G11 Glass Reinforced Tubes - .500" Wall Thickness
G11 Glass Reinforced Tubes
(yellow green to amber)
This grade is similar to G10/FR4, with the addition of a higher operating
temperature and some improved mechanical strength at elevated temperatures.
The main difference between NEMA Grades G11 and FR5 is that FR5 is a fire retardant grade of G11. Therefore, FR5 can be safely substituted when G11 is called for, while G11 can never be substituted where FR5 is called for. (NEMA G-11 certs to MIL-I-24768/3 GEB, IEC 60893-3 Type 2 EP GC 203; FR5 certifies to Mil-I-24768/28 GEB-F.)
G11 Tubes Technical Data Sheet
G11 Tubes Chemical Resistance Chart
Tubes are made in random lengths between 30" - 36".
Our pricing and minimums are based on the 36".
Tubes can also be made in 42" to 48" random lengths for the same pricing.
Measured lengths of 36"±1" and 48"±1" are also available via manual quote.
| .500" Wall Thickness G11 FR5 Tubes | |||||
| Part # | OD (in.) | ID (in.) | Price Per Foot | Minimum | Order Online |
|---|---|---|---|---|---|
| KM-11042 | 1.500 | 0.500 | $207.90 | 6 Feet | Add to Order |
| KM-11043 | 1.562 | 0.562 | $219.30 | 6 Feet | Add to Order |
| KM-11044 | 1.625 | 0.625 | $158.42 | 9 Feet | Add to Order |
| KM-11045 | 1.687 | 0.687 | $166.25 | 9 Feet | Add to Order |
| KM-11064 | 1.750 | 0.750 | $174.08 | 6 Feet | Add to Order |
| KM-11047 | 1.812 | 0.812 | $181.90 | 6 Feet | Add to Order |
| KM-11041 | 1.875 | 0.875 | $189.73 | 6 Feet | Add to Order |
| KM-10734 | 1.937 | 0.937 | $197.58 | 6 Feet | Add to Order |
| KM-10726 | 2.000 | 1.000 | $205.40 | 6 Feet | Add to Order |
| KM-10736 | 2.062 | 1.062 | $213.15 | 6 Feet | Add to Order |
| KM-10737 | 2.125 | 1.125 | $221.05 | 6 Feet | Add to Order |
| KM-10738 | 2.187 | 1.187 | $228.83 | 6 Feet | Add to Order |
| KM-10739 | 2.250 | 1.250 | $236.73 | 6 Feet | Add to Order |
| KM-10740 | 2.312 | 1.312 | $244.48 | 6 Feet | Add to Order |
| KM-8859 | 2.375 | 1.375 | $252.38 | 6 Feet | Add to Order |
| KM-8971 | 2.437 | 1.437 | $260.15 | 6 Feet | Add to Order |
| KM-1536 | 2.500 | 1.500 | $268.03 | 6 Feet | Add to Order |
| KM-8973 | 2.562 | 1.562 | $275.80 | 6 Feet | Add to Order |
| KM-8974 | 2.625 | 1.625 | $283.70 | 6 Feet | Add to Order |
| KM-8952 | 2.687 | 1.687 | $291.45 | 6 Feet | Add to Order |
| KM-1541 | 2.750 | 1.750 | $299.35 | 6 Feet | Add to Order |
| KM-8967 | 2.812 | 1.812 | $307.13 | 6 Feet | Add to Order |
| KM-8945 | 2.875 | 1.875 | $315.03 | 6 Feet | Add to Order |
| KM-8946 | 2.937 | 1.937 | $322.78 | 6 Feet | Add to Order |
| KM-1546 | 3.000 | 2.000 | $330.68 | 6 Feet | Add to Order |
