G11 Glass Reinforced Tubes - .250" Wall Thickness
G11 Glass Reinforced Tubes
(yellow green to amber)
This grade is similar to G10/FR4, with the addition of a higher operating
temperature and some improved mechanical strength at elevated temperatures.
The main difference between NEMA Grades G11 and FR5 is that FR5 is a fire retardant grade of G11. Therefore, FR5 can be safely substituted when G11 is called for, while G11 can never be substituted where FR5 is called for. (NEMA G-11 certs to MIL-I-24768/3 GEB, IEC 60893-3 Type 2 EP GC 203; FR5 certifies to Mil-I-24768/28 GEB-F.)
G11 Tubes Technical Data Sheet
G11 Tubes Chemical Resistance Chart
Tubes are made in random lengths between 30" - 36".
Our pricing and minimums are based on the 36".
Tubes can also be made in 42" to 48" random lengths for the same pricing.
Measured lengths of 36"±1" and 48"±1" are also available via manual quote.
| .250" Wall Thickness G11 Tubes | |||||
| Part # | OD (in.) | ID (in.) | Price Per Foot | Minimum | Order Online |
|---|---|---|---|---|---|
| KM-1504 | 1.000 | 0.500 | $92.18 | 12 Feet | Add to Order |
| KM-1509 | 1.062 | 0.562 | $98.03 | 12 Feet | Add to Order |
| KM-1515 | 1.125 | 0.625 | $71.33 | 15 Feet | Add to Order |
| KM-10875 | 1.187 | 0.687 | $75.35 | 15 Feet | Add to Order |
| KM-1514K | 1.250 | 0.750 | $79.38 | 15 Feet | Add to Order |
| KM-10877 | 1.312 | 0.812 | $83.40 | 12 Feet | Add to Order |
| KM-1520 | 1.375 | 0.875 | $87.40 | 12 Feet | Add to Order |
| KM-10852 | 1.437 | 0.937 | $91.43 | 12 Feet | Add to Order |
| KM-10869 | 1.500 | 1.000 | $95.45 | 12 Feet | Add to Order |
| KM-10847 | 1.562 | 1.062 | $99.43 | 12 Feet | Add to Order |
| KM-10848 | 1.625 | 1.125 | $103.48 | 12 Feet | Add to Order |
| KM-10849 | 1.687 | 1.187 | $107.48 | 12 Feet | Add to Order |
| KM-10850 | 1.750 | 1.250 | $111.53 | 9 Feet | Add to Order |
| KM-10851 | 1.812 | 1.312 | $115.50 | 9 Feet | Add to Order |
| KM-10861 | 1.875 | 1.375 | $119.55 | 9 Feet | Add to Order |
| KM-10853 | 1.937 | 1.437 | $123.55 | 9 Feet | Add to Order |
| KM-10845 | 2.000 | 1.500 | $127.60 | 9 Feet | Add to Order |
| KM-10855 | 2.062 | 1.562 | $131.58 | 9 Feet | Add to Order |
| KM-10856 | 2.125 | 1.625 | $135.63 | 9 Feet | Add to Order |
| KM-10857 | 2.187 | 1.687 | $139.63 | 9 Feet | Add to Order |
| KM-10858 | 2.250 | 1.750 | $143.68 | 9 Feet | Add to Order |
| KM-10859 | 2.312 | 1.812 | $147.65 | 9 Feet | Add to Order |
| KM-10860 | 2.375 | 1.875 | $151.70 | 9 Feet | Add to Order |
| KM-10829 | 2.437 | 1.937 | $155.70 | 9 Feet | Add to Order |
| KM-10950 | 2.500 | 2.000 | $159.75 | 9 Feet | Add to Order |
| KM-11033 | 2.562 | 2.062 | $163.73 | 9 Feet | Add to Order |
