Cast
Nylon Heat Stabilized Blue Tubes
Primarily as a bearing material w/o lubrication. High heat distortion temp., excellent vibration resistance. Heat Stabilized.
Intermittent to 330 deg F, continuous -40 deg F to 230 deg F
Nylon Chemical Resistance Chart
| Nylon Cast HS Blue Nylon Tubes | ||||
| OD Inch | ID Inch | Stock Order# | Price Per 26" Length | Purchase Online |
| 2.00 | 1.00 | KM-2370 | $71.34 | Purchase |
| 2.00 | 1.50 | KM-2371 | $40.62 | Purchase |
| 2.25 | 1.25 | KM-2372 | $90.04 | Purchase |
| 2.25 | 1.50 | KM-2373 | $79.08 | Purchase |
| 2.50 | 1.00 | KM-2374 | $123.24 | Purchase |
| 2.50 | 1.50 | KM-2375 | $99.78 | Purchase |
| 2.50 | 2.00 | KM-2376 | $71.34 | Purchase |
| 3.00 | 1.00 | KM-2377 | $182.80 | Purchase |
| 3.00 | 1.50 | KM-2378 | $158.62 | Purchase |
| 3.00 | 2.00 | KM-2379 | $129.49 | Purchase |
| 3.00 | 2.50 | KM-2381 | $90.04 | Purchase |
| 3.50 | 2.00 | KM-2380 | $189.76 | Purchase |
| 4.00 | 2.00 | KM-2382 | $156.62 | Purchase |
| 4.00 | 3.00 | KM-2383 | $173.14 | Purchase |
| 4.50 | 3.50 | KM-2384 | $197.92 | Purchase |
| 5.00 | 3.00 | KM-2385 | $355.42 | Purchase |
| 5.00 | 4.00 | KM-2386 | $232.20 | Purchase |
| 6.00 | 3.00 | KM-2387 | $578.38 | Purchase |
| 6.00 | 4.00 | KM-2388 | $455.96 | Purchase |
| 6.00 | 5.00 | KM-2389 | $291.54 | Purchase |
|
Note: Sample Charges may apply on particular non stock items! |