| KM-8948 | 3.062 | 2.062 | $338.45 | 3 Feet | Add to Order |
| KM-8949 | 3.125 | 2.125 | $346.33 | 3 Feet | Add to Order |
| KM-8959 | 3.187 | 2.187 | $354.10 | 3 Feet | Add to Order |
| KM-1551 | 3.250 | 2.250 | $362.00 | 3 Feet | Add to Order |
| KM-9044 | 3.312 | 2.312 | $369.75 | 3 Feet | Add to Order |
| KM-9024 | 3.375 | 2.375 | $377.65 | 3 Feet | Add to Order |
| KM-9025 | 3.437 | 2.437 | $385.42 | 3 Feet | Add to Order |
| KM-1556 | 3.500 | 2.500 | $393.33 | 3 Feet | Add to Order |
| KM-9027 | 3.562 | 2.562 | $401.08 | 3 Feet | Add to Order |
| KM-9037 | 3.625 | 2.625 | $408.98 | 3 Feet | Add to Order |
| KM-8568 | 3.687 | 2.687 | $416.75 | 3 Feet | Add to Order |
| KM-1561 | 3.750 | 2.750 | $424.63 | 3 Feet | Add to Order |
| KM-8570 | 3.812 | 2.812 | $432.40 | 3 Feet | Add to Order |
| KM-8571 | 3.875 | 2.875 | $440.30 | 3 Feet | Add to Order |
| KM-8572 | 3.937 | 2.937 | $448.05 | 3 Feet | Add to Order |
| KM-1565 | 4.000 | 3.000 | $455.95 | 3 Feet | Add to Order |
| KM-8574 | 4.062 | 3.062 | $463.73 | 3 Feet | Add to Order |
| KM-9446 | 4.125 | 3.125 | $471.63 | 3 Feet | Add to Order |
| KM-9445 | 4.187 | 3.187 | $479.38 | 3 Feet | Add to Order |
| KM-1570 | 4.250 | 3.250 | $487.28 | 3 Feet | Add to Order |
| KM-9443 | 4.312 | 3.312 | $495.05 | 3 Feet | Add to Order |
| KM-9442 | 4.375 | 3.375 | $502.92 | 3 Feet | Add to Order |
| KM-9441 | 4.437 | 3.437 | $510.70 | 3 Feet | Add to Order |
| KM-1575 | 4.500 | 3.500 | $518.60 | 3 Feet | Add to Order |
| KM-9439 | 4.562 | 3.562 | $526.35 | 3 Feet | Add to Order |
| KM-9588 | 4.625 | 3.625 | $534.25 | 3 Feet | Add to Order |
| KM-9380 | 4.687 | 3.687 | $542.03 | 3 Feet | Add to Order |
| KM-1580 | 4.750 | 3.750 | $549.93 | 3 Feet | Add to Order |
| KM-9692 | 4.812 | 3.812 | $557.68 | 3 Feet | Add to Order |
| KM-9691 | 4.875 | 3.875 | $565.57 | 3 Feet | Add to Order |
| KM-9689 | 4.937 | 3.937 | $573.35 | 3 Feet | Add to Order |
| KM-1584 | 5.000 | 4.000 | $581.23 | 3 Feet | Add to Order |
| KM-9617 | 5.062 | 4.062 | $589.00 | 3 Feet | Add to Order |
| KM-9665 | 5.125 | 4.125 | $596.90 | 3 Feet | Add to Order |
| KM-9637 | 5.187 | 4.187 | $604.65 | 3 Feet | Add to Order |
| KM-9636 | 5.250 | 4.250 | $612.55 | 3 Feet | Add to Order |
| KM-9635 | 5.312 | 4.312 | $620.33 | 3 Feet | Add to Order |
| KM-9634 | 5.375 | 4.375 | $628.23 | 3 Feet | Add to Order |
| KM-9633 | 5.437 | 4.437 | $635.97 | 3 Feet | Add to Order |
| KM-1589 | 5.500 | 4.500 | $643.88 | 3 Feet | Add to Order |
| KM-9631 | 5.562 | 4.562 | $651.65 | 3 Feet | Add to Order |
| KM-9630 | 5.625 | 4.625 | $659.53 | 3 Feet | Add to Order |
