Polycarbonate Lexan® 9034 Sheets
In thicknesses of .125", Lexan® 9034 sheet will transmit 86% of the light. Lexan® 9034 Sheet is UV stabilized, has a heat deflection temperature of 270 degrees F at 264 PSI, and has a smoke density rating less than 75. Lexan® 9034 Sheet is engineered for window glazing as well as for sign applications. In addition to colorless (clear), Lexan® 9034 is available in solar gray and bronze in thicknesses from .080" to .500".
Lexan® 9034 uncoated polycarbonate sheet is the standard grade of Lexan® sheet for general purpose applications. High-impact Lexan® 9034 can be used for economical protection against breakage or intrusion. A better insulator than glass, it contributes to lower energy costs.
Lexan 9034 Sheet Technical Data
Lexan 9034 Chemical Resistance Chart
| Lexan® Transparent Grey | Lexan® Transparent Bronze |
| Actual Colors may appear different than shown due to different monitor setting. | |
| Polycarbonate Lexan® 9034 Sheet | ||||||
|
Standard tolerances estimated +/-10%.
Full Sheets Must Ship By Truck **Note: All Sheets larger than 48" x 48" Ship Via Truck.** |
||||||
| Thickness (in.) | Length (in.) | Width (in.) | Color | Part # | Price | Order Online |
|---|---|---|---|---|---|---|
| .062 | 48 | 96 | Clear | KS-9377 | $302.72 | Add to Order |
| .094 | 48 | 96 | Clear | KS-5128Q | $411.60 | Add to Order |
| .125 | 48 | 96 | Translucent Bronze | KS-2595 | $974.50 | Add to Order |
| .125 | 48 | 96 | Translucent Grey | KS-2590 | $1,138.34 | Add to Order |
| .125 | 48 | 96 | Clear | KS-6111 | $479.22 | Add to Order |
| .188 | 48 | 96 | Translucent Bronze | KS-2597 | $1,416.32 | Add to Order |
| .188 | 48 | 96 | Clear | KS-6112 | $723.32 | Add to Order |
| .188 | 48 | 96 | Translucent Grey | KS-2591 | $1,505.50 | Add to Order |
| .250 | 48 | 96 | Translucent Grey | KS-2592 | $1,579.22 | Add to Order |
| .250 | 48 | 96 | Clear | KS-6114 | $882.00 | Add to Order |
| .250 | 48 | 96 | Translucent Bronze | KS-2596 | $1,515.90 | Add to Order |
| .375 | 48 | 96 | Clear | KS-6113 | $1,580.24 | Add to Order |
| Rev. 10-23, 05-22, 07-21, 06-21 | ||||||
Lexan® 9034 sheet
Approved plastic
material for light transmitting applications.
Minimum thickness 2mm,
Burglary resisting.
Glazing Standard 972.
Minimum thickness 2mm
Meets safety standard for architectural glazing materials categories I & II
| CC 1/ASTM D635 |
| CC-2/ASTM D635 |
| Urban Mass Transit Admin. flammability and smoke guidelines |
