CAB Tubing - Clear
Cellulosic plastics
have good optical clarity and retain their toughness across their temperature
range. Common uses include shipping tubes, laminations, and pneumatic conveyors.
This tubing is
rigid with excellent dimensional stability. Properties include ease of
fabrication, high impact strength, excellent transparency. It is strong, tough,
and durable and can be cut and sawed with standard equipment. It is not UV
resistant, is UL rated, and can be sterilized. Use acrylic cement to bond. It is
also marine and aquarium suitable. The working temp is -40 to 180 deg F. Meets
FDA standards for dry food.
Cab Tubing Chemical Resistance Chart
| Clear Extruded Cellulose Butyrate Tubes- Tenite® | |||||
| O.D. (in.) | I.D. (in.) | Wall (in.) | Part # | Price Per 6 Feet | Order Online |
|---|---|---|---|---|---|
| 0.187 | 0.125 | 0.031 | KM-5796 | $1.62 | Add to Order |
| 0.250 | 0.125 | 0.062 | KM-808 | $10.11 | Add to Order |
| 0.250 | 0.187 | 0.031 | KM-5795 | $2.43 | Add to Order |
| 0.312 | 0.188 | 0.062 | KM-809 | $12.40 | Add to Order |
| 0.312 | 0.250 | 0.031 | KM-5794 | $4.60 | Add to Order |
| 0.375 | 0.250 | 0.062 | KM-810 | $14.54 | Add to Order |
| 0.375 | 0.250 | 0.062 | KM-810-12" | $1.80 per 12" | Add to Order |
| 0.375 | 0.312 | 0.031 | KM-5799 | $3.60 | Add to Order |
| 0.437 | 0.312 | 0.062 | KM-5793 | $9.52 | Add to Order |
| 0.437 | 0.375 | 0.031 | KM-5810 | $3.95 | Add to Order |
| 0.500 | 0.250 | 0.125 | KM-811 | $28.95 | Add to Order |
| 0.500 | 0.375 | 0.062 | KM-2322 | $9.49 | Add to Order |
| 0.500 | 0.438 | 0.031 | KM-2323 | $5.04 | Add to Order |
| 0.625 | 0.375 | 0.125 | KM-812 | $38.87 | Add to Order |
| 0.625 | 0.500 | 0.062 | KM-813 | $16.23 | Add to Order |
| 0.750 | 0.500 | 0.125 | KM-814 | $46.58 | Add to Order |
| 0.750 | 0.625 | 0.062 | KM-2324 | $16.74 | Add to Order |
| 0.750 | 0.688 | 0.031 | KM-2325 | $7.81 | Add to Order |
| 0.875 | 0.750 | 0.062 | KM-5783 | $15.71 | Add to Order |
| 1.000 | 0.750 | 0.125 | KM-815 | $57.54 | Add to Order |
| 1.000 | 0.812 | 0.093 | KM-5791 | $24.34 | Add to Order |
| 1.000 | 0.875 | 0.062 | KM-2326 | $23.49 | Add to Order |
| 1.000 | 0.938 | 0.031 | KM-2327 | $10.26 | Add to Order |
| 1.125 | 1.000 | 0.062 | KM-5800 | $22.57 | Add to Order |
| 1.250 | 1.000 | 0.125 | KM-816 | $71.83 | Add to Order |
| 1.250 | 1.125 | 0.063 | KM-2328 | $25.85 | Add to Order |
| 1.250 | 1.188 | 0.031 | KM-2329 | $13.02 | Add to Order |
| 1.500 | 1.375 | 0.062 | KM-818 | $63.46 | Add to Order |
| 1.500 | 1.438 | 0.031 | KM-2331 | $15.62 | Add to Order |
| 1.750 | 1.625 | 0.063 | KM-2332 | $36.64 | Add to Order |
| 1.750 | 1.688 | 0.031 | KM-2333 | $18.97 | Add to Order |
| 2.000 | 1.750 | 0.125 | KM-817 | $82.86 | Add to Order |
| 2.000 | 1.875 | 0.062 | KM-2334 | $42.04 | Add to Order |
| 2.000 | 1.938 | 0.031 | KM-2335 | $21.20 | Add to Order |
| 2.250 | 2.000 | 0.125 | KM-5789 | $72.96 | Add to Order |
| 2.250 | 2.125 | 0.062 | KM-2336 | $47.43 | Add to Order |
| 2.250 | 2.188 | 0.031 | KM-2337 | $27.00 | Add to Order |
| 2.500 | 2.250 | 0.125 | KM-5788 | $57.12 | Add to Order |
| 2.500 | 2.375 | 0.062 | KM-2338 | $50.42 | Add to Order |
| 2.500 | 2.438 | 0.031 | KM-2339 | $23.59 | Add to Order |
| 2.750 | 2.625 | 0.062 | KM-2340 | $52.08 | Add to Order |
| 2.750 | 2.688 | 0.031 | KM-2341 | $25.79 | Add to Order |
| 3.000 | 2.875 | 0.062 | KM-2342 | $53.23 | Add to Order |
| 3.000 | 2.750 | 0.125 | KM-5787 | $76.91 | Add to Order |
| 3.000 | 2.906 | 0.047 | KM-2343 | $67.32 | Add to Order |
| 3.500 | 3.250 | 0.125 | KM-819 | $239.66 | Add to Order |
| Rev. 01-24, 04-23, 03-23, 09-22 | |||||
| Specific Gravity | 1.22 |
| Water Absorbtion @ 24 hrs | 2% |
| Tensile Strength@Yield | 7200 psi |
| Flexural Modulus | 290,000 psi |
| Notched Izod Impact | 1.3 ft/lb-in |
| Refractive Index | 1.48 |
| Transmittance | 90% |
| Haze | 8.5% |
OD/ ID Tolerance: +/-.015" to 1.0" ID, 1.00" to 2.00" ID +/-.020", 2.00" to 3.00" +/-.025", 3.00" and greater +/-.040"