| KM-9629 | 5.687 | 4.687 | $667.30 | 3 Feet | Add to Order |
| KM-9616 | 5.750 | 4.750 | $675.20 | 3 Feet | Add to Order |
| KM-9627 | 5.812 | 4.812 | $682.95 | 3 Feet | Add to Order |
| KM-9639 | 5.875 | 4.875 | $758.58 | 3 Feet | Add to Order |
| KM-9625 | 5.937 | 4.937 | $767.13 | 3 Feet | Add to Order |
| KM-1594 | 6.000 | 5.000 | $775.78 | 3 Feet | Add to Order |
| KM-9623 | 6.062 | 5.062 | $784.30 | 3 Feet | Add to Order |
| KM-9622 | 6.125 | 5.125 | $792.98 | 3 Feet | Add to Order |
| KM-9621 | 6.187 | 5.187 | $801.50 | 3 Feet | Add to Order |
| KM-9620 | 6.250 | 5.250 | $810.18 | 3 Feet | Add to Order |
| KM-9619 | 6.312 | 5.312 | $818.70 | 3 Feet | Add to Order |
| KM-9618 | 6.375 | 5.375 | $827.38 | 3 Feet | Add to Order |
| KM-9650 | 6.437 | 5.437 | $835.90 | 3 Feet | Add to Order |
| KM-1600 | 6.500 | 5.500 | $844.57 | 3 Feet | Add to Order |
| KM-9628 | 6.562 | 5.562 | $853.10 | 3 Feet | Add to Order |
| KM-9662 | 6.625 | 5.625 | $861.75 | 3 Feet | Add to Order |
| KM-9661 | 6.687 | 5.687 | $870.28 | 3 Feet | Add to Order |
| KM-9660 | 6.750 | 5.750 | $878.95 | 3 Feet | Add to Order |
| KM-9659 | 6.812 | 5.812 | $887.48 | 3 Feet | Add to Order |
| KM-9658 | 6.875 | 5.875 | $896.15 | 3 Feet | Add to Order |
| KM-9657 | 6.937 | 5.937 | $904.68 | 3 Feet | Add to Order |
| KM-1606 | 7.000 | 6.000 | $913.35 | 3 Feet | Add to Order |
| KM-9655 | 7.062 | 6.062 | $878.70 | 3 Feet | Add to Order |
| KM-9654 | 7.125 | 6.125 | $887.15 | 3 Feet | Add to Order |
| KM-9653 | 7.187 | 6.187 | $895.45 | 3 Feet | Add to Order |
| KM-9640 | 7.250 | 6.250 | $903.88 | 3 Feet | Add to Order |
| KM-9651 | 7.312 | 6.312 | $912.18 | 3 Feet | Add to Order |
| KM-9663 | 7.375 | 6.375 | $920.63 | 3 Feet | Add to Order |
| KM-9649 | 7.437 | 6.437 | $928.93 | 3 Feet | Add to Order |
| KM-9648 | 7.500 | 6.500 | $937.35 | 3 Feet | Add to Order |
| KM-9647 | 7.562 | 6.562 | $945.65 | 3 Feet | Add to Order |
| KM-9646 | 7.625 | 6.625 | $954.10 | 3 Feet | Add to Order |
| KM-9645 | 7.687 | 6.687 | $962.40 | 3 Feet | Add to Order |
| KM-9644 | 7.750 | 6.750 | $970.82 | 3 Feet | Add to Order |
| KM-9643 | 7.812 | 6.812 | $979.15 | 3 Feet | Add to Order |
| KM-9642 | 7.875 | 6.875 | $987.57 | 3 Feet | Add to Order |
| KM-9857 | 7.937 | 6.937 | $995.88 | 3 Feet | Add to Order |
| KM-9531 | 8.000 | 7.000 | $1,004.33 | 3 Feet | Add to Order |
| KM-9833 | 8.062 | 7.062 | $1,012.63 | 3 Feet | Add to Order |
| KM-9930 | 8.125 | 7.125 | $1,021.05 | 3 Feet | Add to Order |
| KM-9980 | 8.187 | 7.187 | $1,029.35 | 3 Feet | Add to Order |
| KM-9895 | 8.250 | 7.250 | $1,037.80 | 3 Feet | Add to Order |
