Versilon® C-210-A Precision Polyurethane Tubing
Versilon C-210-A Tubing

  • Consistently tight dimensional tolerances

  • Excellent abrasion and tear resistance

  • Fuel and lubricant resistant

  • Sub-zero temperature capabilities


Versilon® C-210-A  Precision Polyurethane Tubing
Our rigidly controlled manufacturing process makes Versilon® C-210-A Precision Polyurethane Tubing the flexible polyurethane tubing that has consistently tight tolerances from lot to lot. Precision tolerances and high elasticity provide the user with an easy, worry-free attachment to fittings. Made of a tough, ester-based polyurethane, Versilon® C-210-A Precision Polyurethane Tubing's clarity, high tear strength and excellent abrasion resistance make it ideal for many applications, including fuel and lubricant lines, pneumatic lines, abrasive product transfer and cable jacketing. It also offers exceptional resistance to oils, greases, fuels and many chemicals.

Able to withstand rugged daily use, Versilon® C-210-A Precision Polyurethane Tubing resists weathering and can be safely used in temperatures ranging from -100°F (-73°C) to 200°F (93°C). It meets FDA criteria for food and beverage use and is also available in ether-based, medical grade and reinforced formulations.

Versilon® C-210-ATubing Technical Data

Versilon® C-210-A Precision Polyurethane Tubing
Was Tygothane C-210-A
Versilon Part #

Outside Diameter Inches

Inside Diameter Inches

Wall Inches

Stock #

Price/Coil  100 Feet

Purchase Online
AEM02002

0.125

0.063

0.031

KM-2816

$37.40

Purchase
AEM02006

0.188

0.125

0.031

KM-2817

$48.00

Purchase
AEM02007

0.250

0.125

0.063

KM-2818

$52.20

Purchase
AEM02011

0.250

0.188

0.031

KM-2819

$67.10

Purchase
AEM02012

0.313

0.188

0.063

KM-2820

$115.40

Purchase
AEM02013

0.375

0.188

0.094

KM-2821

$235.40

Purchase
AEM02016

0.313

0.250

0.031

KM-2822

$120.80

Purchase
AEM02017

0.375

0.250

0.063

KM-2823

$141.00

Purchase
AEM02018

0.438

0.250

0.094

KM-2824

$278.90

Purchase
AEM02019

0.500

0.250

0.125

KM-2825

$375.80

Purchase
AEM02022

0.438

0.313

0.063

KM-2826

$203.90

Purchase
AEM02027

0.500

0.375

0.063

KM-2827

$182.50

Purchase
AEM02028

0.563

0.375

0.094

KM-2828

$256.10

Purchase
AEM02029

0.625

0.375

0.125

KM-2829

$373.70

Purchase
AEM02033

0.625

0.438

0.094

KM-2830

$328.80

Purchase
AEM02034

0.688

0.438

0.125

KM-2831

$425.20

Purchase
AEM02036

0.625

0.500

0.063

KM-2832

$242.80

Purchase
AEM02037

0.688

0.500

0.094

KM-2833

$344.00

Purchase
AEM02038

0.750

0.500

0.125

KM-2834

$453.60

Purchase
AEM02044

0.750

0.625

0.063

KM-2835

$298.10

Purchase
AEM02045

0.813

0.625

0.094

KM-2836

$457.50

Purchase
AEM02046

0.875

0.625

0.125

KM-2837

$525.70

Purchase
AEM02052

0.938

0.750

0.094

KM-2838

$519.60

Purchase
AEM02053

1.000

0.750

0.125

KM-2839

$595.10

Purchase
AEM02059

1.125

0.875

0.125

KM-2840

$738.00

Purchase
AEM02062

1.250

1.000

0.125

KM-2841

$773.20

Purchase
