Paper X, XX, XXX Paper Reinforced Phenolic
Paper X/XX/XXX Paper Reinforced Phenolic - natural (tan)
Composed of a paper base impregnated with a phenolic resin binder. It has good
electric strength properties with fair mechanical strength.
Outstanding for use as template material and or backup material.
Certifies to
X MIL-I-24768/12 PBM, IEC 60893-3 Type 4 PF CP 201
XX MIL-I-24768/11 PBG, IEC 60893-3 Type 4 PF CP 203
XXX MIL-I-24768/10 PBE, IEC 60893-3 Type 4 PF CP 201
NEMA grades X, XX and XXX Paper Reinforced Phenolic -- natural color is typically light tan to brown.
These grades are composed of a paper base impregnated with a phenolic resin binder. (Phenolics are the oldest, best-known general purpose thermoset resins.
They are among the lowest in cost and easiest to process.
Phenolics are quite adequate for a fair percentage of electrical applications. Generally speaking, they are not equivalent to epoxies in
resistance to moisture, humidity, dimensional stability, shrinkage and retention of electrical properties in extreme environments.)
The paper reinforced phenolic has good electric strength properties with fair mechanical strength and are
outstanding for use as template material and/or back-up material.
Click Here for X, XX, XXX Tubes or Sheets, Bars,
| X, XX, XXX Paper Reinforced Rods | |||
| Part # | Diameter (in.) | Price Per Foot | Order Online |
|---|---|---|---|
| KR-1289 | .062" | $1.37 | Add to Order |
| KR-1290 | .093" | $1.24 | Add to Order |
| KR-1291 | .125" | $1.63 | Add to Order |
| KR-1292 | .156" | $1.58 | Add to Order |
| KR-1293 | .187" | $1.80 | Add to Order |
| KR-1294 | .250" | $2.03 | Add to Order |
| KR-1295 | .312" | $2.40 | Add to Order |
| KR-1296 | .375" | $2.70 | Add to Order |
| KR-1297 | .437" | $3.48 | Add to Order |
| KR-1298 | .500" | $4.40 | Add to Order |
| KR-1299 | .562" | $5.18 | Add to Order |
| KR-1300 | .625" | $5.92 | Add to Order |
| KR-1301 | .750" | $7.90 | Add to Order |
| KR-3159 | .875" | $10.08 | Add to Order |
| KR-1302 | 1.000" | $12.92 | Add to Order |
| KR-1303 | 1.125" | $15.74 | Add to Order |
| KR-1304 | 1.250" | $20.09 | Add to Order |
| KR-1305 | 1.375" | $21.54 | Add to Order |
| KR-1306 | 1.500" | $27.90 | Add to Order |
| KR-1307 | 1.625" | $31.55 | Add to Order |
| KR-1308 | 1.750" | $38.43 | Add to Order |
| KR-1309 | 2.000" | $48.44 | Add to Order |
| Tolerances | |||
Under 1.375" Dia. |
±.001" | ||
1.375" Dia. & Over |
±.003" | ||
| Rev. 03-24, 04-23, 03-23, 04-22 | |||
| X, XX, XXX Paper Reinforced Sheets & Plates | |||||
| Part # | Thickness (in.) | Width (in.) | Length (in.) | Price | Order Online |
|---|---|---|---|---|---|
| KS-5942 | .031 | 12 | 12 | $4.93 | Add to Order |
| KS-2128 | .063 | 12 | 12 | $6.10 | Add to Order |
| KS-2135 | .094 | 12 | 12 | $7.31 | Add to Order |
| KS-2142 | .125 | 12 | 12 | $5.33 | Add to Order |
| KS-2149 | .188 | 12 | 12 | $10.96 | Add to Order |
| KS-2156 | .250 | 12 | 12 | $15.64 | Add to Order |
| KS-2163 | .313 | 12 | 12 | $16.40 | Add to Order |
| KS-2170 | .375 | 12 | 12 | $20.81 | Add to Order |
| KS-2177 | .500 | 12 | 12 | $27.77 | Add to Order |
| KS-2184 | .625 | 12 | 12 | $40.10 | Add to Order |
| KS-2191 | .750 | 12 | 12 | $68.20 | Add to Order |
| KS-2198 | 1.000 | 12 | 12 | $73.42 | Add to Order |
| KS-2205 | 1.250 | 12 | 12 | $91.78 | Add to Order |
| KS-2212 | 1.500 | 12 | 12 | $88.82 | Add to Order |