| KM-11034 | 2.625 | 2.125 | $167.80 | 6 Feet | Add to Order |
| KM-11035 | 2.687 | 2.187 | $171.77 | 6 Feet | Add to Order |
| KM-11036 | 2.750 | 2.250 | $175.83 | 6 Feet | Add to Order |
| KM-11037 | 2.812 | 2.312 | $179.83 | 6 Feet | Add to Order |
| KM-11038 | 2.875 | 2.375 | $183.88 | 6 Feet | Add to Order |
| KM-11048 | 2.937 | 2.437 | $187.85 | 6 Feet | Add to Order |
| KM-11040 | 3.000 | 2.500 | $191.90 | 6 Feet | Add to Order |
| KM-11032 | 3.062 | 2.562 | $195.90 | 6 Feet | Add to Order |
| KM-10967 | 3.125 | 2.625 | $199.95 | 6 Feet | Add to Order |
| KM-10968 | 3.187 | 2.687 | $203.92 | 6 Feet | Add to Order |
| KM-10969 | 3.250 | 2.750 | $207.98 | 6 Feet | Add to Order |
| KM-10970 | 3.312 | 2.812 | $211.98 | 6 Feet | Add to Order |
| KM-10980 | 3.375 | 2.875 | $216.02 | 6 Feet | Add to Order |
| KM-10972 | 3.437 | 2.937 | $220.00 | 6 Feet | Add to Order |
| KM-10964 | 3.500 | 3.000 | $224.05 | 6 Feet | Add to Order |
| KM-10973 | 3.562 | 3.062 | $228.05 | 6 Feet | Add to Order |
| KM-10999 | 3.625 | 3.125 | $232.10 | 6 Feet | Add to Order |
| KM-11000 | 3.687 | 3.187 | $236.08 | 6 Feet | Add to Order |
| KM-11001 | 3.750 | 3.250 | $240.13 | 6 Feet | Add to Order |
| KM-11002 | 3.812 | 3.312 | $244.13 | 6 Feet | Add to Order |
| KM-11003 | 3.875 | 3.375 | $248.17 | 6 Feet | Add to Order |
| KM-11004 | 3.937 | 3.437 | $252.15 | 6 Feet | Add to Order |
| KM-11014 | 4.000 | 3.500 | $256.20 | 6 Feet | Add to Order |
| KM-11006 | 4.062 | 3.562 | $260.20 | 6 Feet | Add to Order |
| KM-10998 | 4.125 | 3.625 | $264.25 | 6 Feet | Add to Order |
| KM-11008 | 4.187 | 3.687 | $268.23 | 6 Feet | Add to Order |
| KM-11009 | 4.250 | 3.750 | $272.28 | 6 Feet | Add to Order |
| KM-11010 | 4.312 | 3.812 | $276.28 | 6 Feet | Add to Order |
| KM-11011 | 4.375 | 3.875 | $280.33 | 6 Feet | Add to Order |
| KM-11012 | 4.437 | 3.937 | $284.30 | 6 Feet | Add to Order |
| KM-11013 | 4.500 | 4.000 | $288.35 | 6 Feet | Add to Order |
| KM-10990 | 4.562 | 4.062 | $292.35 | 6 Feet | Add to Order |
| KM-10988 | 4.625 | 4.125 | $296.40 | 6 Feet | Add to Order |
| KM-11005 | 4.687 | 4.187 | $300.38 | 6 Feet | Add to Order |
| KM-10983 | 4.750 | 4.250 | $304.43 | 6 Feet | Add to Order |
| KM-10984 | 4.812 | 4.312 | $308.43 | 6 Feet | Add to Order |
| KM-10768 | 4.875 | 4.375 | $312.47 | 6 Feet | Add to Order |
| KM-10760 | 4.937 | 4.437 | $316.45 | 6 Feet | Add to Order |
| KM-10770 | 5.000 | 4.500 | $320.50 | 6 Feet | Add to Order |
| KM-10771 | 5.062 | 4.562 | $324.50 | 6 Feet | Add to Order |
| KM-10772 | 5.125 | 4.625 | $328.55 | 6 Feet | Add to Order |
| KM-10773 | 5.187 | 4.687 | $332.53 | 6 Feet | Add to Order |
