440SS (Stainless Steel Balls)

440 Stainless Steel Balls



Stainless Steel Type 440 C Balls

AISI type 440-C stainless steel balls afford the advantage of maximum hardness combined with corrosion-resisting properties. This hardness, together with precise geometry and fine surface finish, makes them especially useful for bearing and valve applications where severe environmental conditions may occure.

Consumable electrode vacuum meleted (CEVM) and vacuum induction melted/vacuum arc remelted (VIM-MAR) materials are available upon request.

440 SS Stainless Steel Balls
Stock # Grade # Diameter Pkg Qty.  Price/Pkg Order
KB-1647 100 0.062 100 $29.97 Order
KB-1648 100 0.094 100 $35.82 Order
KB-713 100 0.094 5000 $433.80 Order
KB-1649 100 0.125 100  $26.96 Order
KB-315 100 0.125 35000 $1953.00 Order
KB-1650 100 0.156 100 $29.43 Order
KB-371 100 0.156 15000 $1863.00 Order
KB-1634 100 0.187 100 $34.20 Order
KB-382 100 0.187 10000 $776.25 Order
KB-349 100 0.218 6400 $1154.88 Order
KB-1727 100 0.218 100 $31.95 Order
KB-1691 100 0.250 100 $47.48 Order
KB-356 100 0.250 4350 $953.50 Order
KB-573 100 0.281 3000 $1081.35 Order
KB-1738 100 0.281 100 $57.42 Order
KB-1694 100 0.250 50 $58.19 Order
KB-571 100 0.312 2200 $830.61 Order
KB-1739 100 0.312 100 $67.01 Order
KB-1690 100 0.343 50 $58.19 Order
KB-1678 100 0.343 100 $40.46 Order
KB-593 100 0.343 1650 $1048.16 Order
KB-1696 100 0.375 50 $92.50 Order
KB-620 100 0.375 1300 $939.63 Order
KB-1697 100 0.437 25 $70.97 Order
KB-627 100 0.437 810 $895.28 Order
KB-601 100 0.469 660 $763.50 Order
KB-1698 100 0.500 25 $99.32 Order
KB-599 100 0.500 550 $807.44 Order
KB-1699 100 0.562 25 $86.49 Order
KB-606 100 0.562 380 $750.69 Order
KB-1701 100 0.625 10 $69.39 Order
KB-530 100 0.625 275 $727.25 Order
KB-1708 100 0.687 10 $79.83 Order
KB-490 100 0.687 200 $1001.07 Order
KB-1707 100 0.750 10 $85.68 Order
KB-507 100 0.750 160 $903.02 Order
KB-1706 100 0.812 5 $64.58 Order
KB-502 100 0.812 125 $1797.30 Order
KB-1704 100 0.875 5 $80.10 Order
KB-496 100 0.875 100 $1613.25 Order
KB-1700 100 0.938 5 $86.54 Order
KB-473 100 0.938 80 $1537.86 Order
KB-479 100 1.000 65 $1569.75 Order
KB-1944 100 1.000 3 $66.85 Order
KB-485 100 1.062 55 $1418.18 Order
KB-1945 100 1.062 3 $73.70 Order
KB-533 100 1.125 40 $1132.20 Order
KB-539 100 1.187 35 $1204.00 Order
KB-545 100 1.250 30 $1195.50 Order
KB-1930 100 1.250 Each $48.45 Order
KB-538 100 1.312 25 $1110.38 Order
KB-514 100 1.375 25 $1201.25 Order
KB-520 100 1.437 20 $999.00 Order
KB-526 100 1.500 20 $1028.70 Order
KB-1968 100 1.500 Each $65.61 Order
KB-1419 100 1.625 15 $1183.50 Order
KB-1437 100 1.687 10 $904.50 Order
KB-1431 100 1.750 9 $824.40 Order
KB-1399 100 1.875 8 $906.00 Order
KB-705 100 2.000 6 $997.20 Order
KB-1990 100 2.000 Each $157.70 Order
KB-675 100 2.250 4 $1107.80 Order
KB-691 100 2.375 Each $340.80 Order
KB-944 100 2.500 3 $1152.75 Order
KB-909 100 3.000 2 $1603.00 Order
KB-914 100 3.500 Each $1147.80 Order
KB-919 100 4.000 Each $1979.30 Order
KB-1426 100 1.687 10 $904.50 Order


