Cast Oil Filled Nylon Rod

Nylon Oil Filled Rod- This highly stable nylon provides a continuously lubricated surface. Features enhanced wear characteristics. Underwriters Laboratories (UL) Ratings.

Oil Filled Nylon was developed to extend the wear-resistant properties of unlubricated or dry lubricated materials such as MoS2 filled nylons. Will last 5 to 7 times longer than unlubricated or MoS2 dry lubricated cast nylons. Lubrication results in 25% lower coefficient of friction. Exhibit more dimensional stability due to reduced moisture absorption. Internal lubricant provides for faster and easier machining than other nylons.


 Green Oil Filled Nylon Rods

Oil Filled Nylon Rod Technical Data
Cast Nylon Oil Filled Rod

Green Color

Diameter Inches Stock Order# Price Per Foot Purchase Online
1.00 KR-1469 $19.00 Purchase
1.25 KR-1470 $30.00 Purchase
1.50 KR-1471 $38.50 Purchase
1.75 KR-1472 $50.00 Purchase
2.00 KR-1449 $65.00 Purchase
2.25 KR-5310 $83.50 Special Order
2.50 KR-1473 $93.90 Purchase
2.75 KR-5311 $120.00 Special Order
3.00 KR-1450 $140.00 Purchase
3.25 KR-5360 $145.40 Purchase
3.50 KR-5348 $159.20 Purchase
3.75 KR-5362 $185.10 Purchase
4.00 KR-1450A $260.00 Purchase
4.25 KR-5363 $231.60 Purchase
4.50 KR-5364 $260.00 Purchase
4.75 KR-5365 $285.20 Purchase
5.00 KR-1451 $390.00 Purchase
5.25 KR-5366 $140.92 Purchase
5.50 KR-5367 $150.12 Purchase
5.75 KR-5368 $168.44 Purchase
6.00 KR-1452 $224.00 Purchase
6.25 KR-1452Q $260.64 Special Order
6.50 KR-5369 $213.40 Purchase
6.75 KR-5370 $228.84 Purchase
7.00 KR-5371 $244.96 Purchase
7.25 KR-5336 $263.72 Purchase
7.50 KR-5334 $279.84 Purchase
7.75 KR-5359 $300.64 Purchase
8.00 KR-1474 $400.00 Purchase
9.00 KR-1475 $375.00 Purchase
9.25 KR-5481 $324.81 Special Order - 3 Ft Std Length
10.00 KR-1476 $450.00 Purchase
11.00 KR-1477 $555.00 Purchase
11.75 KR-5475 $533.52 Special Order - 3 Ft Std Length
12.00 KR-1478 $645.00 Purchase
13.00 KR-5491 $657.66 Special Order - 3 Ft Std Length
13.50 KR-5492 $704.64 Special Order - 3 Ft Std Length
13.75 KR-5493 $736.83 Special Order - 3 Ft Std Length
14.00 KR-5494 $781.74 Special Order - 3 Ft Std Length
16.00 KR-1479 $1200.00 Purchase
20.00 KR-1480 $1800.00 Purchase


Oil filled Nylon Technical Data

Density  Tensile
Strength
Compressive
Strength
Shore
Hardness
Coefficient
of Friction
Continuous
Operating Temp
Wear
Resistance
Index
g/cm3 N/mm2 N/mm2 'D' Scale Sample
on Steel
oC Units
1.12 65-70 85-100 80-85 0.10
0.13
-80
+125
25


Note:  Shipping charges will apply to all orders, and will vary depending on Customer ship to location, pricing does not reflect shipping charges