| KM-10774 | 5.250 | 4.750 | $336.58 | 3 Feet | Add to Order |
| KM-10775 | 5.312 | 4.812 | $340.58 | 3 Feet | Add to Order |
| KM-10752 | 5.375 | 4.875 | $378.40 | 3 Feet | Add to Order |
| KM-10750 | 5.437 | 4.937 | $382.80 | 3 Feet | Add to Order |
| KM-10767 | 5.500 | 5.000 | $387.25 | 3 Feet | Add to Order |
| KM-10745 | 5.562 | 5.062 | $391.63 | 3 Feet | Add to Order |
| KM-10746 | 5.625 | 5.125 | $396.08 | 3 Feet | Add to Order |
| KM-10747 | 5.687 | 5.187 | $400.45 | 3 Feet | Add to Order |
| KM-10748 | 5.750 | 5.250 | $404.90 | 3 Feet | Add to Order |
| KM-10749 | 5.812 | 5.312 | $409.28 | 3 Feet | Add to Order |
| KM-10759 | 5.875 | 5.375 | $413.73 | 3 Feet | Add to Order |
| KM-10751 | 5.937 | 5.437 | $418.10 | 3 Feet | Add to Order |
| KM-10743 | 6.000 | 5.500 | $422.55 | 3 Feet | Add to Order |
| KM-10753 | 6.062 | 5.562 | $426.93 | 3 Feet | Add to Order |
| KM-10754 | 6.125 | 5.625 | $431.38 | 3 Feet | Add to Order |
| KM-10755 | 6.187 | 5.687 | $435.75 | 3 Feet | Add to Order |
| KM-10756 | 6.250 | 5.750 | $440.20 | 3 Feet | Add to Order |
| KM-10757 | 6.312 | 5.812 | $444.58 | 3 Feet | Add to Order |
| KM-10778 | 6.375 | 5.875 | $449.03 | 3 Feet | Add to Order |
| KM-10744 | 6.437 | 5.937 | $453.40 | 3 Feet | Add to Order |
| KM-10769 | 6.500 | 6.000 | $457.85 | 3 Feet | Add to Order |
| KM-10795 | 6.562 | 6.062 | $422.63 | 3 Feet | Add to Order |
| KM-10796 | 6.625 | 6.125 | $426.83 | 3 Feet | Add to Order |
| KM-10797 | 6.687 | 6.187 | $430.97 | 3 Feet | Add to Order |
| KM-10798 | 6.750 | 6.250 | $435.20 | 3 Feet | Add to Order |
| KM-10799 | 6.812 | 6.312 | $439.35 | 3 Feet | Add to Order |
| KM-10800 | 6.875 | 6.375 | $443.58 | 3 Feet | Add to Order |
| KM-10810 | 6.937 | 6.437 | $447.73 | 3 Feet | Add to Order |
| KM-10802 | 7.000 | 6.500 | $451.95 | 3 Feet | Add to Order |
| KM-10794 | 7.062 | 6.562 | $456.10 | 3 Feet | Add to Order |
| KM-10804 | 7.125 | 6.625 | $460.30 | 3 Feet | Add to Order |
| KM-10805 | 7.187 | 6.687 | $464.45 | 3 Feet | Add to Order |
| KM-10806 | 7.250 | 6.750 | $468.68 | 3 Feet | Add to Order |
| KM-10807 | 7.312 | 6.812 | $472.83 | 3 Feet | Add to Order |
| KM-10808 | 7.375 | 6.875 | $477.05 | 3 Feet | Add to Order |
| KM-10809 | 7.437 | 6.937 | $481.20 | 3 Feet | Add to Order |
| KM-10786 | 7.500 | 7.000 | $485.42 | 3 Feet | Add to Order |
| KM-10784 | 7.562 | 7.062 | $489.58 | 3 Feet | Add to Order |
| KM-10801 | 7.625 | 7.125 | $493.78 | 3 Feet | Add to Order |
| KM-10779 | 7.687 | 7.187 | $497.95 | 3 Feet | Add to Order |
| KM-10780 | 7.750 | 7.250 | $502.15 | 3 Feet | Add to Order |
| KM-10781 | 7.812 | 7.312 | $506.30 | 3 Feet | Add to Order |
