PEEK Rods


PEEK Rods provides excellent chemical resistance combined with heat resistance to 480° F. Used in steam or boiling water applications,

 PEEK experiences no significant decline in its properties.

Applications:
  • High pressure liquid/gas chromatography parts
  • Chemical pump gears & wear plates
  • Plasma arc torch bodies
  • Insulators & connectors
  • Steam cleaning equipment
  • Automotive manual
  • Transmission thrust washers

PEEK is used in harsh applications in the Chromatography industry.

PEEK Chemical Resistance

PEEK Rods Technical Data Sheet


PEEK Rods
PEEK Rods  4 Foot Standard Lenghts
Diameter (in.) Part # Price Per Foot Order Online
0.250 KR-832 $10.62 Add to Order
0.313 KR-2122 $13.85 Add to Order
0.375 KR-208 $14.90 Add to Order
0.437 KR-5577 $20.41 Add to Order
0.500 KR-209 $21.04 Add to Order
0.562 KR-5608 $38.60 Add to Order
0.625 KR-210 $32.90 Add to Order
0.750 KR-211 $47.22 Add to Order
1.00 KR-841 $89.76 Add to Order
1.25 KR-2123 $133.02 Add to Order
1.50 KR-833 $186.94 Add to Order
1.75 KR-3367 $252.70 Add to Order
2.00 KR-213 $298.78 Add to Order
2.125 KR-5723 $404.05 Add to Order
2.25 KR-2124 $408.48 Add to Order
2.375 KR-5720 $439.31 Add to Order
2.50 KR-834 $452.71 Add to Order
2.625 KR-5722 $500.35 Add to Order
2.875 KR-5727 $598.48 Add to Order
3.00 KR-214 $615.65 Add to Order
3.50 KR-4138 $951.66 Add to Order
3.75 KR-5712 $1340.48 Add to Order
4.00 KR-835 $1627.38 Add to Order
4.25 KR-5694 $1737.62 Add to Order
4.50 KR-5609 $1796.55 Add to Order
4.75 KR-5610 $1860.21 Add to Order
5.00 KR-4152 $1822.08 Add to Order
5.25 KR-5611 $2251.85 Add to Order
5.50 KR-5612 $2605.10 Add to Order
5.75 KR-5613 $2931.94 Add to Order
6.00 KR-5614 $3271.80 Add to Order
6.50 KR-5615 $4045.88 Add to Order
7.00 KR-5616 $4716.86 Add to Order
7.50 KR-5617 $5395.02 Add to Order
Rev. 06-21
Glass Filled PEEK Rods

Technical Data

PEEK Glass Filled Rod Grey   Ketron GF30, Mil-P-46183 Type 2, Class 3
Diameter (in.) Part # Price Per Foot Order Online
.500 KR-840 $32.08 Add to Order
.625 KR-3355 $46.30 Add to Order
.750 KR-3354 $66.40 Add to Order
.875 KR-3343 $105.84 Add to Order
1.00 KR-841X $124.00 Add to Order
1.25 KR-842 $194.04 Add to Order
1.50 KR-843 $237.88 Add to Order
1.75 KR-3353 $334.07 Add to Order
2.00 KR-3352 $425.07 Add to Order
2.50 KR-2090 $679.61 Add to Order
Carbon Filled PEEK Rods
PEEK 30% Carbon Filled Rod Black, Ketron CF30

The addition of carbon fibers enhances the compressive strength and stiffness of PEEK, and dramatically lowers its expansion rate. It offers designers optimum wear resistance and load carrying capability in a PEEK-based product. This grade provides 3½ times higher thermal conductivity than unreinforced PEEK-dissipating heat from the bearing surface faster.

Technical Data
Diameter (in.) Part # Price Per Foot Order Online
0.500 KR-3351 $30.46 Add to Order
0.625 KR-837 $47.86 Add to Order
0.750 KR-3349 $68.72 Add to Order
1.000 KR-3365 $140.06 Add to Order
1.250 KR-3345 $194.00 Add to Order
1.500 KR-3346 $275.18 Add to Order
1.750 KR-3347 $439.43 Add to Order
2.00 KR-3488 $580.04 Add to Order
Rev. 06-21
