G11 FR5 Glass Reinforced Tubes, Rods, Sheets
G11 Glass Reinforced Epoxy
(yellow green to amber)
This grade is similar to G10/FR4, with the addition of a higher operating
temperature and some improved mechanical strength at elevated temperatures.
The main difference between NEMA Grades G11 and FR5 is that FR5 is a fire retardant grade of G11. Therefore, FR5 can be safely substituted when G11 is called for, while G11 can never be substituted where FR5 is called for. (NEMA G-11 certs to MIL-I-24768/3 GEB, IEC 60893-3 Type 2 EP GC 203; FR5 certifies to Mil-I-24768/28 GEB-F.)
G11 Technical Data
Sheet
G11 Chemical
Resistance Chart
G11 Sheets, G11 Tubes, G11 90º Angles