| KM-9967 | 8.312 | 7.312 | $1,046.10 | 3 Feet | Add to Order |
| KM-9966 | 8.375 | 7.375 | $1,054.53 | 3 Feet | Add to Order |
| KM-9965 | 8.437 | 7.437 | $1,062.83 | 3 Feet | Add to Order |
| KM-9964 | 8.500 | 7.500 | $1,071.28 | 3 Feet | Add to Order |
| KM-9963 | 8.562 | 7.562 | $1,079.58 | 3 Feet | Add to Order |
| KM-9962 | 8.625 | 7.625 | $1,088.00 | 3 Feet | Add to Order |
| KM-9951 | 8.687 | 7.687 | $1,096.30 | 3 Feet | Add to Order |
| KM-9960 | 8.750 | 7.750 | $1,104.75 | 3 Feet | Add to Order |
| KM-9969 | 8.812 | 7.812 | $1,113.05 | 3 Feet | Add to Order |
| KM-9958 | 8.875 | 7.875 | $1,121.48 | 3 Feet | Add to Order |
| KM-9957 | 8.937 | 7.937 | $1,129.78 | 3 Feet | Add to Order |
| KM-9956 | 9.000 | 8.000 | $1,138.23 | 3 Feet | Add to Order |
| KM-9954 | 9.125 | 8.125 | $1,154.95 | 3 Feet | Add to Order |
| KM-9953 | 9.187 | 8.187 | $1,163.25 | 3 Feet | Add to Order |
| KM-9978 | 9.250 | 8.250 | $1,171.70 | 3 Feet | Add to Order |
| KM-9959 | 9.312 | 8.312 | $1,180.00 | 3 Feet | Add to Order |
| KM-9961 | 9.375 | 8.375 | $1,188.43 | 3 Feet | Add to Order |
| KM-9987 | 9.437 | 8.437 | $1,196.75 | 3 Feet | Add to Order |
| KM-9986 | 9.500 | 8.500 | $1,205.18 | 3 Feet | Add to Order |
| KM-9985 | 9.562 | 8.562 | $1,213.48 | 3 Feet | Add to Order |
| KM-9984 | 9.625 | 8.625 | $1,221.93 | 3 Feet | Add to Order |
| KM-9983 | 9.687 | 8.687 | $1,230.23 | 3 Feet | Add to Order |
| KM-9982 | 9.750 | 8.750 | $1,238.65 | 3 Feet | Add to Order |
| KM-9981 | 9.812 | 8.812 | $1,246.95 | 3 Feet | Add to Order |
| KM-9970 | 9.875 | 8.875 | $1,255.40 | 3 Feet | Add to Order |
| KM-9979 | 9.937 | 8.937 | $1,263.70 | 3 Feet | Add to Order |
| KM-9988 | 10.000 | 9.000 | $1,272.13 | 3 Feet | Add to Order |
| KM-9977 | 10.062 | 9.062 | $1,280.43 | 3 Feet | Add to Order |
| KM-9976 | 10.125 | 9.125 | $1,288.88 | 3 Feet | Add to Order |
| KM-9975 | 10.187 | 9.187 | $1,297.18 | 3 Feet | Add to Order |
| KM-9974 | 10.250 | 9.250 | $1,305.60 | 3 Feet | Add to Order |
| KM-9973 | 10.312 | 9.312 | $1,313.90 | 3 Feet | Add to Order |
| KM-9972 | 10.375 | 9.375 | $1,322.35 | 3 Feet | Add to Order |
| KM-9971 | 10.437 | 9.437 | $1,330.65 | 3 Feet | Add to Order |
| KM-9942 | 10.500 | 9.500 | $1,339.08 | 3 Feet | Add to Order |
| KM-9914 | 10.562 | 9.562 | $1,347.38 | 3 Feet | Add to Order |
| KM-9952 | 10.625 | 9.625 | $1,355.83 | 3 Feet | Add to Order |
| KM-9929 | 10.687 | 9.687 | $1,364.13 | 3 Feet | Add to Order |
| KM-9928 | 10.750 | 9.750 | $1,372.55 | 3 Feet | Add to Order |
| KM-9927 | 10.812 | 9.812 | $1,380.88 | 3 Feet | Add to Order |
