Acetal Delrin Tubes (Delrin®, Acetron®)
Acetal, has dimensional stability,
lower moisture acetalorption, and easier machinability than nylon, but is not as
good in slide wear. It is FDA/USDA/NSF/3A Dairy Approved, has continuous-use
temperature of 180F, and is available in three types of Acetal Tubing
(Homopolymers-Delrin, Copolymers-Acetron, Celcon.
ASTM D-4181 POM111,
21CFR177.2480, NSF61, ASTM-D-6100 S-POM111, USDA, 3A
Black POM110B44330 LD25 ASTM-D-6100 S-POM111
Delrin® Technical Data
Chemical Resistance Chart
|
Acetal Dupont Delrin® Tubes - Natural
Tolerances OD +0.050", ID -0.050" |
|||||
| O.D. (in.) | I.D. (in.) | Wall (in.) | Price Per 60" Tube | Order Online | |
|---|---|---|---|---|---|
| 0.250 | .125 | .0625 | $11.00 | Add to Order | |
| 0.500 | .250 | .125 | $30.40 | Add to Order | |
| 0.625 | .375 | .125 | $41.12 | Add to Order | |
| 0.625 | .500 | .062 | $34.30 | Add to Order | |
| 0.625 | .250 | .187 | $46.20 | Add to Order | |
| 0.750 | .250 | .250 | $67.30 | Add to Order | |
| 0.750 | .500 | .125 | $57.90 | Add to Order | |
| 0.875 | .625 | .125 | $53.80 | Add to Order | |
| 1.00 | .500 | .250 | $85.80 | Add to Order | |
| 1.125 | .625 | .250 | $90.25 | Add to Order | 10' Min Order |
| 1.25 | .500 | .375 | $105.76 | Add to Order | 10' Min Order |
| 1.25 | .750 | .250 | $93.70 | Add to Order | |
| 1.25 | 1.00 | .125 | $72.20 | Add to Order | |
| 1.50 | 1.00 | .250 | $101.20 | Add to Order | |
| 1.50 | 1.25 | .125 | $97.20 | Add to Order | |
| 1.75 | 1.25 | .250 | $152.00 | Add to Order | |
| 1.75 | 1.50 | .125 | $126.80 | Add to Order | |
| 2.00 | 1.50 | .250 | $171.60 | Add to Order | |
| 2.00 | 1.75 | .125 | $109.00 | Add to Order | |
| 2.25 | 2.00 | .125 | $136.40 | Add to Order | |
| 2.50 | 2.00 | .250 | $220.50 | Add to Order | |
|
Acetal Dupont Delrin® Tubes - Black
Tolerances OD +0.050", ID -0.050" |
|||||
| O.D. (in.) | I.D. (in.) | Wall (in.) | Part # | Price Per 60" Tube | Order Online |
|---|---|---|---|---|---|
| 0.250 | .125 | .062 | KM-28000 | $21.00 | Add to Order |
| 0.500 | .250 | .125 | KM-28001 | $55.95 | Add to Order |
| 0.625 | .250 | .187 | KM-28002 | $86.25 | Add to Order |
| 0.625 | .500 | .062 | KM-28003 | $64.05 | Add to Order |
| 0.750 | .250 | .250 | KM-28004 | $125.85 | Add to Order |
| 0.750 | .500 | .125 | KM-28005 | $111.30 | Add to Order |
| 0.875 | .625 | .125 | KM-28006 | $100.65 | Add to Order |
| 1.00 | .500 | .250 | KM-28007 | $159.00 | Add to Order |
| 1.25 | .750 | .250 | KM-28008 | $173.85 | Add to Order |
| 1.25 | 1.00 | .125 | KM-28009 | $139.35 | Add to Order |
| 1.50 | 1.00 | .250 | KM-28010 | $187.50 | Add to Order |
| 1.50 | 1.25 | .125 | KM-28011 | $180.15 | Add to Order |
| 1.75 | 1.25 | .250 | KM-28012 | $271.20 | Add to Order |
| 1.75 | 1.50 | .125 | KM-28013 | $218.85 | Add to Order |
| 2.00 | 1.50 | .250 | KM-28014 | $318.15 | Add to Order |
| 2.00 | 1.75 | .125 | KM-28015 | $202.05 | Add to Order |
| 2.25 | 2.00 | .125 | KM-28016 | $252.75 | Add to Order |
| 2.50 | 2.00 | .250 | KM-28017 | $408.60 | Add to Order |
| Rev. 04-23, 09-22, 12-21 | |||||
|
Acetal Copolymer Tubes- Natural
Standard Length 5 Feet Tolerances OD |
|||||
| O.D. (in.) | I.D. (in.) | Wall (in.) | Part # | Price Per Foot | Order Online |
|---|---|---|---|---|---|
| .250 | .125 | .063 | KM-4910 | $3.84 | Add to Order |
| .500 | .250 | .125 | KM-4909 | $13.14 | Add to Order |
| .625 | .250 | .188 | KM-4908 | $19.86 | Add to Order |
| .625 | .375 | .125 | KM-4907 | $11.94 | Add to Order |
| .625 | .500 | .063 | KM-4948 | $14.13 | Add to Order |
| .750 | .250 | .250 | KM-4918 | $28.74 | Add to Order |
| .750 | .500 | .125 | KM-4920 | $24.27 | Add to Order |
| .875 | .625 | .125 | KM-4963 | $16.14 | Add to Order |
| 1.125 | .625 | .250 | KM-4961 | $22.90 | Add to Order |
| 1.00 | .500 | .250 | KM-4962 | $34.83 | Add to Order |
| 1.25 | .500 | .375 | KM-4960 | $26.51 | Add to Order |
| 1.25 | 1.00 | .125 | KM-4958 | $30.78 | Add to Order |
| 1.50 | 1.00 | .250 | KM-4957 | $49.44 | Add to Order |
| 1.75 | 1.25 | .250 | KM-4956 | $45.60 | Add to Order |
| 1.75 | 1.50 | .125 | KM-4955 | $38.04 | Add to Order |
| 2.00 | 1.50 | .250 | KM-4954 | $66.90 | Add to Order |
| 2.00 | 1.75 | .125 | KM-4953 | $32.70 | Add to Order |
| 2.25 | 2.00 | .125 | KM-4952 | $40.92 | Add to Order |
| 2.50 | 2.25 | .125 | KM-23587 | $30.63 | Add to Order |
| 2.50 | 2.00 | .250 | KM-4951 | $66.15 | Add to Order |
| Rev. 04-23, 12-21, 06-21 | |||||
