Bullet Proof Sheets



HYGARD® Makrolon® Polycarbonate Bullet Resistant Sheet

Lead Times May Apply, Call for Volume Discounts



CG375  3/16" Makrolon® GP Interlayer, 3/16" Makrolon® AR Outerlayer (2.4 lbs/SF) Guage .390 (+/-5%)

CG375 HPW Level II Step 10, HPW TP0500.02 Level A Ballistics (.38 Special)  ASTM F 1233 Class III Step 12

CG500  1/8" Makrolon® AR Interlayer,  1/4" Makrolon® GP, 1/8" Makrolon® AR Outerlayer (3.3 lbs/SF) Guage .530 (+/-5%)

CG500 HPW Level II Step 12, HPW TP0500.02 Level A Ballistics (.38 Special)  ASTM F 1233 Class III Step 15

CG750 1/8" Makrolon® AR Interlayer,  1/4" Makrolon® GP, 1/8" Makrolon® AR Outerlayer (4.9 lbs/SF) Guage .780 (+/-5%)

CG750 HPW Level IV Step 31, HPW TP0500.02 Level B Ballistics (9 MM)  ASTM F 1233 Class IV Step 26

BR750 1/8" Makrolon® AR Interlayer,  1/2" Makrolon® GP, 1/8" Makrolon® AR Outerlayer (5.1 lbs/SF) Guage .775 (+/-8%)

BR750  UL Level 1, HPW TP0500.02 Level B Ballistics (9 MM)

BR1000  1/8" Makrolon® AR Interlayer,  3/8" Makrolon® GP, 3/8" Makrolon® GP, (Double Layer), 1/8" Makrolon® AR Outerlayer (6.5 lbs/SF) Guage 1.05 (+/-5%)

BR1000 HPW Level V Step 42, HPW TP0500.02 Level B Ballistics (9 MM)  ASTM F 1233 Class V UL Level 2

BR1250  1/8" Makrolon® AR Interlayer,  1/2" Makrolon® GP, 1/2" Makrolon® GP, (Double Layer), 1/8" Makrolon® AR Outerlayer (8.1 lbs/SF) Guage 1.30 (+/-5%)

BR1250 HPW Level V, HPW TP0500.02 Level C Ballistics (.44 Magnum)  ASTM F 1233 Class IV Step 38 UL Level 3

Sheet Size Part # Color CG/BR Series Price Each Order Online
.390" x 38" x 96" KS-3942 Clear CG375 $4,216.38 Add to Order
.390" x 48" x 96" KS-3954 Clear CG375 $5,326.62 Add to Order
.390" x 60" x 96" KS-3960 Clear CG375 $6,658.20 Add to Order
.530" x 38" x 96" KS-3943 Clear CG500 $4,809.06 Add to Order
.530" x 48" x 96" KS-3955 Clear CG500 $6,075.42 Add to Order
.530" x 60" x 96" KS-3961 Clear CG500 $7,594.26 Add to Order
.780" x 38" x 96" KS-3944 Clear CG750 $6,821.76 Add to Order
.780" x 48" x 96" KS-3956 Clear CG750 $8,618.04 Add to Order
.780" x 60" x 96" KS-3962 Clear CG750 $10,772.58 Add to Order
.780" x 12" x 12" KS-1448 Clear BR750 $257.29 Add to Order
.780" x 24" x 24" KS-1450 Clear BR750 $992.41 Add to Order
.780" x 24" x 48" KS-1451 Clear BR750 $1,704.24 Add to Order
.780" x 38" x 78" KS-3938 Clear BR750 $6,195.18 Add to Order
.780" x 38" x 96" KS-3945 Clear BR750 $7,625.04 Add to Order
.780" x 48" x 60" KS-3948 Clear BR750 $6,020.58 Add to Order
.780" x 48" x 72" KS-3951 Clear BR750 $7,366.00 Add to Order
.780" x 48" x 96" KS-3957 Clear BR750 $9,820.00 Add to Order
.780" x 60" x 96" KS-3963 Clear BR750 $12,041.16 Add to Order
1.05" x 38" x 78" KS-3940 Clear BR1000 $9,204.54 Add to Order
1.05" x 38" x 96" KS-3946 Clear BR1000 $11,329.02 Add to Order
1.05" x 48" x 60" KS-3949 Clear BR1000 $8,945.16 Add to Order
1.05" x 48" x 72" KS-3952 Clear BR1000 $10,734.18 Add to Order
1.05" x 48" x 96" KS-3958 Clear BR1000 $12,376.00 Add to Order
1.05" x 60" x 96" KS-3964 Clear BR1000 $17,890.26 Add to Order
1.30" x 12" x 24" KS-1455 Clear BR1250 $828.38 Add to Order
1.30" x 24" x 24" KS-1456 Clear BR1250 $1,463.45 Add to Order
1.30" x 24" x 48" KS-1457 Clear BR1250 $2,209.48 Add to Order
1.30" x 38" x 78" KS-3941 Clear BR1250 $9,393.30 Add to Order
1.30" x 38" x 96" KS-3947 Clear BR1250 $11,561.34 Add to Order
1.30" x 48" x 60" KS-3950 Clear BR1250 $9,128.58 Add to Order
1.30" x 48" x 72" KS-3953 Clear BR1250 $10,954.26 Add to Order
1.30" x 48" x 96" KS-3959 Clear BR1250 $15,118.00 Add to Order
1.30" x 60" x 96" KS-3965 Clear BR1250 $18,257.16 Add to Order
Rev. 05-22, 06-21







HYGARD® BR-750

HYGARD® BR-750 is a three ply HYZOD® polycarbonate and acrylic laminate for security applications that require UL Listed Level I bullet resisting glazing. HYGARD® BR-750 features abrasion and UV resistant surfaces for extended service life in harsh environments.