| KM-10782 | 7.875 | 7.375 | $510.53 | 3 Feet | Add to Order |
| KM-10783 | 7.937 | 7.437 | $514.68 | 3 Feet | Add to Order |
| KM-10793 | 8.000 | 7.500 | $518.90 | 3 Feet | Add to Order |
| KM-10785 | 8.062 | 7.562 | $523.05 | 3 Feet | Add to Order |
| KM-10777 | 8.125 | 7.625 | $527.28 | 3 Feet | Add to Order |
| KM-10787 | 8.187 | 7.687 | $531.43 | 3 Feet | Add to Order |
| KM-10788 | 8.250 | 7.750 | $535.63 | 3 Feet | Add to Order |
| KM-10789 | 8.312 | 7.812 | $539.78 | 3 Feet | Add to Order |
| KM-10790 | 8.375 | 7.875 | $544.00 | 3 Feet | Add to Order |
| KM-10791 | 8.437 | 7.937 | $548.15 | 3 Feet | Add to Order |
| KM-10727 | 8.500 | 8.000 | $552.38 | 3 Feet | Add to Order |
| KM-10758 | 8.625 | 8.125 | $560.75 | 3 Feet | Add to Order |
| KM-10693 | 8.687 | 8.187 | $564.90 | 3 Feet | Add to Order |
| KM-10694 | 8.750 | 8.250 | $569.10 | 3 Feet | Add to Order |
| KM-10695 | 8.812 | 8.312 | $573.25 | 3 Feet | Add to Order |
| KM-10696 | 8.875 | 8.375 | $577.48 | 3 Feet | Add to Order |
| KM-10697 | 8.937 | 8.437 | $581.63 | 3 Feet | Add to Order |
| KM-10698 | 9.000 | 8.500 | $585.85 | 3 Feet | Add to Order |
| KM-10708 | 9.062 | 8.562 | $590.00 | 3 Feet | Add to Order |
| KM-10700 | 9.125 | 8.625 | $594.23 | 3 Feet | Add to Order |
| KM-10692 | 9.187 | 8.687 | $598.38 | 3 Feet | Add to Order |
| KM-10702 | 9.250 | 8.750 | $602.60 | 3 Feet | Add to Order |
| KM-10703 | 9.312 | 8.812 | $606.75 | 3 Feet | Add to Order |
| KM-10704 | 9.375 | 8.875 | $610.95 | 3 Feet | Add to Order |
| KM-10705 | 9.437 | 8.937 | $615.10 | 3 Feet | Add to Order |
| KM-10706 | 9.500 | 9.000 | $619.32 | 3 Feet | Add to Order |
| KM-10684 | 9.562 | 9.062 | $623.47 | 3 Feet | Add to Order |
| KM-10701 | 9.625 | 9.125 | $627.70 | 3 Feet | Add to Order |
| KM-10699 | 9.687 | 9.187 | $631.85 | 3 Feet | Add to Order |
| KM-10677 | 9.750 | 9.250 | $636.08 | 3 Feet | Add to Order |
| KM-10678 | 9.812 | 9.312 | $640.22 | 3 Feet | Add to Order |
| KM-10679 | 9.875 | 9.375 | $644.43 | 3 Feet | Add to Order |
| KM-10680 | 9.937 | 9.437 | $648.58 | 3 Feet | Add to Order |
| KM-10681 | 10.000 | 9.500 | $652.80 | 3 Feet | Add to Order |
| KM-10691 | 10.062 | 9.562 | $656.95 | 3 Feet | Add to Order |
| KM-10683 | 10.125 | 9.625 | $661.18 | 3 Feet | Add to Order |
| KM-10676 | 10.187 | 9.687 | $665.33 | 3 Feet | Add to Order |
| KM-10685 | 10.250 | 9.750 | $669.55 | 3 Feet | Add to Order |
| KM-10686 | 10.312 | 9.812 | $673.70 | 3 Feet | Add to Order |
| KM-10687 | 10.375 | 9.875 | $677.90 | 3 Feet | Add to Order |
| KM-10688 | 10.437 | 9.937 | $682.05 | 3 Feet | Add to Order |
