Versilon® 2475 High-Purity Tubing

  • Provides an uncompromising fluid path for sensitive solutions
  • Low sorption maintains fluid integrity
  • Plasticizer-free -- virtually no extractables
  • Environmentally friendly -- safe to dispose of through incineration
  • Documented biocompatibility to the ISO 10993 Standard
  • Meets USP Class VI, FDA and NSF criteria

Versilon® 2475 High-Purity Tubing is ideal for handling sensitive fluids such as pharmaceutical or biological solutions. There is virtually no absorption of key fluid constituents into the tubing material or fluid adsorption onto the tubing walls. As a result, fluid alteration and loss is limited. There is no plasticizer to leach into or contaminate the fluid, yet the tubing remains flexible.

Versilon® 2475 High-Purity Tubing can be sterilized by radiation, ethylene oxide, steam or chemical methods.

Frequently, incineration is used to dispose of contaminated materials. While many tubings release hazardous by-products when burned, Versilon® 2475 High-Purity Tubing only releases carbon dioxide and water when properly incinerated, providing safe disposal.

Also available with reinforcement to withstand elevated working pressure.

Versilon 2475 Technical Data

Versilon® 2475 Tubing

Previously Tygon 2275 - AER Numbers are Synonymous with new ACG Numbers

Tygon Part # Outside Diameter (in.) Inside Diameter (in.) Wall (in.) K-mac Part # Price Per 50 Feet Order Online
AER00003 0.188 0.063 0.063 KM-2952 $147.00 Add to Order
AER00007 0.250 0.125 0.063 KM-2953 $230.00 Add to Order
AER00012 0.313 0.188 0.063 KM-2954 $258.40 Add to Order
AER00017 0.375 0.250 0.063 KM-2955 $277.40 Add to Order
AER00022 0.438 0.313 0.063 KM-2956 $321.10 Add to Order
AER00027 0.500 0.375 0.063 KM-2957 $429.00 Add to Order
AER00038 0.750 0.500 0.125 KM-2958 $784.70 Add to Order
AER00046 0.875 0.625 0.125 KM-2959 $906.30 Add to Order
AER00053 1.000 0.750 0.125 KM-2960 $972.80 Add to Order
AER42064 1.375 1.000 0.188 KM-2961 $701.20 (20 feet) Add to Order
Rev. 10-23, 04-23, 09-22, 03-22