APPLICATIONS

HYGARD® BR-750 is used as bullet-resistant glazing in a wide variety of security applications. Installations include convenience stores, specialty retailers, banks government and detention facilities, as well as other cash transaction areas.

GLAZING INFORMATION

Use of structural security framing systems with equal or greater forced entry and/or ballistics ratings as the selected HYGARD® Laminate is recommended.

Size HYGARD® laminates to allow for a minimum of one (1) inch edge engagement in the frame with sufficient rabbet depth for material expansion (approx. 1/16”/ft.).

Use wet or dry sealants/gaskets that are compatible with polycarbonate.

Remove protective masking after glazing operations are completed and before prolonged exposure to direct sunlight, moisture, or high temperature.

PRODUCT SPECIFICATION

HYGARD® BR-750 polycarbonate laminate:

Three ply, clear HYZOD® polycarbonate and acrylic sheet constructed as follows:

  1. 1/8” HYZOD® with high performance AR abrasion-resistant surface

  2. ½” acrylic sheet

  3. 1/8” HYZOD® with high performance AR abrasion-resistant surface

Material shall have a flexural strength of at least 13,500 psi per ASTM D-790; and shall have AR (high performance abrasion-resistant) surfaces for enhanced service life and resistance to marring. Material shall exhibit a self ignition temperature of 1077ºF and a flash ignition temperature of 872ºF (ASTM D-1929), and conform with ICBO & BOCA Model Building Codes as a CC-2 rated Approved Light Transmitting Plastic.

HYGARD® BR1000

HYGARD® BR-1000 is a four-ply HYZOD® polycarbonate laminate for use in security applications that require UL Listed Level 2 bullet-resisting glazing. HYGARD® BR-1000 is hard coated with abrasion and UV resistant surfaces for extended service life in harsh environments.

APPLICATIONS

HYGARD® BR-1000 is used as containment and bullet-resistant glazing in a wide variety of high level security applications. Installations include 24-hour convenience stores, specialty retailers, banks, governmental and detention facilities, as well as other cash transaction areas.

FORCED ENTRY, BALLISTICS RATINGS

HP White TP-500.02 Level V Sequence 42

HP White TP-500.02 Level B Ballistics (9mm)

ASTM F1233 Class V

ASTM F-1233 Ballistics (.38 Super)

UL 752 Level 2 HPSA (.357 Mag)

GLAZING INFORMATION

Use of structural security framing systems with equal or greater forced entry and/or ballistics ratings as the selected HYGARD® Laminate is recommended.

Size HYGARD® laminates to allow for a minimum of one (1) inch edge engagement in the frame, with sufficient rabbet depth for material expansion (approx. 1/16”/ft.).

Use wet or dry sealants/gaskets that are compatible with polycarbonate.

Remove protective masking after glazing operations are completed and before prolonged exposure to direct sunlight, moisture, or high temperature.

PRODUCT SPECIFICATION

Four ply, clear HYZOD® polycarbonate sheet constructed as follows:

  1. 1/8” HYZOD® with high performance AR abrasion-resistant surface

  2. 3/8” HYZOD® polycarbonate sheet

  3. 3/8” HYZOD® polycarbonate sheet

  4. 1/8” HYZOD® with high performance AR abrasion-resistant surface

Material shall have a flexural strength of at least 13,500 psi per ASTM D-790; and shall have AR (high performance abrasion-resistant) surfaces for enhanced service life and resistance to marring. Material shall conform with ICBO & BOCA Model Building Codes as a CC-1 rated Approved Light Transmitting Plastic.


HYGARD® BR-1250

HYGARD® BR-1250 is a fourply HYZOD® polycarbonate laminate for use in security applications that require UL Listed Level III bullet-resisting glazing. HYGARD® BR-1250 is hard coated with abrasion and UV resistant surfaces for extended service life in harsh environments.

APPLICATIONS

HYGARD® BR-1250 is used as containment and bullet resistant glazing in a wide variety of high level security applications. Installations include 24 hour convenience stores, specialty retailers, banks, governmental and detention facilities, as well as other cash transaction areas.

GLAZING INFORMATION

Use of structural security framing systems with equal or greater forced entry and/or ballistics ratings as the selected HYGARD® Laminate is recommended.

Size HYGARD® laminates to allow for a minimum of one (1) inch edge engagement in the frame, with sufficient rabbet depth for material expansion (approx. 1/16”/ft.).

Use wet or dry sealants/gaskets that are compatible with polycarbonate.

Remove protective masking after glazing operations are completed and before prolonged exposure to direct sunlight, moisture, or high temperature.

PRODUCT SPECIFICATION

HYGARD® BR-1250 polycarbonate laminate:

Four ply, clear HYZOD® polycarbonate sheet constructed as follows:

  1. 1/8” HYZOD® with high performance AR abrasion-resistant surface

  2. ½��� HYZOD® polycarbonate sheet

  3. ½” HYZOD® polycarbonate sheet

  4. 1/8” HYZOD® with high performance AR abrasion-resistant surface

Material shall have a flexural strength of at least 13,500 psi per ASTM D-790; and shall have AR (high performance abrasion-resistant) surfaces for enhanced service life and resistance to marring. Material shall exhibit a self ignition temperature of 1077ºF and a flash ignition temperature of 872ºF (ASTM D-1929), and conform with ICBO & BOCA Model Building Codes as a CC-1 rated Approved Light Transmitting Plastic.



Call K-mac Plastics for Current Pricing
