Crystal clear for easy visual flow monitoring
Better flexibility than typical rigid fluoropolymer tubings
Chemically resistant and inert
Non-contaminating fluid path
Versilon® SE-200 Tubing Technical Data
Formerly Tygon® SE-200
**Denotes: Lead Times May Apply.
Without sacrificing the flexibility, glass-like clarity or outstanding bend radius for which Versilon® SE-200 tubing is known, Versilon® SE-200 Inert Tubing can handle many applications where flexible tubing of the past could not be used. Its FEP inner liner provides the ultimate in chemical resistance and can handle a wide variety of fluids from corrosives to MEK-based solvents. The liner is inert, meaning it will not extract or contaminate fluids being transferred. The fluid path will not impart odor or taste, making it well-suited for food and beverage use. It meets FDA criteria for food and beverage applications, as well as USP Class VI criteria for biocompatibility.
Versilon® SE-200 Inert Tubing combines all the benefits of Versilon® SE-200 with the inertness of a fluoropolymer, providing superior performance in many applications and industries.
|Tygon Part #||Outside Diameter (in.)||Inside Diameter (in.)||Wall (in.)||K-mac Part #||Price Per 50 Feet||Order Online|
|AJD00002||0.125||0.063||0.031||KM-2694**||$196.00||Add to Order|
|AJD00007||0.250||0.125||0.063||KM-2695||$257.00||Add to Order|
|AJD00012||0.313||0.188||0.063||KM-2696||$198.86||Add to Order|
|AJD00017||0.375||0.250||0.063||KM-2697||$440.58||Add to Order|
|AJD00028||0.563||0.375||0.094||KM-2698||$490.00||Add to Order|
|AJD00038||0.750||0.500||0.125||KM-2699||$864.00||Add to Order|
|AJD00053||1.00||0.750||0.125||KM-5233**||$1,082.94||Add to Order|
|Rev. 10-23, 04-23, 03-22|