| KS-5943 | .031 | 12 | 24 | $9.86 | Add to Order |
| KS-2129 | .063 | 12 | 24 | $12.20 | Add to Order |
| KS-2136 | .094 | 12 | 24 | $14.63 | Add to Order |
| KS-2143 | .125 | 12 | 24 | $10.67 | Add to Order |
| KS-2150 | .188 | 12 | 24 | $21.92 | Add to Order |
| KS-2157 | .250 | 12 | 24 | $31.25 | Add to Order |
| KS-2164 | .313 | 12 | 24 | $32.81 | Add to Order |
| KS-2171 | .375 | 12 | 24 | $41.60 | Add to Order |
| KS-2178 | .500 | 12 | 24 | $55.51 | Add to Order |
| KS-2185 | .625 | 12 | 24 | $114.20 | Add to Order |
| KS-2192 | .750 | 12 | 24 | $138.18 | Add to Order |
| KS-2199 | 1.000 | 12 | 24 | $211.00 | Add to Order |
| KS-2206 | 1.250 | 12 | 24 | $247.22 | Add to Order |
| KS-2213 | 1.500 | 12 | 24 | $193.06 | Add to Order |
| KS-2130 | .063 | 12 | 36 | $17.91 | Add to Order |
| KS-2137 | .094 | 12 | 36 | $21.45 | Add to Order |
| KS-2151 | .188 | 12 | 36 | $32.14 | Add to Order |
| KS-2158 | .250 | 12 | 36 | $45.85 | Add to Order |
| KS-2165 | .313 | 12 | 36 | $48.11 | Add to Order |
| KS-2172 | .375 | 12 | 36 | $61.03 | Add to Order |
| KS-2179 | .500 | 12 | 36 | $81.42 | Add to Order |
| KS-2131 | .063 | 12 | 48 | $23.87 | Add to Order |
| KS-2138 | .094 | 12 | 48 | $28.60 | Add to Order |
| KS-2152 | .188 | 12 | 48 | $42.86 | Add to Order |
| KS-2166 | .313 | 12 | 48 | $64.15 | Add to Order |
| KS-2173 | .375 | 12 | 48 | $81.36 | Add to Order |
| KS-2180 | .500 | 12 | 48 | $108.55 | Add to Order |
| KS-2187 | .625 | 12 | 48 | $272.84 | Add to Order |
| KS-2194 | .750 | 12 | 48 | $338.14 | Add to Order |
| KS-2201 | 1.000 | 12 | 48 | $424.82 | Add to Order |
| KS-2208 | 1.250 | 12 | 48 | $562.90 | Add to Order |
| KS-2215 | 1.500 | 12 | 48 | $745.60 | Add to Order |
| KS-5944 | .031 | 24 | 24 | $19.27 | Add to Order |
| KS-2132 | .063 | 24 | 24 | $23.87 | Add to Order |
| KS-2139 | .094 | 24 | 24 | $28.60 | Add to Order |
| KS-2146 | .125 | 24 | 24 | $20.86 | Add to Order |
| KS-2153 | .188 | 24 | 24 | $42.86 | Add to Order |
| KS-2160 | .250 | 24 | 24 | $61.12 | Add to Order |
| KS-2167 | .313 | 24 | 24 | $64.15 | Add to Order |
| KS-2174 | .375 | 24 | 24 | $81.36 | Add to Order |
| KS-2181 | .500 | 24 | 24 | $108.55 | Add to Order |
| KS-2188 | .625 | 24 | 24 | $277.65 | Add to Order |
| KS-2195 | .750 | 24 | 24 | $261.84 | Add to Order |
| KS-2202 | 1.000 | 24 | 24 | $246.00 | Add to Order |
| KS-2209 | 1.250 | 24 | 24 | $468.46 | Add to Order |
| KS-2216 | 1.500 | 24 | 24 | $551.90 | Add to Order |
| KS-5945 | .031 | 24 | 36 | $28.27 | Add to Order |
| KS-2133 | .063 | 24 | 36 | $34.98 | Add to Order |
| KS-2140 | .094 | 24 | 36 | $41.93 | Add to Order |
| KS-2147 | .125 | 24 | 36 | $30.59 | Add to Order |
| KS-2154 | .188 | 24 | 36 | $62.84 | Add to Order |
| KS-2161 | .250 | 24 | 36 | $89.59 | Add to Order |
| KS-2168 | .313 | 24 | 36 | $94.04 | Add to Order |
| KS-2175 | .375 | 24 | 36 | $119.26 | Add to Order |
| KS-2182 | .500 | 24 | 36 | $159.12 | Add to Order |
| KS-2189 | .625 | 24 | 36 | $204.14 | Add to Order |
| KS-2196 | .750 | 24 | 36 | $275.88 | Add to Order |
| KS-2203 | 1.000 | 24 | 36 | $327.28 | Add to Order |
| KS-2210 | 1.250 | 24 | 36 | $408.30 | Add to Order |
| KS-2217 | 1.500 | 24 | 36 | $804.78 | Add to Order |
| KS-2134 | .063 | 24 | 48 | $46.63 | Add to Order |
| KS-2141 | .094 | 24 | 48 | $55.90 | Add to Order |
| KS-2148 | .125 | 24 | 48 | $40.79 | Add to Order |
| KS-2155 | .188 | 24 | 48 | $83.79 | Add to Order |
