569.50 | 3 Feet | Add to Order |
| KM-9605 | 18.125 | 16.125 | $4,586.35 | 3 Feet | Add to Order |
| KM-9606 | 18.187 | 16.187 | $4,602.98 | 3 Feet | Add to Order |
| KM-9607 | 18.250 | 16.250 | $4,619.85 | 3 Feet | Add to Order |
| KM-9608 | 18.312 | 16.312 | $4,636.45 | 3 Feet | Add to Order |
| KM-9609 | 18.375 | 16.375 | $4,653.33 | 3 Feet | Add to Order |
| KM-9610 | 18.437 | 16.437 | $4,669.93 | 3 Feet | Add to Order |
| KM-9611 | 18.500 | 16.500 | $4,686.80 | 3 Feet | Add to Order |
| KM-9612 | 18.562 | 16.562 | $4,703.40 | 3 Feet | Add to Order |
| KM-9613 | 18.625 | 16.625 | $4,720.28 | 3 Feet | Add to Order |
| KM-9614 | 18.687 | 16.687 | $4,736.88 | 3 Feet | Add to Order |
| KM-9580 | 18.750 | 16.750 | $4,753.75 | 3 Feet | Add to Order |
| KM-9578 | 18.812 | 16.812 | $4,770.35 | 3 Feet | Add to Order |
| KM-9602 | 18.875 | 16.875 | $4,787.23 | 3 Feet | Add to Order |
| KM-9570 | 18.937 | 16.937 | $4,803.83 | 3 Feet | Add to Order |
| KM-9571 | 19.000 | 17.000 | $4,820.70 | 3 Feet | Add to Order |
| KM-9572 | 19.062 | 17.062 | $4,837.30 | 3 Feet | Add to Order |
| KM-9573 | 19.125 | 17.125 | $4,854.18 | 3 Feet | Add to Order |
| KM-9574 | 19.187 | 17.187 | $4,870.78 | 3 Feet | Add to Order |
| KM-9575 | 19.250 | 17.250 | $4,887.65 | 3 Feet | Add to Order |
| KM-9576 | 19.312 | 17.312 | $4,904.25 | 3 Feet | Add to Order |
| KM-9577 | 19.375 | 17.375 | $4,921.13 | 3 Feet | Add to Order |
| KM-9591 | 19.437 | 17.437 | $4,937.75 | 3 Feet | Add to Order |
| KM-9579 | 19.500 | 17.500 | $4,954.60 | 3 Feet | Add to Order |
| KM-9568 | 19.562 | 17.562 | $4,971.23 | 3 Feet | Add to Order |
| KM-9581 | 19.625 | 17.625 | $4,988.10 | 3 Feet | Add to Order |
| KM-9582 | 19.687 | 17.687 | $5,004.70 | 3 Feet | Add to Order |
| KM-9583 | 19.750 | 17.750 | $5,021.58 | 3 Feet | Add to Order |
| KM-9584 | 19.812 | 17.812 | $5,038.18 | 3 Feet | Add to Order |
| KM-9585 | 19.875 | 17.875 | $5,055.05 | 3 Feet | Add to Order |
| KM-9586 | 19.937 | 17.937 | $5,071.65 | 3 Feet | Add to Order |
| KM-9587 | 20.000 | 18.000 | $5,088.53 | 3 Feet | Add to Order |
| Rev. 08-22, 04-22, 11-21, 06-21 | |||||
| Phenolic Tube Tolerances | ||||
| ↓ Inside Diameter ↓ | ||||
| Outside Diameter | Turned OD Tolerance |
Steel Mandrel |
Built-up Mandrel |
|
| 0.125" to 0.749" | ±.005" | ±.003" | - | |
| 0.750" to 1.999" | ±.005" | ±.004" | - | |
| 2.000" to 4.000" | ±.008" | ±.006" | - | |
| 4.001" - 12.000" | ±.025" ** | ±.010" | - | |
| 12.001" - 18.000" | ±.030" ** | ±.030" | ±.060" | |
| 18.001" - 24.000" | ±.035" ** | ±.040" | ±.075" | |
| 24.001" - 48.000" | ±.040" ** | ±.060" | ±.090" | |
|
** Tubes over 8.000" OD are supplied as wound, which
** Tubes turned to the following OD tolerance
|
||||