Stainless Steel 440-C Balls:   Available Grades and Sizes

Precision Stainless Steel 440-C Balls

Grade

Size Range in Inches and Millimeters

10

3/16 - 1 1/4                         4.762 - 31.750

16

3/16 - 1 1/4                         4.762 - 31.750

24

3/16 - 2                               4.762 - 50.800

48

3/16 - 2                               4.762 - 50.800

100

1/8 - 4 1/2                          3.175 - 114.300

200

1/8 - 4 1/2                          3.175 - 114.300

1000

1/8 - 4 1/2                          3.175 - 114.300

Media

1/8 - 3/4                              3.175 - 19.050

Balls per Pound

Size

Balls per Pound

Inches

Millimeters

1/32

0.793

226,000

3/64

1.190

66,900

1/16

1.587

28,500

3/32

2.381

8,300

1/8

3.175

3,530

5/32

3.968

1,800

3/16

4.762

1,050

7/32

5.556

659

1/4

6.350

441

9/32

7.143

310

5/16

7.937

226

11/32

8.731

170

3/8

9.525

131

7/16

11.112

82.3

1/2

12.700

55.2

9/16

14.287

38.7

5/8

15.875

28.2

11/16

17.462

21.2

3/4

19.050

16.3

13/16

20.637

12.9

7/8

22.225

10.3

15/16

23.812

8.37

1

25.400

5.89

1 1/16

26.987

5.75

1 1/8

28.575

4.84

1 3/16

30.162

4.12

Balls per Pound

Size

Balls per Pound

Inches

Millimeters

1 1/4

31.750

3.53

1 5/16

33.337

3.05

1 3/8

34.925

2.65

1 7/16

36.512

2.32

1 1/2

38.100

2.04

1 9/16

39.687

1.81

1 5/8

41.275

1.61

1 11/16

42.862

1.43

1 3/4

44.450

1.29

1 13/16

46.037

1.16

1 7/8

47.625

1.05

1 15/16

49.212

.948

2

50.80

.862

2 1/8

53.975

.719

2 1/4

57.151

.604

2 3/8

60.325

.515

2 1/2

63.500

.441

2 5/8

66.675

.373

2 3/4

69.850

.325

2 7/8

73.025

.284

3

76.200

.250

3 1/4

82.550

.197

3 1/2

88.900

.157

3 3/4

95.250

.128

4

101.600

.105

4/1/2

114.300

.074

Material Analysis:
All sizes and grades of corrosion-resisting hardened stainless steel balls are made to ASTM 756.  Passivation to ASTM A380 and QQ P 35 is available upon request.

Material

CDA

Federal

Military & Gov’t Std.

ASTM

UNS

AMS

Type 440

440-C

QQ-S-763b

MS 19060

ASTM-756

S-44004

5630G
5880A

Chemical Analysis

Carbon................................................................

0.95% to 1.10%

Chromium...........................................................

16.0% to 18.0%

Manganese.........................................................

1.0% maximum

Silicon..................................................................

1.0% maximum

Molybdenum........................................................

0.40% to 0.65%

Phosphorus.........................................................

0.025% maximum

Sulphur.................................................................

0.025% maximum

Nickel...................................................................

0.75% maximum

Copper.................................................................

0.5% maximum

Mechanical Properties
Type 440-C steel balls are uniformly hardened and tempered throughout their entire diameter to achieve maximum strenght and quality.  Ball hardness is 58-65 Rockwell “C” as measured on parallel flat surfaces. Also, type 440-C stainless steel balls are magnetic. Custom heat treating is available for special hardness requirements.

Tensile Strength..................................................

285,000 psi

Yield Strength......................................................

275,000 psi

Elongation in two inches....................................

2.0%

Reduction in area................................................

10.0%

Modulus of elasticity...........................................

29,500,000 psi

Density.................................................................

0.277 lbs./cu. in.



Click Here for Ball Terms and Definitions (Grades Available and Tolerances)