| KM-9926 | 10.875 | 9.875 | $1,389.30 | 3 Feet | Add to Order |
| KM-9925 | 10.937 | 9.937 | $1,397.60 | 3 Feet | Add to Order |
| KM-9924 | 11.000 | 10.000 | $1,406.05 | 3 Feet | Add to Order |
| KM-9913 | 11.062 | 10.062 | $1,414.35 | 3 Feet | Add to Order |
| KM-9922 | 11.125 | 10.125 | $1,422.78 | 3 Feet | Add to Order |
| KM-9931 | 11.187 | 10.187 | $1,431.07 | 3 Feet | Add to Order |
| KM-9920 | 11.250 | 10.250 | $1,439.52 | 3 Feet | Add to Order |
| KM-9919 | 11.312 | 10.312 | $1,447.83 | 3 Feet | Add to Order |
| KM-9918 | 11.375 | 10.375 | $1,456.25 | 3 Feet | Add to Order |
| KM-9917 | 11.437 | 10.437 | $1,464.55 | 3 Feet | Add to Order |
| KM-9916 | 11.500 | 10.500 | $1,473.00 | 3 Feet | Add to Order |
| KM-9915 | 11.562 | 10.562 | $1,481.30 | 3 Feet | Add to Order |
| KM-9940 | 11.625 | 10.625 | $1,489.73 | 3 Feet | Add to Order |
| KM-9921 | 11.687 | 10.687 | $1,498.03 | 3 Feet | Add to Order |
| KM-9923 | 11.750 | 10.750 | $1,506.48 | 3 Feet | Add to Order |
| KM-9949 | 11.812 | 10.812 | $1,514.77 | 3 Feet | Add to Order |
| KM-9948 | 11.875 | 10.875 | $1,523.20 | 3 Feet | Add to Order |
| KM-9947 | 11.937 | 10.937 | $1,531.50 | 3 Feet | Add to Order |
| KM-9946 | 12.000 | 11.000 | $1,539.95 | 3 Feet | Add to Order |
| KM-9945 | 12.062 | 11.062 | $1,548.25 | 3 Feet | Add to Order |
| KM-9944 | 12.125 | 11.125 | $1,556.68 | 3 Feet | Add to Order |
| KM-9943 | 12.187 | 11.187 | $1,564.98 | 3 Feet | Add to Order |
| KM-9932 | 12.250 | 11.250 | $1,573.43 | 3 Feet | Add to Order |
| KM-9941 | 12.312 | 11.312 | $1,581.73 | 3 Feet | Add to Order |
| KM-9950 | 12.375 | 11.375 | $1,590.15 | 3 Feet | Add to Order |
| KM-9939 | 12.437 | 11.437 | $1,598.48 | 3 Feet | Add to Order |
| KM-9938 | 12.500 | 11.500 | $1,606.90 | 3 Feet | Add to Order |
| KM-9937 | 12.562 | 11.562 | $1,615.20 | 3 Feet | Add to Order |
| KM-9936 | 12.625 | 11.625 | $1,623.65 | 3 Feet | Add to Order |
| KM-9935 | 12.687 | 11.687 | $1,631.95 | 3 Feet | Add to Order |
| KM-9934 | 12.750 | 11.750 | $1,640.38 | 3 Feet | Add to Order |
| KM-10215 | 12.812 | 11.812 | $1,648.68 | 3 Feet | Add to Order |
| KM-10472 | 12.875 | 11.875 | $1,657.13 | 3 Feet | Add to Order |
| KM-10471 | 12.937 | 11.937 | $1,665.43 | 3 Feet | Add to Order |
| KM-10470 | 13.000 | 12.000 | $1,673.85 | 3 Feet | Add to Order |
| KM-10469 | 13.062 | 12.062 | $1,682.15 | 3 Feet | Add to Order |
| KM-10468 | 13.125 | 12.125 | $1,690.60 | 3 Feet | Add to Order |
| KM-10467 | 13.187 | 12.187 | $1,698.90 | 3 Feet | Add to Order |
| KM-10458 | 13.250 | 12.250 | $1,707.32 | 3 Feet | Add to Order |
| KM-10465 | 13.312 | 12.312 | $1,715.63 | 3 Feet | Add to Order |