| KM-10689 | 10.500 | 10.000 | $686.28 | 3 Feet | Add to Order |
| KM-10690 | 10.562 | 10.062 | $690.43 | 3 Feet | Add to Order |
| KM-10710 | 10.625 | 10.125 | $694.65 | 3 Feet | Add to Order |
| KM-10735 | 10.687 | 10.187 | $698.80 | 3 Feet | Add to Order |
| KM-10707 | 10.750 | 10.250 | $703.03 | 3 Feet | Add to Order |
| KM-10728 | 10.812 | 10.312 | $707.18 | 3 Feet | Add to Order |
| KM-10729 | 10.875 | 10.375 | $711.40 | 3 Feet | Add to Order |
| KM-10730 | 10.937 | 10.437 | $715.55 | 3 Feet | Add to Order |
| KM-10168 | 11.000 | 10.500 | $719.75 | 3 Feet | Add to Order |
| KM-10167 | 11.062 | 10.562 | $723.90 | 3 Feet | Add to Order |
| KM-10166 | 11.125 | 10.625 | $728.13 | 3 Feet | Add to Order |
| KM-10188 | 11.187 | 10.687 | $732.28 | 3 Feet | Add to Order |
| KM-10190 | 11.250 | 10.750 | $736.50 | 3 Feet | Add to Order |
| KM-10173 | 11.312 | 10.812 | $740.65 | 3 Feet | Add to Order |
| KM-10195 | 11.375 | 10.875 | $744.88 | 3 Feet | Add to Order |
| KM-10194 | 11.437 | 10.937 | $749.03 | 3 Feet | Add to Order |
| KM-10193 | 11.500 | 11.000 | $753.23 | 3 Feet | Add to Order |
| KM-10192 | 11.562 | 11.062 | $757.38 | 3 Feet | Add to Order |
| KM-10191 | 11.625 | 11.125 | $761.60 | 3 Feet | Add to Order |
| KM-10181 | 11.687 | 11.187 | $765.75 | 3 Feet | Add to Order |
| KM-10189 | 11.750 | 11.250 | $769.98 | 3 Feet | Add to Order |
| KM-10197 | 11.812 | 11.312 | $774.13 | 3 Feet | Add to Order |
| KM-10209 | 11.875 | 11.375 | $778.35 | 3 Feet | Add to Order |
| KM-10208 | 11.937 | 11.437 | $782.50 | 3 Feet | Add to Order |
| KM-10207 | 12.000 | 11.500 | $786.70 | 3 Feet | Add to Order |
| KM-10198 | 12.062 | 11.562 | $790.88 | 3 Feet | Add to Order |
| KM-10205 | 12.125 | 11.625 | $795.07 | 3 Feet | Add to Order |
| KM-10213 | 12.187 | 11.687 | $799.23 | 3 Feet | Add to Order |
| KM-10203 | 12.250 | 11.750 | $803.45 | 3 Feet | Add to Order |
| KM-9846 | 12.312 | 11.812 | $807.60 | 3 Feet | Add to Order |
| KM-9855 | 12.375 | 11.875 | $811.83 | 3 Feet | Add to Order |
| KM-9844 | 12.437 | 11.937 | $815.97 | 3 Feet | Add to Order |
| KM-9843 | 12.500 | 12.000 | $820.20 | 3 Feet | Add to Order |
| KM-9842 | 12.562 | 12.062 | $824.35 | 3 Feet | Add to Order |
| KM-9841 | 12.625 | 12.125 | $828.55 | 3 Feet | Add to Order |
| KM-9840 | 12.687 | 12.187 | $832.70 | 3 Feet | Add to Order |
| KM-9809 | 12.750 | 12.250 | $836.93 | 3 Feet | Add to Order |
| KM-9839 | 12.812 | 12.312 | $841.08 | 3 Feet | Add to Order |
| KM-9829 | 12.875 | 12.375 | $845.30 | 3 Feet | Add to Order |
| KM-9828 | 12.937 | 12.437 | $849.45 | 3 Feet | Add to Order |
| KM-9827 | 13.000 | 12.500 | $853.68 | 3 Feet | Add to Order |
