HDPE Tubing

HDPE is more rigid and harder than low density materials and is three times better in compressive strength.  HDPE complies with FDA requirements for direct food contact applications. It is also accepted by USDA, NSF and Canadian Department of Agriculture. High Density Polyethylene plastic tubing is less flexible than LDPE, but has better physical and chemical properties, and withstands sterilization by boiling.  HDPE tubing is widely used in transporting air, water and chemicals.

HDPE Tubing - Semi Opaque White

High Density Polyethylene plastic tubing is less flexible than LDPE, but has better physical and chemical properties, and withstands sterilization by boiling. HDPE tubing is widely used in transporting air, water and chemicals. High Density Polyethylene tubing is produced from raw materials which meet FDA requirements. NSF 51/61

HDPE Tubing Technical Data Sheet

HDPE Tubing Chemical Resistance

Black Available by Request
Part # OD (in.) ID (in.) Wall (in.) Color Working PSI @73°F Price Per 100 Feet Order Online
KM-516 0.250 0.125 0.062 Natural 456 $15.30 Add to Order
KM-518 0.250 0.170 0.040 Natural 260 $12.68 Add to Order
KM-519 0.312 0.187 0.062 Natural 340 $20.43 Add to Order
KM-520 0.375 0.250 0.062 Natural 272 $25.67 Add to Order
KM-522 0.437 0.312 0.062 Natural 228 $25.53 Add to Order
KM-524 0.500 0.375 0.062 Natural 194 $35.98 Add to Order
KM-526 0.625 0.500 0.062 Natural 151 $45.32 Add to Order
KM-527 0.750 0.600 0.075 Natural 152 $38.70 Add to Order
KM-528 0.750 0.625 0.062 Natural 123 $47.65 Add to Order
KM-529 0.875 0.750 0.062 Natural 105 $60.65 Add to Order
KM-530 1.000 0.750 0.125 Natural 195 $146.50 Add to Order
KM-531 1.000 0.814 0.093 Natural 140 $148.64 Add to Order
KM-532 1.000 0.875 0.062 Natural 90 $68.83 Add to Order
KM-533 1.250 1.000 0.125 Natural 152 $188.50 Add to Order
KM-534 1.500 1.250 0.125 Natural 124 $191.08 Add to Order
KM-535 1.750 1.500 0.125 Natural 105 $224.68 Add to Order
KM-536 2.000 1.750 0.125 Natural 91 $258.08 Add to Order
KM-537 2.250 2.000 0.125 Natural 80 $291.58 Add to Order
Rev. 09-22, 03-22, 02-22, 06-21