| KM-10473 | 13.375 | 12.375 | $1,724.08 | 3 Feet | Add to Order |
| KM-10463 | 13.437 | 12.437 | $1,732.38 | 3 Feet | Add to Order |
| KM-10462 | 13.500 | 12.500 | $1,740.80 | 3 Feet | Add to Order |
| KM-10461 | 13.562 | 12.562 | $1,749.10 | 3 Feet | Add to Order |
| KM-10460 | 13.625 | 12.625 | $1,757.55 | 3 Feet | Add to Order |
| KM-10459 | 13.687 | 12.687 | $1,765.85 | 3 Feet | Add to Order |
| KM-10481 | 13.750 | 12.750 | $1,774.28 | 3 Feet | Add to Order |
| KM-10483 | 13.812 | 12.812 | $1,782.60 | 3 Feet | Add to Order |
| KM-10466 | 13.875 | 12.875 | $1,791.02 | 3 Feet | Add to Order |
| KM-10488 | 13.937 | 12.937 | $1,799.33 | 3 Feet | Add to Order |
| KM-10487 | 14.000 | 13.000 | $1,807.78 | 3 Feet | Add to Order |
| KM-10486 | 14.062 | 13.062 | $1,816.07 | 3 Feet | Add to Order |
| KM-10485 | 14.125 | 13.125 | $1,824.50 | 3 Feet | Add to Order |
| KM-10484 | 14.187 | 13.187 | $1,832.80 | 3 Feet | Add to Order |
| KM-10474 | 14.250 | 13.250 | $1,841.25 | 3 Feet | Add to Order |
| KM-10482 | 14.312 | 13.312 | $1,849.55 | 3 Feet | Add to Order |
| KM-10490 | 14.375 | 13.375 | $1,857.98 | 3 Feet | Add to Order |
| KM-10480 | 14.437 | 13.437 | $1,866.28 | 3 Feet | Add to Order |
| KM-10479 | 14.500 | 13.500 | $1,874.73 | 3 Feet | Add to Order |
| KM-10478 | 14.562 | 13.562 | $1,883.03 | 3 Feet | Add to Order |
| KM-10477 | 14.625 | 13.625 | $1,891.45 | 3 Feet | Add to Order |
| KM-10476 | 14.687 | 13.687 | $1,899.75 | 3 Feet | Add to Order |
| KM-10475 | 14.750 | 13.750 | $1,908.20 | 3 Feet | Add to Order |
| KM-10456 | 14.812 | 13.812 | $1,916.50 | 3 Feet | Add to Order |
| KM-10431 | 14.875 | 13.875 | $1,924.93 | 3 Feet | Add to Order |
| KM-10464 | 14.937 | 13.937 | $1,933.23 | 3 Feet | Add to Order |
| KM-10438 | 15.000 | 14.000 | $1,941.68 | 3 Feet | Add to Order |
| KM-10437 | 15.062 | 14.062 | $1,949.98 | 3 Feet | Add to Order |
| KM-10436 | 15.125 | 14.125 | $1,958.40 | 3 Feet | Add to Order |
| KM-10435 | 15.187 | 14.187 | $1,966.73 | 3 Feet | Add to Order |
| KM-10434 | 15.250 | 14.250 | $1,975.15 | 3 Feet | Add to Order |
| KM-10425 | 15.312 | 14.312 | $1,983.45 | 3 Feet | Add to Order |
| KM-10432 | 15.375 | 14.375 | $1,991.88 | 3 Feet | Add to Order |
| KM-10440 | 15.437 | 14.437 | $2,000.20 | 3 Feet | Add to Order |
| KM-10430 | 15.500 | 14.500 | $2,008.63 | 3 Feet | Add to Order |
| KM-10429 | 15.562 | 14.562 | $2,016.93 | 3 Feet | Add to Order |
| KM-10428 | 15.625 | 14.625 | $2,025.38 | 3 Feet | Add to Order |
| KM-10427 | 15.687 | 14.687 | $2,033.68 | 3 Feet | Add to Order |
| KM-10426 | 15.750 | 14.750 | $2,042.10 | 3 Feet | Add to Order |