| KM-9826 | 13.062 | 12.562 | $857.83 | 3 Feet | Add to Order |
| KM-9825 | 13.125 | 12.625 | $862.03 | 3 Feet | Add to Order |
| KM-9824 | 13.187 | 12.687 | $866.18 | 3 Feet | Add to Order |
| KM-9823 | 13.250 | 12.750 | $870.40 | 3 Feet | Add to Order |
| KM-9822 | 13.312 | 12.812 | $874.55 | 3 Feet | Add to Order |
| KM-9821 | 13.375 | 12.875 | $878.78 | 3 Feet | Add to Order |
| KM-9808 | 13.437 | 12.937 | $882.93 | 3 Feet | Add to Order |
| KM-9819 | 13.500 | 13.000 | $887.15 | 3 Feet | Add to Order |
| KM-9831 | 13.562 | 13.062 | $891.30 | 3 Feet | Add to Order |
| KM-9817 | 13.625 | 13.125 | $895.50 | 3 Feet | Add to Order |
| KM-9816 | 13.687 | 13.187 | $899.68 | 3 Feet | Add to Order |
| KM-9815 | 13.750 | 13.250 | $903.88 | 3 Feet | Add to Order |
| KM-9814 | 13.812 | 13.312 | $908.03 | 3 Feet | Add to Order |
| KM-9813 | 13.875 | 13.375 | $912.25 | 3 Feet | Add to Order |
| KM-9812 | 13.937 | 13.437 | $916.40 | 3 Feet | Add to Order |
| KM-9811 | 14.000 | 13.500 | $920.63 | 3 Feet | Add to Order |
| KM-9810 | 14.062 | 13.562 | $924.78 | 3 Feet | Add to Order |
| KM-9864 | 14.125 | 13.625 | $929.00 | 3 Feet | Add to Order |
| KM-9818 | 14.187 | 13.687 | $933.15 | 3 Feet | Add to Order |
| KM-9820 | 14.250 | 13.750 | $937.35 | 3 Feet | Add to Order |
| KM-9866 | 14.312 | 13.812 | $941.50 | 3 Feet | Add to Order |
| KM-9847 | 14.375 | 13.875 | $945.73 | 3 Feet | Add to Order |
| KM-9872 | 14.437 | 13.937 | $949.88 | 3 Feet | Add to Order |
| KM-9871 | 14.500 | 14.000 | $954.10 | 3 Feet | Add to Order |
| KM-9870 | 14.562 | 14.062 | $958.25 | 3 Feet | Add to Order |
| KM-9869 | 14.625 | 14.125 | $962.48 | 3 Feet | Add to Order |
| KM-9868 | 14.687 | 14.187 | $966.63 | 3 Feet | Add to Order |
| KM-9520 | 14.750 | 14.250 | $970.82 | 3 Feet | Add to Order |
| KM-9867 | 14.812 | 14.312 | $974.98 | 3 Feet | Add to Order |
| KM-9856 | 14.875 | 14.375 | $979.20 | 3 Feet | Add to Order |
| KM-9865 | 14.937 | 14.437 | $983.35 | 3 Feet | Add to Order |
| KM-9832 | 15.000 | 14.500 | $987.57 | 3 Feet | Add to Order |
| KM-9874 | 15.062 | 14.562 | $991.73 | 3 Feet | Add to Order |
| KM-9863 | 15.125 | 14.625 | $995.95 | 3 Feet | Add to Order |
| KM-9862 | 15.187 | 14.687 | $1,000.10 | 3 Feet | Add to Order |
| KM-9861 | 15.250 | 14.750 | $1,004.33 | 3 Feet | Add to Order |
| KM-9860 | 15.312 | 14.812 | $1,008.47 | 3 Feet | Add to Order |
| KM-9859 | 15.375 | 14.875 | $1,012.68 | 3 Feet | Add to Order |
| KM-9837 | 15.437 | 14.937 | $1,016.83 | 3 Feet | Add to Order |
| KM-9836 | 15.500 | 15.000 | $1,021.05 | 3 Feet | Add to Order |
| KM-9835 | 15.562 | 15.062 | $1,025.20 | 3 Feet | Add to Order |
