Graphite Bars / Sheets

Graphite Bars

Extruded Coarse Graphite Bars/Plates
  • Density:  1.55 g/cm³
  • Particle Size:  .25 in
  • Flexural Strength:  1200 PSI
  • Resistivity:  3.0 ohm/in 10 -4
  • Compressive Strength:  4000 PSI
  • CTE:  .0003 ohm/in
  • Operating Temp:  750°F
  • Porosity:  25%
Thickness Inch Width (in.) Length (in.) Part # Price Each Order Online
1.00 6.00 6.00 KBS-3912 $85.56 Add to Order
1.00 6.00 12.00 KBS-3910 $126.63 Add to Order
1.00 6.00 24.00 KBS-3945 $186.36 Add to Order
1.00 6.00 36.00 KBS-3800 $246.21 Add to Order
1.00 6.00 48.00 KBS-3816 $317.10 Add to Order
1.00 6.00 72.00 KBS-3817 $447.84 Add to Order
1.00 12.00 72.00 KBS-3903 $728.76 Add to Order
1.00 24.00 48.00 KBS-3914 $823.35 Add to Order
1.00 12.00 18.00 KBS-3810 $196.17 Add to Order
1.00 12.00 24.00 KBS-3795 $317.10 Add to Order
1.00 12.00 36.00 KBS-3796 $392.19 Add to Order
1.00 12.00 48.00 KBS-3904 $522.93 Add to Order
2.00 6.00 6.00 KBS-3948 $104.37 Add to Order
2.00 6.00 12.00 KBS-3949 $164.10 Add to Order
2.00 6.00 24.00 KBS-3950 $261.48 Add to Order
2.00 6.00 36.00 KBS-3686 $358.83 Add to Order
2.00 6.00 48.00 KBS-3815 $467.31 Add to Order
2.00 6.00 72.00 KBS-3814 $673.14 Add to Order
Rev. 11-21




Isomolded - Superfine Ground Finish Carbon Fiber Bars
  • Density 1.82 g/cm³
  • Particle Size: .0004"
  • Compressive Strength:  17,000 PSI
  • Flexural Strength:  8,500 PSI
  • Resistivity:  .00055 ohm/in
  • CTE:  2.5 in/in/F 10 -6
  • Operating Temp:  800°F
  • Porosity:  9%
  • Thermal Conductivity:  48 BTU/(h.ft 2 °F/ft)
Part # Thickness (in.) Thicknes Tol. Width (in.) Width Tol Length (in.) Length Tol Price Each Order Online
KBS-3813 .125 +/-.001 4.0 +/-.005 4.00 +/-.005 $26.34 Add to Order
KBS-3812 .125 +/-.001 4.0 +/-.005 6.00 +/-.005 $39.81 Add to Order
KBS-3811 .125 +/-.001 6.0 +/-.005 6.00 +/-.005 $57.78 Add to Order
KBS-3767 .125 +/-.001 12.0 +/-.005 12.00 +/-.005 $170.79 Add to Order
KBS-3747 .187 +/-.001 4.0 +/-.005 4.00 +/-.005 $31.20 Add to Order
KBS-3749 .187 +/-.001 4.0 +/-.005 6.00 +/-.005 $46.47 Add to Order
KBS-3777 .187 +/-.001 6.0 +/-.005 6.00 +/-.005 $66.96 Add to Order
KBS-3775 .187 +/-.001 12.0 +/-.005 12.00 +/-.005 $203.85 Add to Order
KBS-3774 .250 +/-.001 4.0 +/-.005 4.00 +/-.005 $37.14 Add to Order
KBS-3712 .250 +/-.001 4.0 +/-.005 6.00 +/-.005 $35.46 Add to Order
KBS-3733 .250 +/-.001 6.0 +/-.005 6.00 +/-.005 $51.28 Add to Order
KBS-3734 .250 +/-.001 12.0 +/-.005 12.00 +/-.005 $158.40 Add to Order
KBS-3731 .312 +/-.001 4.0 +/-.005 6.00 +/-.005 $59.49 Add to Order
KBS-3732 .312 +/-.001 4.0 +/-.005 4.00 +/-.005 $40.50 Add to Order
KBS-3730 .312 +/-.001 6.0 +/-.005 6.00 +/-.005 $57.78 Add to Order
KBS-3728 .312 +/-.001 12.0 +/-.005 12.00 +/-.005 $270.69 Add to Order
KBS-3738 .375 +/-.001 4.0 +/-.005 4.00 +/-.005 $44.97 Add to Order
KBS-3726 .375 +/-.001 4.0 +/-.005 6.00 +/-.005 $66.15 Add to Order
KBS-3725 .375 +/-.001 6.0 +/-.005 6.00 +/-.005 $96.03 Add to Order
KBS-3723 .375 +/-.001 12.0 +/-.005 12.00 +/-.005 $304.11 Add to Order
KBS-3720 .435 +/-.001 6.0 +/-.005 6.00 +/-.005 $70.80 Add to Order
KBS-3722 .437 +/-.001 4.0 +/-.005 4.00 +/-.005 $49.83 Add to Order
KBS-3721 .437 +/-.001 4.0 +/-.005 6.00 +/-.005 $72.87 Add to Order
KBS-3737 .437 +/-.001 12.0 +/-.005 12.00 +/-.005 $337.20 Add to Order
KBS-3685 .500 +/-.001 4.0 +/-.005 6.00 +/-.005 $53.02 Add to Order
KBS-3708 .500 +/-.001 4.0 +/-.005 4.00 +/-.005 $54.27 Add to Order
KBS-3684 .500 +/-.001 6.0 +/-.005 6.00 +/-.005 $76.78 Add to Order
KBS-3709 .500 +/-.001 12.0 +/-.005 12.00 +/-.005 $247.30 Add to Order
KBS-3736 .750 +/-.001 4.0 +/-.005 4.00 +/-.005 $72.51 Add to Order
KBS-3713 .750 +/-.001 4.0 +/-.005 6.00 +/-.005 $106.32 Add to Order
KBS-3715 .750 +/-.001 6.0 +/-.005 6.00 +/-.005 $153.78 Add to Order
KBS-3803 .750 +/-.001 12.0 +/-.005 12.00 +/-.005 $504.24 Add to Order
KBS-3804 1.000 +/-.001 4.0 +/-.005 4.00 +/-.005 $91.14 Add to Order
KBS-3805 1.000 +/-.001 4.0 +/-.005 6.00 +/-.005 $88.48 Add to Order
KBS-3806 1.000 +/-.001 6.0 +/-.005 6.00 +/-.005 $128.02 Add to Order
KBS-3819 1.000 +/-.001 12.0 +/-.005 12.00 +/-.005 $425.26 Add to Order
Rev. 11-21