| KM-10448 | 15.812 | 14.812 | $2,050.40 | 3 Feet | Add to Order |
| KM-10450 | 15.875 | 14.875 | $2,058.85 | 3 Feet | Add to Order |
| KM-10433 | 15.937 | 14.937 | $2,067.15 | 3 Feet | Add to Order |
| KM-10455 | 16.000 | 15.000 | $2,075.58 | 3 Feet | Add to Order |
| KM-10454 | 16.062 | 15.062 | $2,083.88 | 3 Feet | Add to Order |
| KM-10453 | 16.125 | 15.125 | $2,092.33 | 3 Feet | Add to Order |
| KM-10452 | 16.187 | 15.187 | $2,100.63 | 3 Feet | Add to Order |
| KM-10451 | 16.250 | 15.250 | $2,109.05 | 3 Feet | Add to Order |
| KM-10441 | 16.312 | 15.312 | $2,117.35 | 3 Feet | Add to Order |
| KM-10449 | 16.375 | 15.375 | $2,125.80 | 3 Feet | Add to Order |
| KM-10457 | 16.437 | 15.437 | $2,134.10 | 3 Feet | Add to Order |
| KM-10447 | 16.500 | 15.500 | $2,142.53 | 3 Feet | Add to Order |
| KM-10446 | 16.562 | 15.562 | $2,150.83 | 3 Feet | Add to Order |
| KM-10445 | 16.625 | 15.625 | $2,159.28 | 3 Feet | Add to Order |
| KM-10444 | 16.687 | 15.687 | $2,167.58 | 3 Feet | Add to Order |
| KM-10443 | 16.750 | 15.750 | $2,176.00 | 3 Feet | Add to Order |
| KM-10505 | 16.812 | 15.812 | $2,184.33 | 3 Feet | Add to Order |
| KM-10439 | 16.875 | 15.875 | $2,192.75 | 3 Feet | Add to Order |
| KM-10489 | 16.937 | 15.937 | $2,201.05 | 3 Feet | Add to Order |
| KM-10538 | 17.000 | 16.000 | $2,209.50 | 3 Feet | Add to Order |
| KM-10537 | 17.062 | 16.062 | $2,217.80 | 3 Feet | Add to Order |
| KM-10536 | 17.125 | 16.125 | $2,226.23 | 3 Feet | Add to Order |
| KM-10535 | 17.187 | 16.187 | $2,234.52 | 3 Feet | Add to Order |
| KM-10534 | 17.250 | 16.250 | $2,242.98 | 3 Feet | Add to Order |
| KM-10533 | 17.312 | 16.312 | $2,251.28 | 3 Feet | Add to Order |
| KM-10524 | 17.375 | 16.375 | $2,259.70 | 3 Feet | Add to Order |
| KM-10531 | 17.437 | 16.437 | $2,268.00 | 3 Feet | Add to Order |
| KM-10539 | 17.500 | 16.500 | $2,276.45 | 3 Feet | Add to Order |
| KM-10529 | 17.562 | 16.562 | $2,284.75 | 3 Feet | Add to Order |
| KM-10528 | 17.625 | 16.625 | $2,293.18 | 3 Feet | Add to Order |
| KM-10527 | 17.687 | 16.687 | $2,301.48 | 3 Feet | Add to Order |
| KM-10526 | 17.750 | 16.750 | $2,309.93 | 3 Feet | Add to Order |
| KM-10525 | 17.812 | 16.812 | $2,318.23 | 3 Feet | Add to Order |
| KM-10724 | 17.875 | 16.875 | $2,326.65 | 3 Feet | Add to Order |
| KM-10723 | 17.937 | 16.937 | $2,334.95 | 3 Feet | Add to Order |
| KM-10532 | 18.000 | 17.000 | $2,343.40 | 3 Feet | Add to Order |
| KM-10722 | 18.062 | 17.062 | $2,351.70 | 3 Feet | Add to Order |
| KM-10721 | 18.125 | 17.125 | $2,360.13 | 3 Feet | Add to Order |
| KM-10720 | 18.187 | 17.187 | $2,368.45 | 3 Feet | Add to Order |