| KM-9834 | 15.625 | 15.125 | $1,029.43 | 3 Feet | Add to Order |
| KM-9686 | 15.687 | 15.187 | $1,033.58 | 3 Feet | Add to Order |
| KM-9858 | 15.750 | 15.250 | $1,037.80 | 3 Feet | Add to Order |
| KM-9737 | 15.812 | 15.312 | $1,041.95 | 3 Feet | Add to Order |
| KM-9590 | 15.875 | 15.375 | $1,046.15 | 3 Feet | Add to Order |
| KM-9589 | 15.937 | 15.437 | $1,050.30 | 3 Feet | Add to Order |
| KM-9310 | 16.000 | 15.500 | $1,054.53 | 3 Feet | Add to Order |
| KM-9309 | 16.062 | 15.562 | $1,058.68 | 3 Feet | Add to Order |
| KM-9308 | 16.125 | 15.625 | $1,062.90 | 3 Feet | Add to Order |
| KM-9307 | 16.187 | 15.687 | $1,067.05 | 3 Feet | Add to Order |
| KM-9306 | 16.250 | 15.750 | $1,071.28 | 3 Feet | Add to Order |
| KM-9305 | 16.312 | 15.812 | $1,075.43 | 3 Feet | Add to Order |
| KM-9304 | 16.375 | 15.875 | $1,079.63 | 3 Feet | Add to Order |
| KM-9303 | 16.437 | 15.937 | $1,083.80 | 3 Feet | Add to Order |
| KM-9340 | 16.500 | 16.000 | $1,088.00 | 3 Feet | Add to Order |
| KM-9313 | 16.562 | 16.062 | $1,092.15 | 3 Feet | Add to Order |
| KM-9315 | 16.625 | 16.125 | $1,096.38 | 3 Feet | Add to Order |
| KM-9353 | 16.687 | 16.187 | $1,100.52 | 3 Feet | Add to Order |
| KM-9352 | 16.750 | 16.250 | $1,104.75 | 3 Feet | Add to Order |
| KM-9351 | 16.812 | 16.312 | $1,108.90 | 3 Feet | Add to Order |
| KM-9350 | 16.875 | 16.375 | $1,113.13 | 3 Feet | Add to Order |
| KM-9349 | 16.937 | 16.437 | $1,117.28 | 3 Feet | Add to Order |
| KM-9348 | 17.000 | 16.500 | $1,121.48 | 3 Feet | Add to Order |
| KM-9347 | 17.062 | 16.562 | $1,125.63 | 3 Feet | Add to Order |
| KM-9069 | 17.125 | 16.625 | $1,129.85 | 3 Feet | Add to Order |
| KM-9061 | 17.187 | 16.687 | $1,134.00 | 3 Feet | Add to Order |
| KM-9054 | 17.250 | 16.750 | $1,138.23 | 3 Feet | Add to Order |
| KM-9063 | 17.312 | 16.812 | $1,142.38 | 3 Feet | Add to Order |
| KM-9064 | 17.375 | 16.875 | $1,146.60 | 3 Feet | Add to Order |
| KM-9065 | 17.437 | 16.937 | $1,150.75 | 3 Feet | Add to Order |
| KM-9066 | 17.500 | 17.000 | $1,154.95 | 3 Feet | Add to Order |
| KM-9067 | 17.562 | 17.062 | $1,159.10 | 3 Feet | Add to Order |
| KM-9087 | 17.625 | 17.125 | $1,163.33 | 3 Feet | Add to Order |
| KM-9055 | 17.687 | 17.187 | $1,167.48 | 3 Feet | Add to Order |
| KM-9078 | 17.750 | 17.250 | $1,171.70 | 3 Feet | Add to Order |
| KM-9151 | 17.812 | 17.312 | $1,175.85 | 3 Feet | Add to Order |
| KM-9119 | 17.875 | 17.375 | $1,180.07 | 3 Feet | Add to Order |
| KM-9118 | 17.937 | 17.437 | $1,184.23 | 3 Feet | Add to Order |
| KM-9117 | 18.000 | 17.500 | $1,188.43 | 3 Feet | Add to Order |
| KM-9101 | 18.062 | 17.562 | $1,192.60 | 3 Feet | Add to Order |
| KM-9115 | 18.125 | 17.625 | $1,196.80 | 3 Feet | Add to Order |