| KM-10719 | 18.250 | 17.250 | $2,376.88 | 3 Feet | Add to Order |
| KM-10709 | 18.312 | 17.312 | $2,385.18 | 3 Feet | Add to Order |
| KM-10540 | 18.375 | 17.375 | $2,393.60 | 3 Feet | Add to Order |
| KM-10717 | 18.437 | 17.437 | $2,401.93 | 3 Feet | Add to Order |
| KM-10725 | 18.500 | 17.500 | $2,410.35 | 3 Feet | Add to Order |
| KM-10715 | 18.562 | 17.562 | $2,418.65 | 3 Feet | Add to Order |
| KM-10714 | 18.625 | 17.625 | $2,427.10 | 3 Feet | Add to Order |
| KM-10713 | 18.687 | 17.687 | $2,435.40 | 3 Feet | Add to Order |
| KM-10712 | 18.750 | 17.750 | $2,443.83 | 3 Feet | Add to Order |
| KM-10733 | 18.875 | 17.875 | $2,460.58 | 3 Feet | Add to Order |
| KM-10711 | 18.812 | 17.812 | $2,452.13 | 3 Feet | Add to Order |
| KM-10522 | 18.937 | 17.937 | $2,468.88 | 3 Feet | Add to Order |
| KM-10497 | 19.000 | 18.000 | $2,477.30 | 3 Feet | Add to Order |
| KM-10530 | 19.062 | 18.062 | $2,485.60 | 3 Feet | Add to Order |
| KM-10504 | 19.125 | 18.125 | $2,494.05 | 3 Feet | Add to Order |
| KM-10503 | 19.187 | 18.187 | $2,502.35 | 3 Feet | Add to Order |
| KM-10502 | 19.250 | 18.250 | $2,510.77 | 3 Feet | Add to Order |
| KM-10501 | 19.312 | 18.312 | $2,519.08 | 3 Feet | Add to Order |
| KM-10500 | 19.375 | 18.375 | $2,527.53 | 3 Feet | Add to Order |
| KM-10491 | 19.437 | 18.437 | $2,535.83 | 3 Feet | Add to Order |
| KM-10498 | 19.500 | 18.500 | $2,544.25 | 3 Feet | Add to Order |
| KM-10506 | 19.562 | 18.562 | $2,552.55 | 3 Feet | Add to Order |
| KM-10496 | 19.625 | 18.625 | $2,561.00 | 3 Feet | Add to Order |
| KM-10495 | 19.687 | 18.687 | $2,569.30 | 3 Feet | Add to Order |
| KM-10494 | 19.750 | 18.750 | $2,577.73 | 3 Feet | Add to Order |
| KM-10493 | 19.812 | 18.812 | $2,586.05 | 3 Feet | Add to Order |
| KM-10492 | 19.875 | 18.875 | $2,594.48 | 3 Feet | Add to Order |
| KM-10514 | 19.937 | 18.937 | $2,602.77 | 3 Feet | Add to Order |
| KM-10516 | 20.000 | 19.000 | $2,611.23 | 3 Feet | Add to Order |
| Rev. 08-22, 04-22, 11-21, 06-21 | |||||
| Phenolic Tube Tolerances | ||||
| ↓ Inside Diameter ↓ | ||||
| Outside Diameter | Turned OD Tolerance |
Steel Mandrel |
Built-up Mandrel |
|
| 0.125" to 0.749" | ±.005" | ±.003" | - | |
| 0.750" to 1.999" | ±.005" | ±.004" | - | |
| 2.000" to 4.000" | ±.008" | ±.006" | - | |
| 4.001" - 12.000" | ±.025" ** | ±.010" | - | |
| 12.001" - 18.000" | ±.030" ** | ±.030" | ±.060" | |
| 18.001" - 24.000" | ±.035" ** | ±.040" | ±.075" | |
| 24.001" - 48.000" | ±.040" ** | ±.060" | ±.090" | |
|
** Tubes over 8.000" OD are supplied as wound, which
** Tubes turned to the following OD tolerance
|
||||