| KM-9160 | 18.187 | 17.687 | $1,200.95 | 3 Feet | Add to Order |
| KM-9113 | 18.250 | 17.750 | $1,205.18 | 3 Feet | Add to Order |
| KM-9112 | 18.312 | 17.812 | $1,209.33 | 3 Feet | Add to Order |
| KM-9111 | 18.375 | 17.875 | $1,213.55 | 3 Feet | Add to Order |
| KM-8951 | 18.437 | 17.937 | $1,217.70 | 3 Feet | Add to Order |
| KM-8944 | 18.500 | 18.000 | $1,221.93 | 3 Feet | Add to Order |
| KM-8953 | 18.562 | 18.062 | $1,226.08 | 3 Feet | Add to Order |
| KM-8954 | 18.625 | 18.125 | $1,230.28 | 3 Feet | Add to Order |
| KM-8955 | 18.687 | 18.187 | $1,234.43 | 3 Feet | Add to Order |
| KM-8956 | 18.750 | 18.250 | $1,238.65 | 3 Feet | Add to Order |
| KM-8957 | 18.812 | 18.312 | $1,242.80 | 3 Feet | Add to Order |
| KM-9053 | 18.875 | 18.375 | $1,247.03 | 3 Feet | Add to Order |
| KM-8928 | 18.937 | 18.437 | $1,251.18 | 3 Feet | Add to Order |
| KM-9045 | 19.000 | 18.500 | $1,255.40 | 3 Feet | Add to Order |
| KM-9038 | 19.062 | 18.562 | $1,259.55 | 3 Feet | Add to Order |
| KM-9047 | 19.125 | 18.625 | $1,263.75 | 3 Feet | Add to Order |
| KM-9048 | 19.187 | 18.687 | $1,267.90 | 3 Feet | Add to Order |
| KM-9049 | 19.250 | 18.750 | $1,272.13 | 3 Feet | Add to Order |
| KM-9050 | 19.312 | 18.812 | $1,276.28 | 3 Feet | Add to Order |
| KM-9051 | 19.375 | 18.875 | $1,280.50 | 3 Feet | Add to Order |
| KM-9052 | 19.437 | 18.937 | $1,284.65 | 3 Feet | Add to Order |
| KM-9030 | 19.500 | 19.000 | $1,288.88 | 3 Feet | Add to Order |
| KM-8766 | 19.562 | 19.062 | $1,293.03 | 3 Feet | Add to Order |
| KM-9029 | 19.625 | 19.125 | $1,297.25 | 3 Feet | Add to Order |
| KM-8797 | 19.687 | 19.187 | $1,301.40 | 3 Feet | Add to Order |
| KM-8557 | 19.750 | 19.250 | $1,305.60 | 3 Feet | Add to Order |
| KM-8558 | 19.812 | 19.312 | $1,309.75 | 3 Feet | Add to Order |
| KM-8559 | 19.875 | 19.375 | $1,313.98 | 3 Feet | Add to Order |
| KM-8560 | 19.937 | 19.437 | $1,318.13 | 3 Feet | Add to Order |
| KM-8561 | 20.000 | 19.500 | $1,322.35 | 3 Feet | Add to Order |
| Rev. 08-22, 04-22, 11-21, 06-21 | |||||
| Phenolic Tube Tolerances | ||||
| ↓ Inside Diameter ↓ | ||||
| Outside Diameter | Turned OD Tolerance |
Steel Mandrel |
Built-up Mandrel |
|
| 0.125" to 0.749" | ±.005" | ±.003" | - | |
| 0.750" to 1.999" | ±.005" | ±.004" | - | |
| 2.000" to 4.000" | ±.008" | ±.006" | - | |
| 4.001" - 12.000" | ±.025" ** | ±.010" | - | |
| 12.001" - 18.000" | ±.030" ** | ±.030" | ±.060" | |
| 18.001" - 24.000" | ±.035" ** | ±.040" | ±.075" | |
| 24.001" - 48.000" | ±.040" ** | ±.060" | ±.090" | |
|
** Tubes over 8.000" OD are supplied as wound, which
** Tubes turned to the following OD tolerance
|
||||
